RADIOGRAPHIC FILM PROCESSING DARKROOM

1
RADIOGRAPHIC FILM PROCESSINGDARKROOM
2
THE PROCESSING AREA

• PROCESSING AREA
• VIEWING SECTION

3
VIEWING AREA
PROCESSING AREA
4
VIEWING SECTION VIEWBOX ILLUMINATION
INTENSITY-500-1000 FOOT CANDLES
5
PHOTOMETER IS USED TO MEASURE VIEWBOX
ILLUMINATION INTENSITY
6
VIEWING STATION
7
VIEWING AREA HOT LIGHT
8
MOST OF MODERN MEDICAL IMAGING DEPARTMENTS USE
AUTOMATIC PROCESSORSMOST OF THOSE ARE DAYLIGHT
PROCESSORS
9
AUTOMATIC DAYLIGHT PROCESSORS
10
AUTOMATIC DARKROOM PROCESSORS
11
AUTOMATIC DARKROOM PROCESSORS
12
MANUAL PROCESSING
13
DARKROOM
14
BASIC COMPONENTS OF DARKROOM
STORAGE SHELVES
WORKBENCH
15
BASIC COMPONENTSPROCESSOR
16
BASIC COMPONENTSCHEMISTRY MIXING TANKS
17
BASIC COMPONENTSFILM DUPLICATOR
18
DUPLICATING FILM EXPOSED TO ULTRAVIOLET RADIATION
19
BASIC COMPONENTSFILM FLASHER
20
BASIC COMPONENTSSILVER RECOVERY SYSTEM
21
BASIC COMPONENTSFILM BIN
22
FILM BIN AUDIO ALARM
23
FILM BIN ANATOMY

• CONTAINS INDIVIDUAL SLOTS THAT HOLD FILMS OF
  DIFFERENT SIZES

24
TYPICAL DARKROOM FILM BIN
OTHER FILMS
8 x 10
10 x 12
11 x 14
14 x 17
FRONT
25
RADIOGRAPHIC FILM SIZES

• 14 X17
• 11 x 14
• 10 x 12
• 8 x 10
• 7 x 17
• 6 x 12
• 14 x 36

• 35 x 43
• 28 x 35
• 25 x 30
• 20 x 25
• 18 x 43
• 15 x 30
• 35 x 91

26
DARKROOM LIGHT

• WHITE LIGHTS
• SAFELIGHTS

27
WHITE LIGHT IS USED FOR

• EQUIPMENT REPAIR AND DARKROOM CLEANING

28
SAFELIGHTS USED

• DURING FILM PROCESSING

29
SAFELIGHT BULBSINCANDESCENT RECESSED WITHIN
METALLIC LIGHT FIXTURE

• RED FILTER-- KODAK GBX-2 OR GS-1
• AMBER FILTER --WRATTEN 6B

30
SAFELIGHTS

• REDGREEN LIGHT SENSITIVE FILM ORTHOCHROMATIC
• AMBER BLUE LIGHT SENSITIVE FILM
• TOTAL DARKNESS FOR PANCHROMATIC FILM

31
AT LEAST 3 FEET FROM THE FILM TRAY
7.5 W
FILM TRAY
32
AT LEAST 4 FEET FROM THE FILM TRAY
15 W
FILM TRAY
33
LATENSIFICATION

• INCCREASED SENSITIVITY TO SAFELIGHT ILLUMINATION
  AFTER FILM WAS EXPOSED

34
DARKROOM DESIGN
35
LEAD SHIELDING IF ADJACENT TO X-RAY ROOM

• 1/16 INCH OF LEAD IN THE WALLS ALL THE WAY TO THE
  CEILING.

36
IF ADJACENT TO X-RAY ROOMS

• PASS-BOXES NEEDED TO PASS FILMS DIRECTLY FROM
  THE X-RAY ROOM TO DARKROOM

37
VENTILATION

• SYSTEM MUST BE LIGHTPROOF AND ABLE TO FILTER OUT
  DUST

38
HUMIDITY

• 40-60
• gt 60--FILM FOG
• lt40 STATIC ARTIFACTS

39
SIZE

• BIG ENOUGH!!!?

40
COLOR

• WALLS AND CEILING CAN BE PAINTED IN ANY COLOR

41
TEMPERATURE

• 50-70 º F FOR FILM STORAGE TO SLOW DOWN THE
  AGING PROCESS OF THE FILM

42
WOULD YOU STORE IT LIKE THIS???
43
STORE YOUR FILMS STANDING ON THE EDGE TO AVOID
PRESSURE MARKS. USE FILM STORAGE CARTS OR SHELVES
44
DARKROOM ENTRANCE REVOLVING DOOR
45
DARKROOM ENTRANCESINGLE DOOR
46
DARKROOM ENTRANCEDOUBLE DOOR
47
DARKROOM ENTRANCEMAZE
48
COLOR OF THE MAZE

• DARK-- NOT OT REFLECT WHIT LIGHT INTO THE DARKROOM

49
DARKROOM TESTING

• WHITE LIGHT LEAKS
• SAFELIGHT FOG

50
SAFELIGHT TEST
