Rebanding Update

1
Rebanding Update
2
Basic Rebanding Message

• Interference has been a serious problem for 800
  MHz Public Safety and Critical Infrastructure
  communications
• FCC spent 2 1/2 years studying problem with 10s
  of thousands of pages of comments
• Report and Order was designed to reduce PS
  interference
• If you are impacted, it is mandatory--you cant
  get out of it
• All costs are covered
• Motorola is here to help you through the process
  and provide the absolute minimum disruption to
  your operation

3
Impacts to Subscribers and Infrastructure
4
Motorolas System Categories System impact falls
into 4 categories based upon channels used

• A Channels in first 120 only (806.0125/851.01
  25 808.9875/853.9875)
• No NPSPAC 821-824 Channels at all
• B Channels in NPSPAC only (821.0125/866.0125
  823.9875/868.9875)
• No Channels in 806-809 General Category
• C Channels in NPSPAC and first 120 / Expansion
• D Channels in Interleaved spectrum
  (809.0125/854.0125 815.9875/860.9875)
• No NPSPAC 821-824 Channels at all
• No 806-809 General Category Channels

Note Expansion Band PS will move, unless they
opt to stay
5
Retune/Reprogram/Update/Replace Definitions

• Retune Updating the channel frequencies via the
  Customer Programming Software/Radio Service
  Software programming software
• Reprogram Updating operating software via
  software FLASH with new frequencies band plan
• Update One or more boards must be replaced in
  the equipment to enable retuning or reprogramming
• Replace Cannot be updated to support new
  frequencies or band plans

6
Subscriber Impact -- Category A Channels in
first 120 only

• System with channels from 851.0125 /
  806.0125 to 853.9875 / 808.9875
• Relocates to channels from 854.0125 /
  809.0125 to 861.9875 / 816.9875
• Does not have any NPSPAC channels including
  Mutual Aid programmed in radio
• Equipment impact
• Radio units can be retuned to new frequencies
• Radios in red are class B IM protection. Motorola
  recommends replacing those units for better
  interference protection after rebanding
• Costs to replace radios that can be
  retuned or reprogrammed will be the
  responsibility of the licensee

7
Subscriber Impact -- Category B Channels in
NPSPAC only

• System with NPSPAC channels from
  866.0125/821.0125 to 868.9875/823.9875
• Relocates to rechanneled 851.0125/806.0125
  853.9875/808.9875
• 821/866-824/869 MHz must be reflashed with new
  radio software to operate in 806/851-809/854 MHz
• All radios must be retuned. The radios must be
  reprogrammed with a new RSS/CPS programming
  software to support new channels

Reprogram Subscriber
Replace Subscriber
Spectra Spectra E Saber SI STX Gemini Plus MTX
820 MaxTrac LCS 2000 LTS 2000 MTS2000
(256k) ASTRO Saber (512k) ASTRO Spectra (lt96)
XTS5000 XTS2500 XTS1500 XTS3000 MCS2000 MTS2000
(512k) ASTRO Saber (1MB) ASTRO Spectra
(gt95) XTL5000 VRM PRM (All)
8
Subscriber Impact -- Category C Both NPSPAC
first 120 Channels

• System with NPSPAC channels from 866.0125 /
  821.0125 to 868.9875 / 823.9875 and channels from
  851.0125 / 806.0125 to 853.9875 / 808.9875
• May be a multi-step process
• First Relocation from lower 120 (851.0125 /
  806.0125 to 853.9875 / 808.9875) is retune only
• Second Relocation to rechanneled
  851.0125/806.0125 853.9875/806.9875 is
  Reprogram and/or Replace
• All radios with NPSPAC channels must be
  re-flashed with new radio software to operate in
  new NPSPAC channels (806/851 - 809/854 MHz)
• All radios must be retuned. Radios must be
  reprogrammed with a new RSS/CPS programming
  software to support new channels

Reprogram Subscriber
Replace Subscriber
Spectra Spectra E Saber SI STX Gemini Plus MTX
820 MaxTrac LCS 2000 LTS 2000 MTS2000
(256k) ASTRO Saber (512k) ASTRO Spectra (lt96)
XTS5000 XTS2500 XTS1500 XTS3000 MCS2000 MTS2000
(512k) ASTRO Saber (1MB) ASTRO Spectra
(gt95) XTL5000 VRM PRM (All)
9
Subscriber Impact -- Category D Channels in
Interleaved spectrum

• System with channels from 854.0125 / 809.0125
  860.9875 / 815.9875 only
• At this time, no impact
• However,
• Public Safety licensees in new Expansion band
  channels 860.0125 / 815.0125 to 860.9875 /
  815.9875 can relocate if desired to frequencies
  below 809-815 / 854-860 MHz.
• Project only requires retuning for those who move
  out of Expansion Band

10
Category B C Product Replacement Mapping
Rebanded Subscribers
Replace Subscriber
Decision for 01 to 03 Portable If the portable
is a model III, requires encryption or 255
channels, it should be replaced with an 03
radio. Otherwise, it should be replaced with
01s LTS2000 are replaced with 03s Mobile If
the mobile requires encryption or 255 channels,
it should be replaced with an 03
radio. Otherwise, it should be replaced with
01s LCS2000 are replaced with 03s
RBP03 RBP01 RBM03 RBM01
LTS 2000 ASTRO Saber (512k) Saber SI MTS2000
(256k) STX Gemini Plus STX LCS 2000 ASTRO
Spectra (lt96) Spectra Spectra E MaxTrac Syntor
9000 Syntor X MICOR Mostar Traxar Motrar
Encryption Model III Large Channel size
No Encryption Model I
Encryption Large Channel size
No Encryption
11
Replacement ProductsCategory B and C
RBP03
RBP01
PORTABLES
RBM03
RBM01
MOBILES
12
Subscriber Summary

• If system is 806-816 MHZ only it is a Retune
• If subscriber has any NPSPAC trunking channels,
  use replacement radio chart
• Be sure youve checked your interoperability
  plans
• Rebanding radios are driven by 3 factors
• Display
• Encryption
• Number of channels
• Accessories will be swapped on 1 for 1 basis

13
Systems Impact Categories A D (No NPSPAC
821-824MHz channels)
Reprogram or Replace

• ASTRO/Analog SmartZone 4.1
• ASTRO 25 6.X (SE LE included)
• Private Data Systems
• Privacy Plus
• Privacy Plus-Enhanced
• SMARTNET I
• SMARTNET II (21 channels)
• SMARTNET II
• SMARTNET 3.O
• SMARTNET 3.1
• SMARTNET 3.2
• SmartWorks
• SmartZone 2.03
• SmartZone 3.0
• SmartZone OmniLink 3.5
• StartSite

None
Unknown SPs are at risk
14
Systems Impact Categories B C (Includes
NPSPAC 821-824 MHz Channels)
Update
None
ASTRO 25 6.X - SE and LE included Private Data
Systems
SMARTNET I SMARTNET II (21 channels)
SMARTNET II SMARTNET 3.O SMARTNET 3.1 SMARTNET
3.2 SmartWorks SmartZone 2.03 SmartZone
3.0 SmartZone OmniLink 3.5 SmartZone 4.1
ASTRO/Analog StartSite
Unknown SPs are at risk
15
Stations
Reprogram
Retune

• Retune
• All Categories
• DSS I, II, III (Data Stations)
• MTR 2000
• MSF 5000
• Quantar
• Quantro
• STR 3000
• MICOR-Non-Simulcast
• Note Requires retune of high stability
  oscillator in Channel Element
• MICOR Simulcast
• Note Requires retune of Reis Lab Synthesizer
• For Category A D
• IntelliRepeater (IR)

For Category B C IntelliRepeater (IR)
16
Controllers

• For Category B C 6809 (Pre-28Ch)

Retune
Retune
Reprogram

• Retune

Update
All Categories RNC3000 RNC6000 NCP3000 For
Category A D 6809 MTC 3600 IMP Zone Controller
MZC 3000 CSC 7000
For Category B C 6809 (28 Channel) -
Includes StartSite SmartWorks MTC 3600 IMP
Zone Controller MZC 3000 CSC 7000
17
Network Management
Replace
Retune
Reprogram

• For Category B C
• SIMS I
• SIMS II
• SIP

• All Categories
• Zone Manager
• Site Command
• Site Control Manager
• For Category A D SIMS II
• System Watch II
• SIP
• SIMS I (Open Issue)
• Site Lens

For Category B C System Watch II Site Lens
18
Consoles

• Conventional onlyNo Impact
• Category A D Trunked SystemsNo Impact
• Impact on Category B C SystemsNo Impact with
  two exclusions
• Trunked CENTRACOM II will have to be replaced
• CENTRACOM Series II still being evaluated

19
Software Development and Certification Effort For
Fielded Units

• New channel assignment required to move NPSPAC to
  lower part of band
• Channel Spacing in 806-809 changes with new band
  plan
• Channel number to frequency translation must
  change
• Control channel list has been increased to allow
  old and new assignments
• Failsoft channel list has been increased to allow
  old and new assignments
• New plan allows radios to work on either upgraded
  or not upgraded site
• Simplifies rebanding migration process
• Minimizes disruption to Licensees
• Greatly reduces infrastructure costs and overlay
  requirements
• Reduces number of duplicate systems needed
• Enables system-wide mobility throughout customer
  migration

20
Band Plan Migration
Old Plan New Plan (Includes Old Plan)
Site 1
Site 2

• Step 1 Update Mobile with New Plan (Includes
  Old Plan)

21
Band Plan Migration
Old Plan New Plan (Includes Old Plan)
Site 1
Site 2

• Step 1 Update Mobile with New Plan (Includes
  Old Plan)
• Step 2 Update Site 1 with New Plan

22
Band Plan Migration
Old Plan New Plan (Includes Old Plan)
Site 1
Site 2

• Step 1 Update Mobile with New Plan (Includes
  Old Plan)
• Step 2 Update Site 1 with New Plan
• Step 3 Update Site 2 with New Plan

23
Infrastructure Summary

• Impact on Non-NPSPAC Systems is Retune
• Impact on NPSPAC Systems requires more effort
  Reprogram or Update
• SMARTNET I II need HW Replacements
• Other Systems need new SW
• New band plan software incorporates both before
  and after plans
• Simplifies rebanding process significantly

24
Motorola Rebanding Services

• Management services
• Pre rebanding services
• Inventory
• Impact assessment
• Costing
• Engineering services
• Baseline current system operation
• System design
• Overall project management
• System rebanding
• Subscriber changes
• Infrastructure changes
• Site upgrades and antenna systems
  installation--when necessary
• Perform final Acceptance Test Plan

25
Information Sources

• Motorolas Public Website www.motorola.com/800r
  ebanding
• Specific 800 MHz Rebanding Questions
• RebandQs_at_motorola.com
