Turbinate Dysfunction

1
Turbinate Dysfunction

• Shashidhar S. Reddy, MD, MPH
• Matthew Ryan, MD
• March 2003

2
Overview

• Focus on Nasal Obstruction
• Anatomy
• Histology and Physiology
• Evaluation of Nasal Obstruction
• Turbinate Disorders
• Medical Management
• Surgical Management

3
Anatomy

• Inferior Turbinate
• An inferior infolding of the lateral nasal wall.
• 60 mm in anterior to posterior direction.
• Forms an important component of the nasal valve.
• Derived from the maxilloturbinal ridge.

4
Anatomy

• Middle Turbinate
• Lies medial to the anterior ethmoid air cells,
  the maxillary sinus ostium, the nasofrontal duct,
  and the uncinate process.
• Length of 40 mm and mean height of 14.5 mm
  anteriorly and 7 mm posteriorly.
• Develops from the second ethmoturbinal.

5
Anatomy

• Superior Turbinate
• Meatus drains the posterior ethmoid air cells.

6
Anatomy

• Nasal Valve
• External Nasal Valve
• Boundaries include
• lower lateral cartilages
• Soft tissue alae
• Membranous septum
• Sill of the nostril
• Can be site of obstruction (e.g. s/p rhinoplasty)

7
Anatomy

• Internal Nasal Valve
• Boundaries include
• Septum
• Upper lateral cartilages
• Anterior end of inf. Turbinate
• 1.3cm from nares
• Accounts for 50 of airway resistance
• Inferior turbinate can affect this area greatly

8
Histology

• Three layers of Turbinates
• Medial thin mucosa
• Bone
• Lateral thick mucosa

From   Berger Laryngoscope, Volume
111(12).December 2000.2100-2105
9
Histology

• Mucosa
• Pseudostratified columnar ciliated respiratory
  epithelium
• Goblet cells produce salts, glycoproteins,
  polysaccharides, lysozymes.
• Complex array of arteries, veins, and venous
  sinusoids.
• Lamina Propria contains the above tissue.

10
Physiology

• Functions of the Nose Related to Turbinates
• Airway
• Filtration most particles gt 30?m
• Heating to 31-37 degrees
• Humidification to 95

11
Physiology

• Chemical or microbial irritation leads to rapid
  inflammatory response.
• Nasal cycle lasts 2-6 hrs, occurs in 20-80 of
  people.
• Sympathetic nervous system increases vascular
  resistance
• Parasympathetic nervous system (vidian nerve)
  relaxes capacitance vessels.
• Sensory receptors temperature receptors

12
Evaluation of Patients

• History nasal obstruction symptoms
• Physical exam
• Look for dynamic and structural cause of nasal
  obstruction.
• Check before and after decongestion.

13
Evaluation of Patients

• Rhinomanometry
• Anterior pressure sensor in one nostril, flow
  meter in a mask.
• Posterior pressure sensor in the mouth, flow
  meter in a mask.
• Ohms Law RP/V
• Normal is .15 to .3 Pa/cm3
• gt.3 is usually associated with symptoms.

14
Evaluating Patients

• Acoustic Rhinometry
• Measures cross-sectional area (CSA)
• Minimal CSA before consistent reporting of nasal
  obstruction is .3cm2 or less.
• Above .3cm2, reliability to predict gradation of
  symptoms is controversial.

15
Evaluating Patients

• Other tests
• Olfaction tests
• Nasal smear
• Tests of humidity and heating

16
Turbinate Disorders

• Allergic rhinitis
• Histologic turbinate findings mast cell
  abundance, seromucous gland hyperplasia,
  interstitial fibrosis, eosinophils on smear.
• Probably the most frequent cause of
  turbinate-related nasal obstruction.
• Acute rhinosinusitis Exam similar to AR
• Leukocytes on nasal smear.

17
Turbinate Disorders

• Chronic Rhinosinusitis
• Leads to longstanding changes in mucosa.
• Fibrosis, polyposis.
• Vasomotor Rhinitis
• Nasal congestion, rhinorrhea only
• Drug Induced Rhinitis

18
Turbinate Disorders

• Nasal Polyposis
• Etiology unclear - ?denervated mucosa
• Samters Triad
• Atrophic Rhinitis
• Progressive slow atrophy of nasal mucosa
• Questionable association with aggressive
  turbinate resection

19
Turbinate Disorders

• Anatomic
• Septal Deviation
• Concha Bullosa

From Baylor Grand Rounds Archive
20
Turbinate Disorders

• Anatomic
• Paradoxical middle turbinate curvature in 10-29
• Synechiae, polypoid changes

21
Medical Management

• Allergic Rhinitis Nasal steroids with oral
  and/or topical antihistamines, systemic
  decongestants.
• Drug induced rhinitis cessation of topical
  medicine and switch to steroids.
• Nasal Polyposis systemic steroids, topical
  steroids.
• Rhinosinusitis Antibiotics

22
Surgical Management

• Total inferior Turbinectomy
• Benefits
• Most effective in terms of LONG TERM improvement
  of airway
• Ophir et al followed 186 patients for 10 years
  and showed that 82 showed subjective
  improvement, 95 had widely patent airways

23
Surgical Management

• Total Inferior Turbinectomy
• Disadvantages
• Postoperative hemorrhage rate of 5-8
• Nasal crusting, sometimes lasting for months, up
  to 15 at one year, in a study by Mabry et al
  (40pts. followed for one year)
• Synechiae 6-12 of the time
• Atrophic rhinitis? Classic study by Moore shows
  rate of 66 in group of 18 pts at 3-5 years. Six
  ENTs in Australia reported none in 17,000 cases.
  (Fry et al 1992)

24
Surgical Management

• Partial Turbinectomy
• Anterior portion, at nasal valve, is resected.
• Advantages
• Addresses nasal valve
• Courtis showed 92 satisfaction at gt2 years
• Disadvantages
• Similar to total, but less severe

25
Surgical Management

• Submucous Resection
• Advantages
• Decreased risk of hemorrhage
• Preserves mucociliary clearance and air
  conditioning
• Disadvantages
• Technical difficulty
• Tendency to relapse 25 in a 1988 study by
  Mabry et al

26
Surgical Management

• Mucosal Lesion-Producing techniques
• Electrocautery, Cryosurgery, Laser Surgery
• Advantages
• Local Anesthesia, Easy, low hemorrhage risk
• Disadvantages
• Extensive post-op crusting, probable regrowth of
  lesions

27
Surgical Management

• Laser Illustrations

28
Surgical Management

• Submucous Lesions
• Radiofrequency unipolar or bipolar
• Study by by Back et al on twenty patients showed
  improvement in nasal cross-sectional area by
  acoustic rhinometry at one year
• KTP, Argon, and CO2 have all been shown to be
  effective.

29
Surgical Management

• Corticosteroid Injection
• Advantages minimally invasive, low cost, cost
  effective
• Disadvantages - Effects wear off by 6 weeks
• Microdebrider

30
Surgical Management

• Vidian Neurectomy
• Ligate vidian nerve, thus cutting parasympathetic
  supply.
• Transantral, Transseptal, Transpalatal.
• Good immediate relief (Fernandes et al) reports
  88 of 139 patients reported improvement in
  rhinorrhea.
• Can have high complication rate including bleeding

31
Surgical Management

• Middle Turbinate
• Concha Bullosa
• Indications
• Complications

32
Surgical Management

• Middle Turbinate
• Medialization after sinus surgery
• Prevents synechiae formation?

33
Surgical Management

• Resection of the normal middle turbinate?
• Havas, et al. show clear benefit in reducing
  synechiae requiring revision at osteomeatal
  complex after partial resection of middle
  turbinate (15 without resection vs. 7.1 with)
  in a randomized trial of gt1000 patients.

34
Conclusion

• Anatomy
• Histology/Physiology
• Evaluation of Nasal Obstruction
• Turbinate Disorders
• Medical Management
• Surgical Management
• Controversial

35
Bibliography McCaffrey, Thomas V., Nasal
Function and Evaluation, Byron J. Baileys Head
and Neck Surgery Otolaryngology, Third Edition,
pgs 261-271. Lippincott Williams and Wilkins
Philadelphia, 2001. Lindemann, Jorg, MD Impact
of Unilateral Sinus Surgery with Resection of the
Turbinates by Means of Midfacial Degloving on
Nasal Air Conditioning, Laryngoscope, 112(11),
pgs. 2062-2066. Jafek, Bruce W. et al Nasal
Obstruction, Head and Neck Surgery
Otolaryngology, Third Edition, pgs 293-308.
Lippincott Williams and Wilkins Philadelphia,
2001. Dowley, A.C. et al The effect of inferior
turbinate hypertrophy on nasal spray distribution
to the middle meatus, Clinical Otolaryngology
26(6) pgs 488-490. Ophir, D. et al, Total
inferior turbinectomy for nasal airway
obstruction, Archives of Otolaryngology 11193,
1985. Courtiss, E.H. et al Resection of
obstructing inferior turbinates a 6 year
follow-up, Plastic Reconstructive Surgery 72
913, 1983. Jackson, Lance E et al Controversies
in the Management of Inferior Turbinate
Hypertrophy A Comprehensive Review, Lippincott
Williams and Wilkins, Plastic and Reconstructive
Surgery 103(1) pgs 300-312. Leunig, Andread, MD
et al Ho YAG Laser Treatment of Hyperplastic
Inferior Nasal Turbinates, Laryngoscope 109(10)
pgs 1690-1695. Havas, TE Lowinger, DSG,
Comparison of functional endonasal sinus surgery
with and without partial middle turbinate
resection, Annals of Otolgoy, Rhinology,
Laryngology, 109634-640 pp 113-119. 10. Fisher,
E.W. Acoustic Rhinometry Reproducibility and
Reliablity, Clinical Otolaryngology, 22(4) pp
307-317. Hanif, J et al, The nasal cycle in
health and disease. Clinical Otolaryngology and
Allied Sciences, 25(6) pp 461-467. Mygin, N.
Nasal Polyposis, Eosinophil dominated
inflammation, and Allergy, Thorax 55(supplement
2) pp s79-s83. Berger, Gilead et al,
Histopathology of the inferior turbinate with
compensatory hypertrophy in patients with
deviated nasal septum, Laryngoscope 111(12) pp
2100-2105. Saunders, M.W. et al, Parameters of
nasal airway anatomy on magnetic resonance
imaging correlate poorly with subjective symptoms
of nasal patency Clinical Otolaryngology
Allied Sciences 24(5) pp 431-434.Howard, et al
Understanding the Nasal Airway Principles and
Practice, Plastic and Reconstructive Surgery,
109(3) pp 1128-1146.Thornton, Robert S., Middle
Turbinate Stabilization Technique in Endoscopic
Sinus Surgery Arch Otolaryngol Head Neck
Surg.1996122869-872Dogru, Harun. Tuz, Mustafa.
Uygur, Kemal. Cetin, Meltem, A New Turbinoplasty
Technique for the Management of Concha Bullosa
Our Short-Term Outcomes, Laryngoscope.
111(1)172-174, January 2001.Back et al,
Sumucosal Bipolar Radiofrequency thermal
ablation of inferior turbinates A long-term
follow-up with subjective and objective
assessment, Laryngoscope 112(10) pp 1806-1812.
