IMT 140

1
IMT 140

• Chapter 16
• Typical Bell Circuits

2
Bell Circuits

• Nearly every electrical installation includes
  some type of signaling circuit.

3
Bell Circuit Rules

• It is easy to wire simple low-voltage bell
  circuits if 3 rules are followed.
• 1. Connect a conductor from 1 side of the
  voltage source to the bell.
• 2. Connect a conductor from the other side of
  the voltage source to the control point (or
  pushbutton).
• 3. Connect a conductor from the pushbutton to
  the bell which is to be controlled.

4
Bell Circuits

• Figure 16-1 shows a bell controlled from 1
  pushbutton using a transformer as a source of
  power.

5
What type circuit is this?
This is a simple series circuit.
6
What does the transformer do in this circuit?
7
Bell Buzzer Circuits

• A bell may be controlled from more than 1
  location.
• The same 3 rules apply to these applications.
• These pushbuttons will be in parallel and the
  pushbutton combination will be in series with the
  bell.

8
Bell Buzzer Circuits

• Several signaling devices, each controlled with a
  separate pushbutton, may be used on the same bell
  transformer.
• However, to distinguish between the different
  devices, it is common use different tones for
  each device.
• (Most homes use different tones for the front
  doorbell and the rear doorbell.).

9
(No Transcript)
10
What type circuit is this?
This is a Series-Parallel Circuit.
11
Bell Buzzer Circuits

• Combination units containing a bell and buzzer in
  a single housing are commonly used.
• This type of signaling device has 3 terminals.
  (See figure 16-4).
• The terminals are connected as follows
• Center terminal to the transformer.
• Right-hand terminal to the front door pushbutton.
• Left-hand terminal to the back door pushbutton.

12
(No Transcript)
13
Pushbuttons

• Pushbuttons are used to open and close a bell
  circuit.
• When the button is depressed, the circuit is
  closed.
• This is basically a single pole, normally open
  switch.

14
Doorbells

• Figure 16-5 is a typical doorbell.
• Two small coils of insulated wire mounted on iron
  cores form an electromagnet.
• Current passes from terminal A to E by the way of
  the electromagnets, contact points B C and the
  armature.

15
Doorbells

• When the circuit is energized, the 2 coils become
  electromagnets and attract the armature toward
  the iron cores. This causes
• The hammer to strike the gong and at the same
  instant
• Causes contacts B C to separate by the action
  of the moving armature.

16
Doorbells

• The circuit is now open and the coils no longer
  attract the armature.
• The cycle of operation is very rapid which causes
  the armature, contact spring and the hammer to
  vibrate rapidly.

17
Adjustment screw
Coils and Iron Cores
Armature
18
Buzzers may be used with bells to distinguish
between which pushbutton was activated.
19
This coil is for the bell And this coil is
for the buzzer.
20
Door Chimes

• Many homes use chimes rather than a door
  bell/buzzer.
• These are available in many tones and can be
  designed for multiple entrances.

21
Bell Transformer

• Chime transformers are generally larger in
  capacity than bell or buzzer transformers.
• Voltages for chimes range from 10 to 24 volts
  with a rating of 5 to 20 volt-amperes.
• Bell transformers are generally rated at 6 to 10
  volts with a rating of 5 to 20 volt-amperes.

22
Bell Wire

• Number 18 AWG is generally used for bell wire.
• Single or multiple conductor wire is available.
• Special staples are used with bell wire.

23
National Electric Code

• In general, bell wires with low voltage
  insulation should not be installed in the same
  raceway or enclosure with lighting or power
  conductors.
• Check Article 725 of the NEC for further details.

24
The End!!
