Title: String-wound Filter Cartridges


1
String-wound Filter Cartridges
Superiorfiltration technology
2
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • Yarn consists of continuous filaments.
  • No short fibers to come loose and migrate.

Sedifilt media
3
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • No chemical leaching
  • No chemicals to leach out with new melt spinning
    and yarn forming process (patented).
  • No downstream foaming in filtrate.
  • 100 pure polypropylene.

4
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • No chemical leaching
  • True graded density
  • New winding technology.
  • Continuously controlled pitch, number
    ofcrossings and space between each strandof
    yarn.
  • Denser winding in inner layers,coarser winding
    in outer layers.
  • Consistent winding tension.high structural
    integrity,more consistent performance.

5
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • No chemical leaching
  • True graded density
  • High dirt holding capacity
  • Longer life as particles are trappedthroughout
    the cross-section of the filter.

6
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • No chemical leaching
  • True graded density
  • High dirt holding capacity
  • High bulk mediaBetter performance
  • Media with high bulk, stable, three-dimensional
    random structure with multi-lobal cross section
    filaments.
  • Captures more particles compared to conventional
    filters.
  • Improved solid to void ratio gives higher flow
    rates with low pressure drop.

7
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • No chemical leaching
  • True graded density
  • High dirt holding capacity
  • High bulk mediaBetter performance
  • 100 polypropylene
  • 100 pure homopolymer polypropylene.
  • Wide chemical compatibility.
  • Excellent micro-organism resistance.
  • Environmentally safe.
  • Ease of disposal.
  • Incinerates to trace ash.

8
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • No chemical leaching
  • True graded density
  • High dirt holding capacity
  • High bulk mediaBetter performance
  • 100 polypropylene
  • High structural stabilityNo particle unloading
  • Firm, stable structure.
  • No shifting of media.
  • Improved resistance to particle unloading.
  • More consistent performance.
  • Excellent knife-edge sealing.

9
Sedifilt string-wound filter cartridgesNew
developments in filter media
  • No media migration
  • No chemical leaching
  • True graded density
  • High dirt holding capacity
  • High bulk mediaBetter performance
  • 100 polypropylene
  • High structural stabilityNo particle unloading
  • Environmentally friendly
  • Environmentally friendly disposal.
  • Incinerates to trace ash.
  • No hazardous volatiles.

10
5 micron, 10 polypropylene cartridgeTest
results
11
Sedifilt string-wound filter cartridgesEconomic
benefits of Sedifilt
  • Increased filtration capacity
  • Higher dirt holding capacity
  • Longer lifetime
  • Fewer change outs
  • Reduced costs
  • Less labour requirement
  • Less equipment downtime
  • Lower inventory levels

5 micron 10" Dirt holding capacity
Ordinary string-wound 30-55 gm
Sedifilt string-wound 108 gm
12
Sedifilt string-wound filter cartridgesFilter
cartridge range End adapters and extended cores
13
Sedifilt string-wound filter cartridgesFilter
cartridge range
14
Sedifilt string-wound filter cartridgesApplicati
ons
  • RO Pretreatment (SDI Reduction)
  • Drinking Water and Beverage Processing
  • Sea Water Desalination
  • Deep Well Injection
  • Gas Purification
  • Cooling Tower Water Filtration
  • Electronics and Electroplating
  • Industrial Process Water
  • Pharmaceutical Healthcare
  • Chemical Industry
  • ED Automotive Paint
  • Photographic Solutions
  • Wastewater Disposal
  • And more

15
String-wound Filter Cartridges
Comparison with conventional media
16
Conventional media cross-section
  • Round cross-section
  • Fewer micro-voids
  • Lower dirt holding capacity
  • Higher resistance to flow

17
Sedifilt media cross-section
  • Multi-lobal cross-section
  • More micro-voids
  • Higher dirt holding capacity
  • Lower resistance to flow

18
Comparison with conventional mediaConventional
media vs. Sedifilt media
  • Sedifilt media has a higher void to solid ratio,
    giving higher flow rates, improved dirt holding
    capacity, and lower pressure drop.

19
Conventional string-wound filter
cartridgesProblems with conventional media
  • Media migration
  • Short fibers are not properly or fully locked
    into the main body.
  • Fibers tend to come loose and migrate into
    filtrate with flow of liquid and pressure surges.
  • Loose fiber ends protruding from the surface can
    be seen clearly in friction-spun yarn media.

Friction-spun yarn media
20
Conventional string-wound filter
cartridgesProblems with conventional media
  • Media migration
  • Chemical leaching
  • Spin-finish chemicals (lubricants, surfactants,
    antioxidants, antistatic agents, emulsifiers,
    bactericides, etc.) leach out.
  • Evident as foaming in filtrate.
  • Washed media is never 100 clean.

Friction-spun yarn media
21
Conventional string-wound filter
cartridgesProblems with conventional media
  • Media migration
  • Chemical leaching
  • Particle unloading
  • Round cross-section media have unstable
    structure.
  • Under conditions of flow and pressure surges,
    unstable round yarns shift, giving rise to
    tunneling effect and particle unloading.

22
Conventional string-wound filter
cartridgesProblems with conventional media
  • Media migration
  • Chemical leaching
  • Particle unloading
  • Poor knife-edge sealing
  • Unstable edges cause seal by-pass problems.

23
Conventional melt-blown cartridgesMelt-blown
media
  • Only Advantage
  • Freedom from process chemicals
  • Disadvantages
  • Tendency to collapse under moderate pressure
    differential
  • Requires supporting core
  • Very poor knife- edge sealing
  • Particle unloading

Melt-blown filter cartridge
24
Resin-bonded filter cartridgesResin-bonded media
  • Disadvantages
  • Higher cost
  • Limited chemical compatibility
  • Bonding agent compatibility problems
  • Poor density grading
  • Lower dirt holding capacity
  • Prone to media migration media crumbles easily
  • Poor knife-edge sealing

Resin-bonded filter cartridge
25
Pleated paper cartridgesPleated paper media
Pinched pleat
  • Only Advantage
  • Absolute ratings are possible
  • Disadvantages
  • Consists of more than one material
  • Weak strength of thin paper media
  • Pleat pinch-off and pleat collapse problems

Collapsed pleat
Pleated paper cartridge
26
Comparison of surface and depth filtration
  • Direct interception
  • Particles larger in size than the pores deposit
    on surface of media
  • Numerous tortuous flow passages
  • Direct interception and dirt retention within
    depth of media
  • Complex mixture of mechanisms

27
String-wound Filter Cartridges
Increased filtration capacity
Reduced costs
Higher performance
Longer lifetime
Superiorfiltration technology
