Concepts of Chemical Bonding

1
Concepts of Chemical Bonding

• Brown, LeMay Ch 8
• AP Chemistry
• Monta Vista High School

2
8.1 Types of Inter-Atomic or Intra molecular
Bonding a.k.a bonding

• Ionic electrostatic attraction between
  oppositely charged ions. Ex. NaCl, K2SO4.
  Generally solids.
• Covalent sharing of e- between two atoms
  (typically between nonmetals). Ex. CO2, SO2.
  Generally gases and liquids
• Metallic sea of e- bonding e- are relatively
  free to move throughout the 3D structure
• Ex. Fe, Al, generally solids

IncreasingDiff. of EN
4. Covalent Network large number of
atoms/molecules bonded in a network through
covalent bonding. Ex. SiO2, Si, Ge, Diamond,
Graphite
3
8.2 Ionic Bonding

• Results as atoms lose or gain e- to achieve a
  noble gas e- configuration is typically
  exothermic.
• The bonded state is lower in energy (and
  therefore more stable).
• Electrostatic attraction results from the
  opposite charges. Electrostatic attraction
  (force) determines the strength of ionic bond,
  just like electro negativity difference
  determines the strength of covalent bond.
• Occurs when diff. of EN of atoms is gt 1.7
  (maximum is 3.3 CsF)
• Can lead to interesting crystal structures (Ch.
  11).
• Use brackets when writing Lewis symbols of ions.
• Ex Draw the Lewis symbol of fluoride.
  Animation of Ionic/Covalent BondingAnimation
  of LiCl Crystal

4
Lattice Energy

• Measurement of the energy of stabilization
  present in ionic solids
• DHlattice energy required to completely
  separate 1 mole of solid ionic compound into its
  gaseous ions

• Electrostatic attraction (and thus lattice
  energy) increases as ionic charges increase and
  as ionic radii decrease. Animation showing
  formation of a lattice

5

• The lattice energy of NaCl is the energy given
  off when Na and Cl- ions in the gas phase come
  together to form the lattice of alternating Na
  and Cl- ions in the NaCl crystal (in this case
  lattice energy is negative) or it may be defined
  as the amount of energy required to break 1 mole
  of solid NaCl into its ions in gaseous state (in
  this case lattice energy will be positive).
• Na(g) Cl-(g) ? NaCl(s) ?Ho -787.3 kJ/mol

6

• The lattice energies for the alkali metal halides
  is therefore largest for LiF (smallest size,
  smallest d) and smallest for CsI ( largest size,
  largest d), as shown below.
• Values of Lattice Energies of Alkali Metals
  Halides (kJ/mol)
• F- Cl- Br- I-
• Li 1036 853 807 757
• Na 923 787 747 704
• K 821 715 682 649
• Rb 785 689 660 630
• Cs 740 659 631 604 Data taken from Purdue
  website

7
Understanding Check

• Ex Which has a greater lattice energy? Why?
• NaCl or KCl NaCl or MgS

8
Covalent Bonding

• Atoms share e- to achieve noble gas configuration
  that is lower in energy (and therefore more
  stable).
• Occurs when diff. of EN of atoms is 1.7
• Polar covalent
• 0.3 lt diff. of EN 1.7 (e- pulled closer to
  more EN atom)
• Nonpolar covalent
• 0 diff. of EN 0.3 (e- shared equally)
• (ionic vs. covalent bonding in youtube video)
• Coordinate Covalent Shared pair contributed by
  only one of the two sharing species. Ex. Lewis
  acids and bases

9
Cl-Cl Bond in Cl2 molecule
Animation of bonding in Chlorine Molecule
10
23.5 Metallic bonding

• Metallic elements have low I.E. this means
  valence e- are held loosely.
• A metallic bond forms between metal atoms because
  of the movement of valence e- from atom to atom
  to atom in a sea of electrons. The metal thus
  consists of cations held together by
  negatively-charged e- "glue.

• This results in excellent thermal electrical
  conductivity, ductility, and malleability.
• A combination of 2 metals is called an alloy.

11
Free e- move rapidly in response to electric
fields, thus metals are excellent conductors of
electricity.
http//www.uwgb.edu/dutchs/EarthSC202Notes/mineral
s.htm
Free e- transmit kinetic energy rapidly, thus
metals are excellent conductors of heat.
Layers of metal atoms are difficult to pull apart
because of the movement of valence e-, so metals
are durable.
However, individual atoms are held loosely to
other atoms, so atoms slip easily past one
another, so metals are ductile.
12
Covalent (a.k.a. covalent network) Atoms bonded in a covalent network Covalent bonds Very hard Very high MP Generally insoluble Variable conductivity C (diamond graphite) SiO2 (quartz) Ge, Si, SiC, BN
Diamond
Graphite
SiO2
13
The Octet Rule

• Atoms tend to gain, lose, or share e- until they
  are surrounded by 8 e- in their outermost energy
  level (have filled s and p sub shells) and are
  thus energetically stable.
• Exceptions do occur (and will be discussed
  later.)
• Visualizing atomic orbitals

14
Lewis symbols

• Valence e-
• e- in highest energy level and involved in
  bonding all elements within a group on P.T. have
  same of valence e-
• Lewis symbol (or electron-dot symbol)
• Shows a dot only for valence e- of an atom or
  ion.
• Place dots at top, bottom, right, and left sides
  and in pairs only when necessary (Hunds rule).
• Primarily used for representative elements only
  (Groups 1A 8A)
• Ex Draw the Lewis symbols of C and N.

Gilbert N. Lewis(1875 1946)
C
N
15

• Transition metals typically form 1, 2, and 3
  ions.
• It is observed that transition metal atoms first
  lose both s e-, even though it is a higher
  energy subshell. Cr2, Cr3
• Most lose e- to end up with a filled or a
  half-filled subshell. Ex. Cu ion

16
Lewis Structures

• Lewis structures are used to depict bonding pairs
  and lone pairs of electron in the molecule.
• Step 1
• Total number of valence electrons in the system
  Sum the number of valence electrons on all the
  atoms . Add the total negative charge if you have
  an anion. Subtract the charge if you have a
  cation.
• Example CO32-

17

• Step 2
• Number of electrons if each atom is to be happy
  Atoms in our example will need 8 e (octet rule)
  or 2 e ( hydrogen). So, for the ex.
•  Step 3
• Calculate number of bonds in the system Covalent
  bonds are made by sharing of e. You need 32 and
  you have 24. You are 8 e deficient. If you make 4
  bonds ( with 2 e per bond) , you will make up the
  deficiency. Therefore,
• of bonds ( e in step 2- e in step 1)/2
  (32-24)/2 4 bonds

18

• Step 4
• Draw the structure The central atom is C (
  usually the atom with least electro negativity
  will be in the center). The oxygens surround it .
  Because there are four bonds and only three
  atoms, there will be one double bond.
• Step 5
• Double check your answer by counting total number
  of electrons.
• Drawing Lewis Structures (youtube video)

19

• Level 1 Practice for Lewis Structurs
• Draw the Lewis structures for the following using
  above steps. Show work!
• A.Cl2
• B. CH2Cl2
• C. NH3
• D. NaCl

20
Level 2 practice on Lewis Structures

• SO42- HCN
• H2O2 CNS1-

21
8.8 Exceptions to the Octet Rule

• Odd-electron moleculesEx NO or NO2 (involved
  in breaking down ozone in the upper atmosphere)
• Incomplete octet
• H2 He BeF2 BF3
• NH3 BF3 ? NH3BF3 (Lewis acid/base rxn)

22

• Expanded octet occurs in molecules when the
  central atom is in or beyond the third period,
  because the empty 3d subshell is used in
  hybridization (Ch. 9)
• PCl5 SF6

23
8.6 Formal Charge Movie on Formal Charge

• For each atom, the numerical difference between
  of valence e- in the isolated atom and of e-
  assigned to that atom in the Lewis structure.
• To calculate formal charge
• Assign unshared e- (usually in pairs) to the atom
  on which they are found.
• Assign one e- from each bonding pair to each atom
  in the bond. (Split the electrons in a bond.)
• Then, subtract the e- assigned from the original
  number of valence e-.

VALENCE e- in free atom NON-BONDING e-
½(BONDING e-) FC
24

• Used to select most stable (and therefore most
  likely structure) when more than one structure
  are reasonable according to the rules.
• The most stable
• Has FC on all atoms closest to zero
• Has all negative FC on most EN atoms.
• FC does not represent real charges it is simply
  a useful tool for selecting the most stable Lewis
  structure.

25
Examples Draw at least 2 Lewis structures for
each, then calculate the FC of each atom in each
structure.

• SCN1-
• N2O BF3

26
8.7 Resonance Structures

• Equivalent Lewis structures that describe a
  molecule with more than one likely arrangement of
  e-
• Notation use double-headed arrow between all
  resonance structures.
• Ex O3
• Note one structure is not better than the
  others. In fact, all resonance structures are
  wrong, because none truly represent the e-
  structure of the molecule. The real e-
  structure is an average of all resonance
  structures.

27
Bond Order

• An indication of bond strength and bond length
• Single bond 1 pair of e- shared
• Ex F2

Longest, weakest
F-F

• Double bond 2 pairs of e- shared
• Ex O2

• Triple bond 3 pairs of e- shared
• Ex N2

Shortest, strongest
N N
28
Bond Order Resonance Structures

• To determine bond order with resonance
  structures
• Determine the bond order at one position in one
  resonance structure, and add it to the bond
  orders at the same bond position in all other
  resonance structures.
• Divide the sum by the number of resonance
  structures to find bond order.

29
Examples draw the Lewis structure and determine
the bond S-O, C-C, and C-H bond orders

• SO3 C6H6

30
8.9 Bond enthalpy

• Amount of energy required to break a particular
  bond between two elements in gaseous state. Given
  in kJ/mol. Remember, breaking a bond always
  requires energy!
• Bond enthalpy indicates the strength of a bond.

• Bond enthalpies can be used to figure out ?Hrxn .
• Ex CH4 (g) Cl2 (g) ? CH3Cl (g) HCl (g)
  DHrxn ?
• 1 C-H 1 Cl-Cl bond are broken (per mole)
• 1 C-Cl 1 H-Cl bond are formed (per mole)
• ?Hrxn ? (Hbonds broken) - ? (Hbonds formed)
• Note this is the opposite of Hess Law where
• ?Hrxn DHproducts Dhreactants
• Bond Enthalpy link

31

• Ex CH4 (g) Cl2 (g) ? CH3Cl (g) HCl (g)
  DHrxn ?
• Bond Ave DH/mol Bond Ave DH/mol
• C-H 413 Cl-Cl 242
• H-Cl 431 C-Cl 328
• C-C 348 CC 614
• ?Hrxn ? (Hbonds broken) - ? (Hbonds formed)
• ?Hrxn (1(413) 1(242) 1(328) 1(431)
• ?Hrxn -104 kJ/mol
• ?Hrxn -99.8 kJ/mol (actual)
• Note 2 C-C ? 1 CC
• 2(348) 696 kJ ? 614 kJ

32
Ex CH4(g) Cl2(g) ? CH3Cl(g) HCl(g) DHrxn?
CH3(g) H(g) 2 Cl(g)
Absorb E, break 1 C-H and 1 Cl-Cl bond
Release E, form 1 C-Cl and 1 H-Cl bond
H
CH4(g) Cl2(g)
CH3Cl (g) HCl (g)
DHrxn
?Hrxn ? (Hbonds broken) ? (- Hbonds
formed) ?Hrxn ? (Hbonds broken) - ? (Hbonds
formed)
