Wood Joints

1
Wood Joints
2
What is Wood Joinery?

• Joinery is a part of woodworking that involves
  joining together pieces of wood, to create
  furniture, structures, toys, and other items.
  Some wood joints employ fasteners, bindings, or
  adhesives, while others use only wood elements.
• Joinery used to build a house is different from
  that used to make puzzle toys, although some
  concepts overlap.

3
Wood Joints

• Increased strength with the increase of glued
  surface area
• When selecting joints, consider strength,
  appearance, and difficulty
• Pieces to be joined should be cut and squared

4
Butt and Edge Joints

• Used on boxes and frames that are reinforced with
  screws or nails
• Butt joint
• Plain edge
• Doweled edge
• Rabbeted edge or edge lap
• Tongue and groove
• Splined and edge

5
Dados and Grooves

• Used for shelves, frames, bookcases, chests,
  cabinets
• Dado
• Blind dado
• Dado rabbet
• Groove

6
Rabbet joints

• Used for the corners of simple boxes, cases,
  drawers
• Formed with the grain or cross grain

7
Lap joints

• Cross-lap
• End-lap
• Middle-lap
• Half-lap

8
Mortise-and-Tension joint

• One of the strongest wood joints
• Blind
• Open (slip joint)
• Haunched
• Barefaced

9
Dowel Joints

• Very strong
• Easier to make than the mortis-and-tenon

10
Miter Joints

• Used for picture frames and moldings for
  furnature
• Feather
• Mitered end-lap
• Dowels
• Glue block
• Spline
• Lock

11
Dovetail and Box joints

• Lap dovetail
• Trough dovetail
• Box joints
• Half-blind dovetail
• Dovetail dado

12
Dovetail Joint Made with Hand Tools
13
Biscuit/Plate Joinery

• Joint made with biscuits wafers or plates
• Plate sizes
• 0 16 x 47mm
• 10 20 x 52mm
• 20 24 x 58mm

14
Assignment

• Locate and Identify at least five wood joints in
  the shop.
• Create a Dovetail Joint using only hand tools
  with the wood provided by the teacher.

15
Resources

• Youtube
• pp026.k12.sd.us/Wood20Joints.ppt
• Wikipedia
