FLOW CYTOMETRY

1
FLOW CYTOMETRY

• Dr. MOHAMMED H SAIEMA LDAHR
• KAAU
• FACULTY OF APPLIED MEDICAL SCIENCES
• MEDICAL TECHNOLOGY DEPT.
• 2ND YEAR MT
• INSTROMINTATION
• EXT 21060

2
WHAT IS A FLOW CYTOMETER

• IT IS A MACHINE

3
(No Transcript)
4
FCM
5
FLOW CYTOMETRY
6
FLOW CYTOMETRY
7
WHAT IS FLOW CYTOMETRY ?

• Flow Cytometry means measuring cells in a fluid
  medium.
• It is a technique for making rapid
  physical and or chemical measurement on particles
  or cells as they flow in a fluid stream one by
  one through sensing point .
• A technology that simultaneously measures
  multiple characteristics of single cells at a
  rapid rate.
• Is the measurement of cellular properties as they
  move in a fluid past a stationary set of
  detectors.
• FCM permits analysis of 105-106 cells per
  minutes, simultaneously measuring physical and
  biological properties.

8
WHAT IS FLOW CYTOMETRY ?

• FCM is an automated method used to measure cells
  or particles as they flow single file though a
  sensing area.
• Optical sensing is done with intense light
  source, usually LASER or mercury arc lamp.
• The FCM measures light scatter and fluorescent
  signal generated as cell pass through a light
  beam.

9
WHAT IS THE COMPONANTS OF THE FLOW CYTOMETER ?

• Instrument Components are,
• Fluidics
• Optics
• Electronics
• Data Analysis

10
Fluidics

• Cell transportation
• To introduce and focus the cells for
  interrogation
• Most instruments utilize a laminar/sheath flow
  and turbulent boundary drag techniques to confine
  (detain) cells to the center of the flow stream.
• Cells enters the chamber under pressure through a
  small aperture (opening) which is surrounded by
  sheath fluid.

11
Fluidics

• The sheath fluid in the sample chamber creates a
  hydrodynamic focusing effect and draw the sample
  fluid into a stream.
• Turbulent boundary flow, The sample is injected
  into a chamber tapering (narrowing) to a small
  exit orifice. The speed of the entry of the
  sample combined with the back pressure generated
  by the exit orifice results in sample turbulence.


12
(No Transcript)
13
FACScan FLUIDICS SYSTEM speed of the entry of
the sample combined with the back pressure
generated by the exit orifice results in sample
turbulence.
14
(No Transcript)
15
OPTICS

• Excitation optics consist of
• Laser Light Amplification by Stimulated Emission
  of
• Radiation
• Lenses to shape and focus the laser beam
• Collection optics consist of
• i- a collection lens to collect light emitted
  from the particle-laser
• beam interaction
• ii- a system of optical mirrors and filters to
  route specified
• wavelengths of the collected light
  to designated optical detectors

16
OPTICS

• LASER Light Amplification by Stimulated Emission
  of Radiation

17
OPTICS

• Laser have the advantage of producing an intense
  beam
• of monochromatic light.
• The most common laser used in FCM are
• Argon lasers, produce light between (351-528 nm)
• Krypton laser, produce light between (350-799 nm)
• Helium-neon laser produce lines at 543,594,611,
  and 633nm
• Helium-cadmium laser produce lines at 325 and 441
  nm.

18
OPTICS

• Forward Scatter Channel (FSC)
• A beam of laser light is projected at specific
  point of the flow cell .
• As a particle passes through the laser beam
  light, most of the light is scattered in the
  forward direction, this forward scatter is
  related to the size of the particle.

19
OPTICS (FSC)
