RCC Facing Using Vibrating

1
RCC Facing Using Vibrating Plate Compaction
Methods
2
Many Farms Dam Spillway Stilling Basin and
Downstream Apron
3
Many Farms Dam Spillway Stilling Basin 21 and
11 Side Slopes
4
Many Farms Dam Spillway

• Trackhoe with vibrating
• plate compactor

5
Many Farms Dam Spillway

• Trackhoe with vibrating
• plate compactor

6
Many Farms Dam 21 side Slope

• Trackhoe with vibrating plate compactor

7
Pueblo Dam Spillway RCC Toe Block

• Trackhoe with vibrating plate compactor
• 2 H 1 V side slope

8
Pueblo Dam Spillway RCC Toe Block

• Vibrating plate compactor 2 H 1 V side slope

9
Dulce Dam Overtopping Protection

• Hand-operated vibrating plate compactor

10
Dulce Dam Overtopping Protection

• Hand-operated vibrating plate compactor

11
Dulce Dam Overtopping Protection

• Hand-operated vibrating plate compactor

12
Cold Springs Dam Spillway Modification

• Dozer mounted vibrating plate compactor
• 1-1/2 1 side slope

13
Cold Springs Dam Spillway Modification

• Dozer mounted vibrating
• plate compactor
• 1-1/2 1 side slope

14
Cold Springs Dam Spillway Modification

• Dozer mounted vibrating plate compactor
• 1-1/2 1 side slope

15
Cold Springs Dam Spillway Modification

• Dozer mounted vibrating plate compactor
• 1-1/2 1 side slope

16
Ochoco Dam Spillway Modification

• RCC Plunge Pool
• 0.8 H 1 V slope
• 1H 1 V slope

RCC
17
Vesuvious Dam Facing RCC Overtopping Protection
18
Vesuvious Dam RCC Facing

• 2.5 H 1.0 V slope
• Hand-operated vibrating compactor

19
Vesuvious Dam RCC Facing

• 2.5 H 1.0 V slope
• Hand-operated vibrating compactor

Drains under RCC
20
Vesuvious Dam Facing

• RCC covered with grass
• (will erode with spillway operation)

21
Vesuvious Dam Facing

• RCC covered with grass
• (will erode with spillway operation)
