Title: ASIC 120: Digital Systems and Standard-Cell ASIC Design


1
ASIC 120 Digital Systems and Standard-Cell ASIC
Design
  • Tutorial 4 Digital Systems Concepts
  • November 16, 2005

2
Outline
  • Summary of previous tutorial
  • The FPGA LEs, buffers and routing
  • Other FPGA resources clocks, memories, memory
    interfaces, multipliers, etc.
  • Soft- and hard-processors in FPGAs
  • Bus interfaces
  • Register files

3
Summary of Previous Tutorial
  • Other signal values besides 0 and 1
  • More VHDL data types
  • Attributes, type definitions
  • Generics
  • Splitting a VHDL project across multiple design
    units and files
  • if generate, for generate
  • VHDL 1987 vs. 1993 vs. 2000
  • Test benches
  • time, procedures, variables, file access, etc.

4
The FPGA
  • FPGA stands for Field Programmable Gate Array
  • reprogrammable hardware
  • FPGAs contain
  • Logic Elements (LEs) which do calculations
  • Routing resources between LEs
  • Other specialized functions (memory, multipliers,
    etc.)

5
The FPGA Origins
  • The FPGA is the latest in the family of
    Programmable Logic Devices (PLDs)
  • First came the Programmable Logic Array (PLA) or
    Programmable Array Logic (PAL)
  • implements combinational (non-clocked) logic
    using array of AND and OR gates
  • hundreds to thousands of gates
  • Then, the Complex Programmable Logic Device
    (CPLD)
  • ability to do sequential circuits
  • unlike FPGAs, non-volatile
  • thousands to tens of thousands of gates
  • Field Programmable Gate Array (FPGA)
  • tens of thousands to millions of gates
  • often include other resources besides pure logic

6
FPGA vs. ASIC
  • FPGA
  • reprogrammable
  • cheap in small quantities
  • ASIC
  • mistakes are costly and time consuming to fix
  • cheap in large quantities
  • better power consumption
  • smaller for same functionality

7
FPGA vs. PSoC or SoC
  • System on a Chip (SoC) or System on a
    Programmable Chip (PSoC)
  • Integrates several functional blocks onto one
    silicon wafer
  • Could include
  • Microprocessor
  • RAM, ROM, EEPROM
  • USB interface
  • Ethernet interface
  • Graphics controller
  • DSP
  • etc.

8
FPGA vs. PSoC or SoC
  • SoC is implemented in an ASIC
  • PSoC is implemented in an FPGA
  • Another alternative Structured ASICs
  • Pre-fab ASICs that take a design implemented and
    tested in an FPGA and put it into an ASIC
  • Example Altera HardCopy and HardCopy II
  • http//altera.com/products/devices/hardcopyii/hr2-
    index.jsp
  • Features
  • Power usage and speed characteristics of an ASIC
  • Time from order to production can be as fast as
    several weeks (as opposed to months for an ASIC)
  • Cost savings

9
The FPGA
10
The FPGA
11
The FPGA
12
An FPGA Datasheet
  • Datasheets of any ASIC contain detailed
    specifications and technical data
  • FPGAs are no exception
  • Before you start any design, know the FPGA
    resources
  • size limitations
  • speed limitations
  • number of I/O pins
  • clock pins and resources
  • special features
  • You can never have enough FPGA resources

13
Components of an FPGA
  • Logic Elements (LEs)
  • Routing
  • Input/Output logic
  • Extra features
  • clocking
  • memory
  • memory interfaces
  • multipliers

14
The Logic Element
  • Two main parts
  • Look-Up Table (LUT)
  • Flip Flop (FF)
  • Other characteristics
  • load/clear logic
  • carry chain logic
  • LUT/FF bypass logic
  • clock enable
  • other routing

15
The Logic Element
  • Look-Up Table
  • generally four inputs and one output
  • can implement any four input boolean expression
  • LEs maintain their configuration while power is
    applied to the FPGA
  • need to be re-programmed after power-up or global
    reset, and before using

16
Routing
  • Routing logic connects LEs to
  • other LEs
  • specialized FPGA resources
  • input/output pins
  • Different kinds of routing logic
  • short lines
  • long lines
  • carry chains
  • clock routing

17
How a Design Goes from VHDL to FPGA
  • Synthesis ( compilation)
  • VHDL to intermediate representation
  • Translate
  • intermediate representation mapped to LUTs and
    FFs
  • Map
  • fit translated design into available resources on
    FPGA
  • Place and Route
  • place mapped LUTs and FFs into locations on FPGA
  • determine best routing subject to timing
    constraints
  • Programming
  • generate a bit stream (binary file) which can be
    loaded into the FPGA at programming time

18
How a Design Goes from VHDL to FPGA
  • This entire process is extremely
    non-deterministic
  • much more so than software compilation
  • Terms and steps on previous slide are generic
  • individual FPGA companies have their own terms
    and slightly different design flows

19
Input/Output Logic
  • I/O buffers
  • input
  • output
  • tri-state (output enable)
  • Specialized I/O
  • memory interfaces
  • high speed differential signalling
  • Modern FPGAs can be wired directly (with
    appropriate analog support components) to
  • RAM chips
  • 10/100/1000Base-T Ethernet
  • SD-SDI, HD-SDI drivers (up to 1.5 Gbps)
  • etc.

20
Extra FPGA Features
  • Clock features
  • Phase/Delay Locked Loops (PLLs/DLLs)
  • Special routing resources
  • Memory
  • Block RAM
  • Distributed RAM
  • Memory interfaces
  • SD-RAM, DDR, DDR2, etc.
  • Configuration devices
  • Multipliers

21
Clocks
  • Modern FPGAs feature multiple onboard PLLs that
    can be used for
  • phase/frequency synchronization
  • frequency multiplication
  • arbitrary duty cycles
  • Clock routing logic
  • dedicated clock lines that run to all LEs
  • reduce clock jitter and skew
  • Generally external clocks must be connected to
    one of several special pins to use these features

22
Memory
23
Block RAM
24
Distributed RAM
25
RAM Inference
26
Memory Interfaces
27
FPGA Configuration
  • What happens to an FPGA on power-up?
  • LEs and RAM values are random, or some
    initialization value such as all 0
  • An FPGA must be configured before it can be used
  • Configured by a microprocessor
  • Dedicated configuration device
  • CPLD using a non-volatile Flash RAM device

28
Multipliers
29
Hard- and Soft-Processors
30
Soft Processor ExmpleAltera NIOS-II
31
Hard Processor ExamplePowerPC
32
Interfacing with FPGA Features in VHDL
33
Buses
  • A bus allows multiple entities to communicate
    over the same wires
  • External buses interface between physical ASICs
    or FPGAs
  • Internal buses interface between different
    components within an ASIC or FPGA

34
An Idle Bus
35
Bus Read Cycle
36
Bus Write Cycle
37
External Bus Interfaces
38
Internal Buses
  • Separate read and write buses

39
Buses What Ive Skipped
  • Bus arbitration
  • multiple masters
  • Direct Memory Access (DMA)
  • Bus mastering
  • See the ECE 324 course notes for more on buses

40
Register Files
  • Also called register blocks

41
What Ive Skipped
  • Blocks, Libraries/Packages
  • other modularity features
  • weve had a taste of libraries and packages
  • library ieee
  • Configurations
  • way to select among multiple architectures
  • Constants
  • like generics, but within one file
  • File access
  • useful for test benches, not synthesizable
  • Functions, procedures, variables

42
Preview of Next Tutorial
  • Digital Systems Concepts
  • The FPGA LEs, buffers and routing, other
    resources
  • Bus interfaces
  • Register files
  • Other FPGA resources clocks, memories, memory
    interfaces, multipliers, etc.
  • Soft- and hard-processors in FPGAs

43
Summary
  • Summary of previous tutorial
  • Other signal values besides 0 and 1
  • More VHDL data types
  • Attributes, type definitions
  • Generics
  • Splitting a VHDL project across multiple design
    units and files
  • if generate, for generate
  • VHDL 1987 vs. 1993 vs. 2000
  • Test benches
  • time, procedures, variables, file access, etc.

44
UW ASIC Design Team
  • www.asic.uwaterloo.ca
  • reference material
  • Accolade VHDL reference (excellent!)
  • http//www.acc-eda.com/vhdlref/
  • many of todays examples came from here
  • Bryce Leungs tutorials (UW ASIC website)
  • Mike Goldsmiths tutorials (UW ASIC website)
  • your course notes
  • my contact info
  • Jeff Wentworth, jswentwo_at_engmail.uwaterloo.ca
