Ignition Systems
Or..
How to be a bright spark
2
Magneto Operation
IGNITION SYSTEM
IGNITION SYSTEM
3
Principal -
Volt Meter
Coil Windings
Each time the magnetic field washes through
wires
An electrical current is produced
Called an EMF Electro Motive Force
IGNITION SYSTEM Faraday Law
4
Magneto Operation
EMF produced in the coil windings
The magnetic field passes through soft iron core
IGNITION SYSTEM
IGNITION SYSTEM
5
No EMF produced in the coil windings
No magnetic field in soft iron core
IGNITION SYSTEM
6
EMF produced in the coil windings again
The magnetic field passes through soft iron core
again
IGNITION SYSTEM
7
Magneto Unit
Spark Generation
Power Generation
Coil
Distribution
Magneto
Ignition Switch
IGNITION SYSTEM Magneto System
8
Distributor
Coil
Ignition Switch
Dynamo/ Alternator
Battery
IGNITION SYSTEM Dynamo/Alternator System
9
Typical Distributor
Vacuum Advance
Centrifugal Advance
IGNITION SYSTEM Distributor
10
Engine Speed Sensing Unit
Control Unit
Ignition Switch
Alternator
Battery
IGNITION SYSTEM Electronic Systems
11
IGNITION SYSTEM Spark Plug
12
Change Spark Plugs at specified times
Make sure the correct Spark Plug is fitted
IGNITION SYSTEM Spark Plug
13
