Title: Fused Deposition Modeling


1
Fused Deposition Modeling
2
Definition
  • Fused Deposition Modeling (FDM) is a
    extrusion-based rapid prototyping process, it has
    been used in conjunction with stereolithograghy
    and laser sintering.

3
History
  • FDM was developed by Stratasys, Inc. of Eden
    Prairie, MN in the early 1990s.
  • It was created as a concept modeling device, but
    is now used more for creating casting masters and
    direct use prototyping.

4
History
  • FDM has evolved thru several models beginning
    with the original 3-D modeler which was a floor
    unit. They have progressed thru various desktop
    units.

5
Specs
  • The 1500-2000 models are capable of building
    parts in the 10 x 10 x 10 range where as the
    8000 and Quantum model can build 24 x 20 x 24
    parts.
  • A newly released water soluble support material
    which allows for more complex geometry where
    complicated support structures can now be flushed
    away with a water based solution.

6
Build Materials
  • The FDMs can be equipped to build with
    investment casting wax, acrylonitrile butadiene
    styrene (ABS) plastic, medical grade ABS
    thermoplastic, and or Elastomer.
  • The build and support materials come in filament
    form, about 0.070 in diameter, rolled on spools.
  • The spools mount on a spindle in the rear of the
    machine, and the filament feeds thru a flexible
    tube attached to the back of the extrusion head.
  • New technologies in the ceramics industry involve
    base material research.

7
More About the Filament
  • http//www.emeraldinsight.com

8
More About the Filament
  • A new binder formulation for fused deposition of
    ceramics (FDC) has been developed. This material
    is formulated entirely from commercially
    available constituents, and performs well in FDC
    applications. In addition to adequate FDC
    properties, the binder shows good thermal
    decomposition behavior for binder removal. As a
    result, several complex PZT samples have been
    fabricated using FDC. This formulation shows
    promise for use in conjunction with FDC of
    functional piezoelectric ceramic transducers and
    actuators. Since the exact formulation is known,
    this material should be easily adaptable to other
    fillers such as stainless steel, aluminum oxide,
    or silicon nitride.

9
More About the Filament
  • The quality of the feed filament is one of the
    most important parameters for successful FDC.
  • The critical properties for high quality feed
    filaments include
  • viscosity
  • strength
  • modulus

10
Extrusion Head
  • The extrusion head is the key to FDM technology.
    It consists of
  • Drive Wheels
  • Drive Blocks
  • Heating Chamber
  • Tips
  • Filament

11
Extrusion Headwww.csa.com
12
Click here to view FDM machines at the
www.stratasys.com site.
13
FDM Operation
  • Before building the STL file has to be converted
    into the machine language which is done by the
    Quick-Slice software.
  • The STL file is read into Quick-Slice and is
    displayed graphically on the screen in the
    Cartesian coordinate system.
  • This software allows you to choose slice layer
    thickness, the build and support materials, as
    well as the tip sizes.
  • Then the part must be scaled to fit the bounding
    box size, and oriented at the optimum build
    position.

14
FDM Operation
  • Once the part has been oriented and scaled, it
    must be sliced.
  • The slice range is from 0.005 to 0.015.
  • The rest of the build parameters are default by
    the Quick-Slice software but can be changed
    manually .

15
Typical Uses of FDM Parts
  • Concept/Design Visualization
  • Direct use components
  • Investment casting
  • Medical applications- results show that FDM
    allows the design and fabrication of highly
    reproducible bioresorbable 3D scaffolds with a
    fully interconnected pore network.
  • Flexible components

16
Advantages
  • The strength and temperature capability of the
    build material.
  • Safe laser free operation.
  • Easy post processing with the new water soluble
    support material.

17
Disadvantages
  • Slower than laser based systems
  • Small features like a vertical thin column prove
    difficult to build with FDM.

18
Materials Research
  • Ceramics are the newest thing in fully functional
    working products from a RP perspective.
  • Glass fibers were found to significantly improve
    the strength of an ABS filament at the expense of
    reduced flexibility and handle-ability.
  • The latter two properties of glass fiber
    reinforced ABS filaments were improved by adding
    a small amount of plasticizer and compatibilizer.

19
Hospital Use
  • This new manufacturing device uses a photocurable
    monomer, hardened by a UV-laser. The spatial
    resolution of the system is about 0.1 mm.
    3D-reconstructions were performed on a personal
    computer.

20
Future Applications
  • Three-dimensional honeycomb, which were formed
    via the FD technique, showed excellent
    electromechanical properties for transducer
    applications.
  • Highly efficient ceramics for electrical transfer
    purposes
  • Accurate bio-safe replacement body parts for our
    troops and victims of senseless violence.

21
References
  • Rapid Prototyping Technology by Kenneth G. Cooper
  • http//www.mec.cf.ac.uk/services/?viewfdmstylep
    lain
  • www.csa.com/partners/viewrecord
  • www3.interscience.wiley.com
  • www.blackwell-synergy.com
  • Journal of the American Ceramic Society
    www.emeraldinsight.com
