Title: Common Paediatric Respiratory conditions


1
Common Paediatric Respiratory conditions
  • Corrine Balit

2
Outline
  • Respiratory Distress Signs and Treatment
  • Respiratory Supports
  • High Flow Nasal prong
  • CPAP/ BIPAP
  • Ventilation
  • Bronchiolitis
  • Pertussis
  • Asthma

3
Case 1 6 week old E.L.
  • 6 week old infant presents with severe
    respiratory distress
  • Taken to resuscitation bay on arrival
  • Call from ED doctor asking for help

4
  • Resp
  • RR 90
  • Tracheal tug
  • Intercostal and subcostal recession
  • Grunting
  • Head bobbing, nasal flaring
  • CVS
  • HR 200
  • Cap refill 3 seconds
  • Mottled
  • Neuro
  • Agitated,
  • Unsettled,

5
Respiratory Distress/ Failure
  • One of most common reason ICU will need to review
    a patient
  • Hard to determine which patients will need to
    come to ICU
  • Clinical assessment and reassessment is most
    important
  • May need to start some basic measures and then
    reassess again.

6
Increased work of breathing Malformations of chest wall Evidence of hypoxemia/hypercarbia
Tachypnea Large A diameter (barrel chest) Agitation
Nasal Flaring Narrow AP diameter Confusion
Chest wall retractions Somnolence
Paradoxical breathing Cyanosis
Agitation
Grunting
Accessory muscle use
7
(No Transcript)
8
(No Transcript)
9
Investigations
  • Venous Blood Gas
  • Carbon dioxide and pH
  • Lactate
  • Oximetry
  • Chest x-ray
  • Other investigations to support underlying cause.

10
Who needs to come to ICU
  • Clear cut ones that do and dont
  • In-between that is the hardest.
  • Indications
  • Mod- Severe respiratory distress despite basic
    treatment
  • Recurrent apnoeas
  • Respiratory acidosis (pH lt 7.2)
  • Increasing oxygen requirements
  • Change in mental state
  • Needing airway protection

11
Treatment of Respiratory Failure
  • Administration of supplemental oxygen consider
    humidification
  • Evaluation of airway patency
  • Clear secretions / Airway toileting to maintain
    airway patency
  • Appropriate adjuncts
  • Salbutamol /- ipratropium
  • Steroids if indicated

12
Respiratory Distress
RR lt 60 Mild-Mod Work of breathing Oxygen
requirement lt 2L Not irritable/agitated
RR gt60 Mod-severe work of breathing Increasing
oxygen requirement Irritable/agitated
Basic Measures Nil by mouth Cannula IVF
Humidified oxygen total flow of 2-3L Adjuncts
appropriate to condition e.g. salbutamol,
steroids
13
Mod-Severe Respiratory Distress
IV Cannula
Oxygen humidification
Salbutamol, ipratropium, steroids
  • Indications for ICU
  • Ongoing mod-severe respiratory distress despite
    above
  • Apnoeas
  • Respiratory Acidosis
  • Fatigue

14
Treatment of Respiratory Distress
  • Specific treatment for conditions
  • Non-invasive support
  • High Flow nasal prong oxygen
  • CPAP
  • BIPAP
  • Mechanical ventilation
  • IPPV
  • HFOV
  • ECMO

15
Treatment of Respiratory Distress
  • Fluid Management
  • Generally restricted if receiving ventilatory
    support
  • Two- thirds maintenance
  • Normal saline or Hartmann's as fluid for severe
    resp distress
  • Watch EUC
  • Feeds
  • Feed once stable and improving
  • Can feed while receiving NIV support

16
High Flow Nasal Prong oxygen
  • Delivered via nasal prong and using Fisher and
    Paykel System
  • Rational is two fold
  • High flows provide positive distending pressure
    to the airway improving functional residual
    capacity
  • Use of humidification
  • Humidification improves mucocillary clearance
  • Advantages
  • Tolerated better by children
  • Avoid some of CPAP complication like nasal
    mucosal injury

17
High Flow Nasal Prong oxygen
  • Flow rates currently recommended up to 8L/Min
  • Prospective study in Brisbane where the used flow
    rates between 1 and 8 L/min were used and they
    used electrical impedance tomography and
    oesophageal pressures measured.
  • Found that using 8L/min flow rate delivered on
    average a CPAP effect of 4 cm H20 in infants with
    viral bronchiolitis
  • Definition of High flow nasal prong cannula
  • 1L/kg/min
  • Current cannula for paediatrics up to 8L flow.

18
High Flow- Indications
  • Respiratory distress with hypoxemia
  • Bronchiolitis
  • Pneumonia
  • Post extubation respiratory support
  • Facilitation of weaning from CPAP
  • Post operative respiratory failure

19
High Flow- Contraindications
  • Nasal obstruction
  • Choanal atresia
  • Large polyps
  • Foreign body aspiration
  • Children requiring airway protection
  • Severe life threatening hypoxia (not a
    replacement for intubation

20
Non-Invasive Ventilation
  • CPAP versus bi-level NIV
  • Difficulties is with appropriate size mask
  • Bubble CPAP good for infants (lt10kg)
  • PEEP 5-10cm
  • Contraindications
  • If airway protection is needed
  • Decreased level of consciousness
  • Nasal obstruction

21
Invasive Ventilation
  • Conventional Ventilation
  • High Frequency Ventilation
  • If intubating patient for severe respiratory
    distress suggest always using cuffed tube.
  • Cuff doesnt need to go up but there if you need
    it

22
Bronchiolitis
23
Bronchiolitis- aeitology
  • Respiratory Syncytial Virus
  • Para influenza virus
  • Adenovirus
  • Influenza virus
  • Rhinoviruses
  • Human metapneumovirus

24
Bronchiolitis- Pathology
  • Loss of epithelial cells
  • Cellular infiltration
  • Oedema around airway
  • Plugging of airway with mucus
  • Can get complete and partial plugging of airways
    resulting in localised atelectasis and over
    distention in other areas.
  • Imbalance of ventilation and perfusion leads to
    hypoxemia.

25
Bronchiolitis Clinical Features
  • Coryzal symptoms
  • Wheezing
  • Pneumonia
  • Aponea
  • Hyponatremia
  • Seizures
  • Encephalopathy
  • Myocarditis

26
Investigations
  • NPA
  • Blood Gas
  • CXR
  • Septic workup if severe or very young
  • FBC, EUC

27
Bronchiolitis- Indications for ICU admission
  • Recurrent Apnoea
  • Slow irregular breathing
  • Decreased level of consciousness
  • Shock
  • Exhaustion
  • Hypoxia
  • Respiratory acidosis

28
Bronchiolitis- Management
  • Supportive Care
  • Oxygen
  • Suction
  • Fluids / Feeding
  • Always Nil by mouth if moderate- severe
  • IV fluids 2/3 maintenance if moderate- Severe
  • NG Tube
  • Decompression of stomach
  • Feeds once more stable
  • Infection Control

29
Bronchiolitis Specific Treatments
  • Bronchodilators
  • Surfactant
  • Corticosteroids
  • Ribavirin
  • RSV Immunoglobulin
  • Palivizumab
  • Antibiotics

30
Bronchiolitis Specific Treatments
  • Bronchodilators
  • B- agonists
  • Meta analysis modest short term improvement in
    clinical scores, without changes in oxygen
    saturation, rate of hospitilisation or length of
    hospital stay
  • Adrenaline
  • RCT comparing adrenaline nebulised with placebo
  • No difference in length of hospital stay and no
    short term or long term clinical improvement

31
Bronchiolitis Specific Treatments
  • Corticosteroids
  • Controversial, conflicting studies
  • Cochrane review no benefits in either length of
    stay or clinical course in infants
  • Surfactant
  • Promising as RSV affects endogenous surfactant
    production
  • given to mechanically ventilated infants with RSV
    shortened time on mechanical ventilation,
  • Individual case reports and series.
  • Limited evidence, very expensive

32
Bronchiolitis Specific Treatments
  • Ribavirin
  • Antiviral
  • Inhibits RSV replication
  • Evidence supports aerolised use, IV can be given
  • Early trials showed it to be effective
  • No convincing benefit on clinical outcomes expect
    to patients post BMT with RSV

33
Bronchiolitis Specific Treatments
  • RSV- IG IV
  • No improvement on clinical outcome
  • Palivizumab
  • Monoclonal antibody
  • For prophylaxis for high risk infants
  • Expensive
  • 50 decrease in need for hospitlisation in high
    risk infants

34
Bronchiolitis Specific Treatments
  • Ipratropium bromide
  • Not been demonstrated to be efficacious
  • Heliox
  • Helium-oxygen gas
  • Prospective study looking at 70 helium, 30
    oxygen mixture- improved tachypnoea and
    tachycardia and shorter stay in PICU
  • Nitric oxide
  • Case reports only

35
Bronchiolitis Antibiotics
  • Used for secondary bacterial infection
  • Traditionally risk of secondary infection with
    RSV thought to be low but theses studies based on
    children not admitted to PICU.
  • Recent studies PCCM 2010
  • Secondary pneumonia in patients in PICU with RSV
    reported to be as high as 20-50
  • If child is unwell enough to be admitted to PICU
    with bronchiolitis, cultures should be taken and
    antibiotics started

36
Levin et al PCCM 2010
  • Prospective study looking at patients admitted
    with RSV bronchiolitis with progressive
    respiratory failure
  • Excluded patients who had pre-existing conditions
  • Found 39 had probable pneumonia by tracheal
    aspirate
  • Concluded that due to high rate of possible
    secondary bacterial pneumonia, empirical
    antibiotics for 24-48 hrs pending cultures may be
    justified in those sick enough to come to PICU

37
Bronchiolitis- Ventilation
  • High Flow Nasal Prongs
  • CPAP
  • Mechanical Ventilation
  • IPPV
  • HFOV
  • ECMO

38
My Approach to moderate-severe bronchiolitis
  • Suction and clear airway esp nasal passages
  • Application of oxygen with humidification if
    possible
  • Nil by mouth
  • IV cannula 2/3 maintaince IVF
  • Obtain venous blood gas (BC FBC/EUC at time of
    IVC)
  • Decide on level of respiratory support
  • High flow Nasal prong Cannula to 8L/min (not
    available in ED)
  • Bubble CPAP

39
  • OG or NG if on respiratory support
  • Constant reassessment, looking for
  • Decreasing respiratory rate
  • Decrease in work of breathing
  • Heart rate improving
  • If not responding to above to be intubated and
    ventilated
  • If sick enough with bronchiolitis to need
    ventilatory support I do blood culture and sputum
    culture and cover with antibiotics.
  • Need to monitor Sodium

40
Pertussis
41
Pertussis - Pathology
  • Bordetella Pertussis
  • Toxin damages respiratory epithelium and can
    produce systemic toxicity
  • Severe, Prolonged Coughing
  • Aponea in young infants
  • Whoop- loud stridor on inspiration after a
    paroxysm

42
Pertussis- Severe Complications
  • Pneumonia
  • Pulmonary Hypertension
  • Encephalopathy
  • Seizures
  • Global Myocardial dysfunction

43
Pertussis
  • Mortality highest in
  • Very young infants
  • WCC gt 100 000
  • Presenting with pneumonia
  • Need for circulatory support
  • Indications for ICU
  • Apnoeas
  • Seizure
  • Severe respiratory failure

44
Pertussis - Investigations
  • PCR on NPA
  • CXR
  • WCC
  • ECHO if severe

45
Pertussis- Management
  • Suction
  • Oxygen
  • Respiratory support
  • High flow nasal o2
  • CPAP
  • Ventilation
  • Antimicrobials
  • Azithromycin

46
Pertussis- Other Management
  • If leukocytosis (esp neutrophilia)
  • Exchange transfusions or aphaeresis to remove
    white cells
  • With high white cell count can get leukocyte
    aggregates in pulmonary vessels
  • If Pulmonary Hypertension present
  • Consider inhaled nitric oxide or sildenafil
  • If Severe respiratory failure
  • ECMO
  • Treat contacts

47
PCCM 2007
  • Retrospective study from RCH Melbourne
  • Median age at admission was 6 weeks
  • 94 of patients were unimmunised at time of
    admission
  • Infants presenting with pneumonia had raised
    white cell count
  • 38 needing intubation died
  • All patients who needed ECMO died

48
Asthma
49
Asthma Management
  • Oxygen
  • B-adrenergic agonists
  • Corticosteroids
  • Anticholinergic
  • Magnesium Sulphate
  • Theophylline/ Aminophylline
  • Inhalational anaesthetics

50
Asthma- Management
  • Helium-Oxygen
  • Non-invasive ventilation
  • Ventilation
  • Ketamine
  • Adrenaline

51
B-adrenergic agonists
  • Salbutamol first line bronchodilator of choice
  • MDI with spacer as effective as nebulisation
  • When giving nebulisation, continuous nebulization
    is superior to intermittent doses (Cochrane
    Review 2009)
  • Provides sustained stimulation of B-receptors
  • Promotes progressive bronchodilatation
  • Improves drug delivery in distal airway

52
IV salbutamol
  • Considered in patients unresponsive to treatment
    with continuous nebulisation.
  • RCT in children 2002
  • IV salbutamol as a bolus , atrovent or IV
    salbutamol atrovent
  • In severe asthma, IV salbutamol as a bolus lead
    to more rapid recovery

53
Ipratropium bromide
  • Leads to bronchodilatation by decreasing
    parasympathetic-mediated cholinergic bronchomotor
    tone
  • Cochrane review 2009
  • Adding multiple doses of anticholinergic to B2
    agonists appears safe and improves lung function
  • Would avoid hospital admission in 1 of 12 such
    patients
  • No studies in critically ill children admitted to
    PICU
  • Because safe, considered reasonable to use

54
Magnesium Sulphate
  • Acts as calcium antagonist leading to smooth
    muscle relaxation
  • 5 x RCT looking at IV magnesium in children
  • 4 of these studies showed improvement in
    respiratory function and decrease in hospital
    admissions
  • 1 study showed no significant difference between
    magnesium and placebo group
  • 2 x meta analysis that showed adding magnesium
    provided additional benefit to children

55
Methylxanthines
  • Theophylline and Aminophylline
  • Role is in severe asthma who have failed other
    treatment
  • Meta analysis of RCT in paeds found no benefit in
    mild or moderate asthma
  • RCT in 163 children with status asthmaticus
  • Aminophylline improved oxygen sats and pulmonary
    function
  • No difference in length of stay
Write a Comment
User Comments (0)
About PowerShow.com
