PRO-LOCKTM PVC Double Containment Pipe

1
PRO-LOCKTMPVC Double Containment Pipe

• Asahi/America, Inc.

2
Double Containment Systems
Duo-Pro - PP x PP - PVDF x PVDF, PVDF x PP -
ECTFE x PP
Poly-Flo - PP x PP - HDPE x HDPE
Chemical Pharmaceutical Semiconductor Biotech Wate
r Treatment
Fluid-LoK - PP x PP - HDPE x HDPE
Chemical Pharmaceutical Semiconductor Biotech Chem
Transfer
Pro-Lock - PVC x PVC - CPVC x CPVC - CPVC x PVC
Remmediation Landfill
Water Treatment
3
Pro-Lock ProductPVC Double Containment

• Available ½ x 2 to 4 x 8
• Schedule 40x40, 80x40 and 80x80
• PVC and CPVC
• NSF approved Piping
• IAPMO approved pipe and fittings

4
Pro-Lock Design
Support disk sits on both socket and containment
fitting shoulder
Support Disk locks inner and outer together
5
Target Applications in Water Treatment
6
Installation Method
Staggered joining
Fitting Support Clips Locks into Place
Final joints can be simultaneous
7
Full Pressure Dogbone Fittings
Restraint Dogbone Fitting
Restrains inner Pipe - Anchor
Below Ground
Above Ground
Dogbone terminates DW, continues Single Wall
Flanged End Termination
8
Dogbone Common Applications
Manual Drain Port
Leak/Drain Port
Leak Detection Port
End of Line Leak Port
Compartmentalize the System
9
Accessories for Pro-Lock
10
Thank you for your time

• Asahi/America, Inc.
