Energy efficiency with environmental protection in production

1
GReening business through the Enterprise Europe Network
Linking energy efficiency with environmental
protection in production - good practice Vanja
Strle Ljubljana, 23th of February 2011
European CommissionEnterprise and Industry
2
GReening business through the Enterprise Europe
Network
Energy efficiency
Environmental protection
Use of energy
Use of fuels
Use of energy transferable mediums
Production
3
Enterprise Europe Network
GReening business through the Enterprise Europe
Network
Goals

• BETTER ENVIRONMENT
• LOWER COSTS
• BIGGER BENEFITS

4
Goals
GReening business through the Enterprise Europe Network
Energy efficiency
Environmental protection
Lower costs / Better environment

• lower emissions
• avoiding of penalties
• lower taxes
• lower fees
• better business occasions

• reduced energy use
• reduced use of fuels
• reduced use of energy
• transferable mediums
• - better working utilisation rate

5
GReening business through the Enterprise Europe Network
DETAILED KNOWLEDGE OF THE ENERGIES FLOWS
OPTIMISATION OF THE PRODUCTION PROCESS

• reduced energy use
• reduced use of fuels
• reduced use of energy transferable mediums
• better working utilisation rate
• environmental benefits

6
GReening business through the Enterprise Europe Network

• EXAMPLES / Energy intensive industries
• Production of insulation materials
• Lime industry
• Cement industry

7
GReening business through the Enterprise Europe Network

• EXAMPLES / Energy intensive industries
• Critical points in this industries are industrial
  ovens
• the consumption of the fuel
• the type of the fuel
• the type of the burners
• increasing the heat transfer
• adding the oxygen in the process
• measuring and regulation of the combustion
  process
• fore-heating of the burning air and the oven bed
  material
• isolation
• recuperation of the waste heat
• good maintaining

8
1 - Production of insulation materials
GReening business through the Enterprise Europe
Network

• isolation heat, sound, fire
• big consumption of energy source and energy
• big production of greenhouse gas emission
• important reducing of fuel consumption in
  isolated buildings
• The ratio - the production of greenhouse
  emission
• production of stone wool non-isolated
  buildings, 50 years
• 1 1000

9
Production of insulating materials - stone wool
GReening business through the Enterprise Europe
Network

• Production phases
• raw material preparation
• melting
• fiberisation of the melt
• binder application
• product mat formation
• curing
• cooling
• product finishing

10
Production of insulation materials - stone wool/
melting
GReening business through the Enterprise Europe
Network

• oven the coke hot blast cupola,
• alumino-silicate rock, dolomite, technological
  scrap from stone wool (briquettes to prevent
  flow of dust emissions (oven atmosphere, external
  air), quality of melted material, disturbing of
  the flow blowing into the oven),
• 1700 C,
• reductive conditions,
• warmed air / O2 - blowing into the hot blast
  cupola

11
Production of insulation materials - stone wool/
melting - the energy flow
GReening business through the Enterprise Europe
Network
taken away with cooling
entry- energy
waste energy
taken away with air emissions
melting
possibilities for waste heat use
12
Production of insulation materials - stone wool/
cooling
GReening business through the Enterprise Europe
Network
cooling of the coat of hot blast cupola
waste heat
regulation
heat is used for drive of absorption cooling
system
cooling of other users
room heating
13
Production of insulation materials - stone wool/
air emissions from melting
GReening business through the Enterprise Europe
Network
warmed air / O2 - blowing into the hot blast
cupola
hot waste air emission
waste heat
14
Production of insulation materials - stone wool/
air emissions from melting
GReening business through the Enterprise Europe
Network

• Different emission pollutants - need different
  cleaning approaches
• dust bag filter, electrostatic precipitator,
  stone wool filter,
• inorganic gas parameters like oxides of sulphur,
  oxides of nitrogen are affected by the
  composition of the raw material and the quality
  of the coke, wet scrubber,
• combustible gas parameters as volatile organic
  compounds, hydrogen sulphide, carbon monoxide
  burned in incinerator (thermal oxidation)

15
Production of insulation materials - stone wool/
air emissions from melting - carbon monoxide
GReening business through the Enterprise Europe
Network

• carbon monoxide burned in incinerator it
  has to be achieved
• as much as possible complete burning
• CO ½ O2 CO2

En
using of waste heat for near users
minimizing of CO
less needed fuel for incineration
16
Production of insulation materials - stone wool/
air emissions from melting - carbon monoxide
GReening business through the Enterprise Europe
Network
Cupola furnaces (data from EMEP/CORINAR)
substance air emission mg/ m3 grams / ton of melted material Example for capacity of 20 tons / day
CO 10 100.000 30 300.000 (0,6 kg 6.000 kg)/ day
17
Production of insulation materials - stone wool/
air emissions from melting - carbon monoxide
GReening business through the Enterprise Europe
Network
Coke hot blast cupola
Reactions Energy formation /units
C (coke) ½ O2 CO 1,1
C (coke) O2 CO2 3,9
CO ½ O2 CO2 2,8
Energy consumed (1,7 units)
C (coke) CO2 2 CO
18
Production of insulation materials - stone wool
GReening business through the Enterprise Europe
Network

• Other possible measures to reduce the consumption
  of the fuel and energy and consequently also the
  air emissions - on the local and global level
• monitoring of the used fuel (coke, other fuels)
• monitoring of the concentration of oxygen, carbon
  monoxide and carbon dioxide, which can show the
  efficiency of the burning
• good isolation of the installations with warmed
  air and water
• the process has to run continuously to prevent
  heat oscillations
• working start and stop of the hot blast cupola
  has to be made progressive

19
Production of insulation materials - stone wool
GReening business through the Enterprise Europe
Network

• Other possible measures to reduce the consumption
  of the fuel and energy and consequently also the
  air emissions - on the local and global level -
  saving the electric energy gt minimizing the
  operators costs and the emissions on the global
  level
• high efficiency motors, variable speed drive,
• minimizing of the reactive energy losses that cos
  f between the voltage and the current peaks lies
  permanently between 0,95 0,99,
• minimizing of compressed air demand,
• Introducing a regular leak control program for
  compressed air system,
• using of transporters with minimal rubbing

20
2 - Lime industry
GReening business through the Enterprise Europe
Network

• CaCO3 ? CO2
  CaO
• limestone ? decarbonisation ?
  quicklime

raw material acquisition, preparation
burning in the lime kiln in the range of 800-
1000-1200 -900 /C
quicklime treatment
slaked lime
different granulations
21
Lime industry
GReening business through the Enterprise Europe
Network

• Burning of the limestone in the lime kiln gt to
  use the best combination - the choice of the
  fuel, type of the kiln, position of the burners,
  affects on fuel consumption and emissions, as
  well as on the quality of the product
• gas, liquid fuel, solid fuel, waste fuels
• shaft kilns, rotary kilns, other kilns
• internal burners, external burners, special
  burners for waste fuel, centralized burners etc

22
Lime industry
GReening business through the Enterprise Europe
Network

• Burning of the limestone in the lime kiln gt the
  right granulation of the limestone in the kiln
  makes space between particles and this aids
• better air circulation gt reduction of excess air
  gt saving the fuel gt less air emissions
• better heat exchange between gases and particles
  gt saving the fuel gt less air emissions
• better burning gt saving the fuel gt less air
  emissions
• better thermal oxidation of CO gt less CO
  emissions is produced gt more energy is released

23
Lime industry
GReening business through the Enterprise Europe
Network

• Burning of the limestone in the lime kiln gt the
  previous cleaning of the limestone
• better conditions to make free space in the kiln
  between particles
• less impurities have positive impact on the
  composition of the air emissions
• easier regulation of the excess air, so not too
  much heat escapes with it through the chimney

24
Lime industry
GReening business through the Enterprise Europe
Network

• Burning of the limestone in the lime kiln

fuel, air
preheated air
emissions to air
preheating zone
calcining zone
cooling zone
900C - 1200C
800 C
900C gt 100C
the direction of the limestone flow
25
Lime industry
GReening business through the Enterprise Europe
Network

• Other possible measures to reduce the consumption
  of the fuel and energy in the lime industry and
  consequently also the air emissions
• monitoring of the used fuel
• monitoring of the concentration of oxygen, carbon
  monoxide and carbon dioxide, which can show the
  efficiency of the burning
• monitoring for controlling of good combustion of
  the fuel
• regulation of burners
• good isolation of lime kiln and installations
  with hot air
• the process has to run continuously to prevent
  heat oscillations
• working start and stop of the lime kiln has to be
  made progressive

26
Lime industry
GReening business through the Enterprise Europe
Network

• Other possible measures to reduce the consumption
  of the fuel and energy in the lime industry and
  consequently also the air emissions
• saving the electric energy (high efficiency
  motors, variable speed drivers, minimising of the
  reactive energy losses that cos f between the
  voltage and the current peaks lies permanently
  between 0,95 0,99, minimising of compressed air
  demand etc.) gt minimising of the emissions on
  the global level
• use of waste hot air coming from preheating zone
  of lime kiln for the drying

27
Lime industry
GReening business through the Enterprise Europe
Network

• Use of waste hot air from preheating zone of lime
  kiln for the drying

emissions to air
cleaning-2
fuel, air
preheated air
DRYING, cleaning-1
production of the sand
preheating zone
calcining zone
cooling zone
900C - 1200C
800 C
900C gt 100C
the direction of the limestone flow
washed / wet sand
28

GReening business through the Enterprise Europe
Network
3 - Cement industry

• Basic steps

calcination
clinkering process
raw material acquisition, preparation
cooling of clinker
grinding of clinker, gypsum and additives
cement
29
Cement industry burning
GReening business through the Enterprise Europe
Network
1. step
CaCO3 ? CO2 CaO
limestone ? calcination
quicklime
800 - 900C
2. step
CaO (Silica, Al2O3, Fe2O3) ?
Ca-aluminates,
Ca-ferrites,
Ca-silicates clinkering process
clinker
1400C - 1500C
30
Cement industry fuels for the burning
GReening business through the Enterprise Europe
Network

• Fuels used in rotary kiln for the clinker
  burning
• solid fuels e.g. coal, petcoke
• liquid fuels e.g. fuel oil
• gaseous fuels e.g. natural gas
• wastes e.g. used tyres, waste oils, plastics
  etc. / the high temperatures and long residence
  times in the kiln system implies considerable
  potential for the destruction of organic
  substances

31
Cement industry fuels for the burning
GReening business through the Enterprise Europe
Network

• the cost for the fuel
• using of natural fuel resources
• problems to achieve the reducing of CO2

fossil fuel

• the profit for the waste removal
• saving the natural fuel resources
• less CO2 produced

wastes
32

GReening business through the Enterprise Europe
Network
Cement industry wastes as a fuel for the burning
process

• Additional advantages for using waste as a fuel
  comparison with the waste incineration
• - in the rotary kiln are better conditions
  as in the waste incineration / gas retention
  times of about 8 seconds at temperatures above
  1200C in the rotary kiln
• (waste incineration minimum 2 seconds at
  temperatures gt 850C or minimum 2 seconds at
  temperatures 1100C for halogens)
• maximum temperatures achieved in the rotary kiln
  2000 C
• oxidising gas atmosphere in the rotary kiln
• uniform burnout conditions in the rotary kiln

33

GReening business through the Enterprise Europe
Network
Cement industry wastes as a fuel for the burning
process

• Aditional advantages for using waste as a fuel
  comparison with the waste incineration
• destruction of organic substances due to the high
  temperatures at sufficiently long retention time
• sorption of gaseous components (e.g. HF, HCl,
  SO2) on alkaline reactants
• short retention time of exhaust gases in the
  temperature range in which PCDD/F can arise
• chemical-minerological incorporation of the heavy
  metals into the clinker
• complete utilisation of the ashe as a clinker
  component

34

GReening business through the Enterprise Europe
Network
Cement industry wastes as a fuel for the burning
process

• Final conclusions about using waste as a fuel in
  the burning process in cement industry
• saving the natural fuel resources (less fuel
  used)
• less CO2 emissions
• controlled removal of the waste
• better environmental conditions for waste removal
  as in the waste incineration (less problematic
  air emissions) of course cleaning device for air
  emissions has to be used as in waste incineration
• complete utilisation of the ash of the burned
  waste, as a clinker component

35

GReening business through the Enterprise Europe Network

Thanks for your attention!
