Histology of Nervous Tissue

1
Histology of Nervous Tissue

• PROF. DR. FAUZIAH OTHMAN
• DEPT OF HUMAN ANATOMY

2

• Feature of nerves tissue
• Type of cell neuron neuroglia
• General feature of neuron
• Type of neuroglia astrocyte, oligodendrocyte,
  ependymal cell, microglia
• Synapses
• Myelin formation function
• General structure of peripheral nerves
• Ganglia dorsal root ganglia
• autonomic ganglia

3

• Nervous system divided into
• Central nervous system (CNS)
• Brain and spinal cord
• Peripheral nervous system (PNS)
• Cranial and spinal nerves locate outside the
  CNS.

4
Morphology of typical neuron

• Neuron functional cell of the nervous tissue.
• Cell body or perikaryon - contains the nucleus
  regulates the functioning of the neuron.
• Numerous dendrites and a single axon.
• Contains Nissl bodies in the cytoplasm
• Axon hillock- no Nissl bodies
• Axon cellular process (extension) carries
  impulses away from the cell body.
• Dendrites cellular process (extension)
  carries impulses toward the cell body

5
(No Transcript)
6

• 2 types of cell
• i) Neurons (nerve cells)
• ii) Supporting cells
• Functions of neurons
• specialized to receive stimuli and to conduct
  electrical impulses to other parts of the system.
• Arranged as an integrated communications network,
  with several neurons in a chain-like fashion
  involved in sending impulses from one part of the
  system to another.

7
Neuron Classification

• Structural
• Multipolar most common type in CNS.
• Include all motor neurons and interneurons of
  brain and spinal cord.
• Bipolar- not as common purely sensory.
• Retina of eye, inner ear, olfactory epithelium in
  the upper region of nose.
• Unipolar (formerly known as pseudounipolar)
• Sensory neurons found in numerous craniosacral
  ganglia of the spinal cord.

8
Comparison of Structural Classes of Neurons
9
Comparison of Structural Classes of Neurons
10
Comparison of Structural Classes of Neurons
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
The supporting cells (neuroglia or glia)

• Astrocytes
• Oligodendrocytes
• Microglial cells
• Ependymal cells
• Schwann cells
• Satellite cells

CNS
PNS
21
Astrocytes

• Largest, most numerous, versatile, and highly
  branched glial cells
• They cling to neurons and cover capillaries
• Functionally, they
• Support and brace neurons
• Anchor neurons to their nutrient supplies
• Guide migration of young neurons
• Control the chemical environment

22
Astrocytes
23
Microglia

• Microglia smallest, ovoid cells with spiny
  processes
• - phagocytic cells that migrate through the CNS
  and remove foreign and degenerated material

24
Ependymal Cells

• Ependymal cells squamous- to columnar-shaped
  cells
• They line the central cavities of the brain and
  spinal column

25
Oligodendrocytes

• Oligodendrocytes branched cells that wrap CNS
  nerve fibers
• - Produce myelin in CNS

26
Schwann Cells and Satellite Cells

• Schwann cells (neurolemmocytes) form myelin
  sheaths around peripheral axons
• Satellite cells surround neuron cell bodies with
  ganglia

27
(No Transcript)
28
Synapse

• The region where the terminals come close to
  another cell and transmit the impulse

• A junction that mediates information transfer
  from one neuron
• To another neuron
• To an effector cell
• Presynaptic neuron conducts impulses toward the
  synapse
• Postsynaptic neuron transmits impulses away
  from the synapse

29

30
(No Transcript)
31
(No Transcript)
32
Myelin formation function

• Whitish, fatty (protein-lipid), segmented sheath
  around most long axons
• Its function
• Protection of the axon
• Electrically insulating fibers from one another
• Increasing the speed of nerve impulse
  transmission

33
2 types of neuroglia produce myelin

• CNS Oligodendrocyte
• PNS Schwann cells

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
