Vertigo Its Management By Dr.H.T.Lathadevi

M.S(ENT) Shree B.M.Patil Medical College
Hospital Research Centre Bijapur
2
What is Vertigo

• Giddiness /dizziness
• Light headedness.
• Sensation of floating in space.
• Unstable or uncertain gait.
• Loss of balance
• Ringing in the ears.

3
Vertigo

• Vertigo is a hallucination of self or
  environmental movement , a feeling of spinning
• Vertigo is a symptom and not a disease.

4
Body Balance System

• Maintenance of balance is a function of nervous
  system
• Balance is achieved by integrating information
  from 3 sources
• Vestibular labyrinth
• Eyes
• Proprioceptors located in muscles and joint
• Harmonious integration of these inputs in the
  brain is essential for maintenance of balance

5
Disorder of Balance System

• Disorder may occur in one or more organs of the
  balance system
• Commonest site is labyrinth
• Labyrinth is susceptible to damage by numerous
  factors -
• Medicines ( e.g.gentamycin,streptomycin )
• Infections
• Degenerative changes of aging
• Head trauma

6
Vertigo - Prevalence

• Present in about 5 of all patients consulting
  general practitioners
• Seen in 10-15 of patients seen by ENT
  specialist or neurologist
• The reasons for high prevalence
• -Vertigo is a symptoms which accompanies
  large number of diseases
• -More than 80 possible causes have
  been described

7
Vertigo- symptoms

• Giddiness /dizziness
• Light headedness.
• Sensation of floating in space.
• Unstable or uncertain gait.
• Loss of balance
• Ringing in the ears.

8
Vestibular System
9
Vestibular Function and Anatomy
10

• System of balance
• Membranous and bony labyrinth embedded in petrous
  bone
• 5 distinct end organs
• 3 semicircular canals superior, lateral,
  posterior
• 2 otolith organs utricle and saccule

11

• Semicircular canals are orthogonal to each other
• Lateral canal inclined to 30 degrees
• Superior/postereor canals 45 degrees off of
  sagittal plane

12

• Utricle is in horizontal plane
• Saccule is in vertical plane

13
Anatomy
14

• There are five openings into area of utricle
• Saccule in spherical recess
• Utricle in elliptical recess

15

• 45 from AICA
• 24 superior cerebellar artery
• 16 basilar
• Two divisions anterior vestibular and common
  cochlear artery

16

• Superior vestibular nerve superior canal,
  lateral canal, utricle
• Inferior vestibular nerve posterior canal and
  saccule

17

• Membranous labyrinth is surrounded by perilymph
• Endolymph fills the vestibular end organs along
  with the cochlea

18

• Perilymph
• Similar to extracellular fluid
• K10mEQ, Na140mEq/L
• Unclear whether this is ultrafiltrate of CSF or
  blood
• Drains via venules and middle ear mucosa

19

• Endolymph
• Similar to intracellular fluid
• K144mEq/L, Na5mEq/L
• Produced by marginal cells in stria vascularis
  from perilymph at the cochlea and from dark cells
  in the cristae and maculae
• Absorbed in endolymphatic sac which connected by
  endolymphatic, utricular and saccular ducts

20
Sensory structures

• Ampulla of the semicircular canals
• Dilated end of canal
• Contains sensory neuroepithelium, cupula,
  supporting cells

21

• Cupula is gelatinous mass extending across at
  right angle
• Extends completely across, not responsive to
  gravity
• Crista ampullaris is made up of sensory hair
  cells and supporting cells

22

• Sensory cells are either Type I or Type II
• Type I cells are flask shaped and have chalice
  shaped calyx ending
• One chalice may synapse with 2-4 Type I cells
• Type II cells cylinder shaped, multiple
  efferent and afferent boutons

23
Hair cells have 50-100 stereocilia and a single
kinocilium.
24
stereocilia are not true cilia, they are graded
in height with tallest nearest the kinocilium.
25

• Kinocilium is located on one end of cell giving
  each cell a polarity
• Has 92 arrangement of microtubule doublets
• Lacks inner dynein arms, and central portion of
  microtubules not present near ends may mean
  they are immobile or weakly mobile

26

• Each afferent neuron has a baseline firing rate
• Deflection of stereocilia toward kinocilium
  results in an increase in the firing rate of the
  afferent neuron
• Deflection away causes a decrease in the firing
  rate

27
(No Transcript)
28
(No Transcript)
29

• kinocilia are located closest to utricle in
  lateral canals and are on canalicular side in
  other canals
• Ampullopetal flow (toward the ampulla) excitatory
  in lateral canals, inhibitory in
  superior/posterior canals
• Ampullofugal flow (away from the ampulla) has
  opposite effect

30

• Semicircular canals are paired
• Horizontal canals
• Right superior/left posterior
• Left superior/right posterior
• Allow redundant reception of movement
• Explains compensation after unilateral vestibular
  loss

31
Otolithic organs

• Utricle and saccule sense linear acceleration
• Cilia from hair cells are embedded in gelatinous
  layer
• Otoliths or otoconia are on upper surface

32
(No Transcript)
33

• Calcium carbonate or calcite
• 0.5-30um
• Specific gravity of otolithic membrane is
  2.71-2.94
• Central region of otolithic membrane is called
  the striola

34

• Saccule has hair cells oriented away from the
  striola
• Utricle has hair cells oriented towards the
  striola
• Striola is curved so otolithic organs are
  sensitive to linear motion in multiple
  trajectories

35
(No Transcript)
36
Central connections

• Scarpas ganglion is in the internal auditory
  canal
• Contains bipolar ganglion cells of first order
  neurons
• Superior and inferior divisions form common
  bundle which enters brainstem
• No primary vestibular afferents cross the midline

37

• Afferent fibers terminate in the vestibular
  nuclei in floor of fourth ventricle
• Superior vestibular nucleus
• Lateral vestibular nucleus
• Medial vestibular nucleus
• Descending vestibular nucleus

38

• Vestibular nuclei project to
• Cerebellum
• Extraocular nuclei
• Spinal cord
• Contralateral vestibular nuclei

39

• Senses and controls motion
• Information is combined with that from visual
  system and proprioceptive system
• Maintains balance and compensates for effects of
  head motion

40

• Vestibulo-ocular reflex
• Membranous labyrinth moves with head motion to
  right
• Endolymph moves utriculopetally
• Cupula on right canal deflected towards utricle
  causing increase in firing rate, left deflects
  away causing a decrease in firing rate.
• Reflex causes movement of eyes to the left with
  saccades to right
• Stabilizes visual image

41

• If acceleration stops, and spin to right is at
  constant velocity, sensation of motion stops
  after 14-20 seconds as does nystagmus
• Cupula only takes 8-10 seconds to return to
  equilibrium position
• Vestibular integrator is the term for the
  prolongation and is mediated by the vestibular
  nuclei and cerebellum

42
Vestibulospinal Reflex

• Senses head movement and head relative to gravity
• Projects to antigravity muscles via 3 major
  pathways
• Lateral vestibulospinal tract
• Medial vestibulospinal tract
• Reticulospinal tract

43
How do calorics work?

• Patient is lying down with horizontal canals
  oriented vertically (ampulla up)
• Cold water irrigation causes endolymph in lateral
  portion to become dense and fall causing
  deflection of cupula away from utricle with a
  decrease in the firing rate
• This causes nystagmus with fast phase (beat) away
  from the stimulus

44

• With warm water irrigation column of endolymph
  becomes less dense, rises and causes deflection
  of cupula toward the utricle
• Results in increase firing rate and nystagmus
  which beats towards the stimulation
• COWS (cold opposite, warm same)

45
Investigations for vertigo

• Caloric Test
• Audiometry
• Electronystagmography (ENG)
• Craniocorpography (CCG)
• Brain -Stem Evoked Response Audiometry (BERA)

46
NYSTAGMUS
Pendular Or Phasic Spontaneous Or Induced Horizont
al Or Vertical
47
Electronystagmography (ENG)

• Basic test for balance system
• Assesses the integrity of
• - vestibular labyrinth its connections with
  the eyes and certain parts of the brain which
  are concerned with the maintenance of balance
• Gives an idea of functional integrity of
  vestibulo-ocular reflex system
• It comprises tests like test for spontaneous
  nystagmus, the gaze nystagmus, pendulum tracking
  test caloric test

48
Caloric Test

• Caloric test involves instillation of hot or cold
  water into ear canal
• When labyrinth is stimulated, either by heat or
  cold, caloric nystagmus generally results
• Nystagmus produced by left right eyes are
  assessed

49
Brain Stem Evoked Response Audiometry (BERA)

• A method of plotting electrical activities in
  response auditory or vestibular stimuli
• Electrical activities are measured by keeping the
  electrode on the scalp
• In BERA wave-form obtained from one particular
  site on the scalp (vertex), over specified
  duration of time of 10 milliseconds

50
Investigations - for structural integrity

• Tests to asses structural integrity of the system
• X rays
• CT scan
• MRI
• Newer imaging ethnologies - for visualization of
  functional or metabolic activity occurring in
  brain
• Positron emission tomography (PET)
• Single photon emission computed tomography (SPECT)

51
(No Transcript)
52
Vertigo - Possible circulatory causes

• Increased vascular resistance
• Increased blood viscosity due to -
• Reduced flexibility of RBCs
• Increased blood viscosity
• Reduced micro-circulation

53
Vertigo Peripheral V/S Central

• PERIPHERAL
  CENTRAL
• Occurrence Episodic . May
  be constant
• Severity Proportionate .
  Disproportionate .
• Axis Horizontal .
  Variable O
• Nyst. Type Slow Fast .
  Irregular phases

• Latency 10 to 20 sec. . None
• Direction Single .
  Changing
• Duration Brief .
  Long
• Fatigue Yes .
  No
• Hearing loss
• /Tinitus Possible .
  No

54
ANATOMY OF BALANCE AND VERTIGO
55
Menieres syndrome

• Sudden onset recurring episodes of vertigo
• Tinnitus
• Progressive deafness.
• Ischaemia of the inner ear.
• The cause is unknown - may be associated with
  dilation of the endolymphatic system due to
  increase in the amount of endolymph.

56
Meniere's Disease
57
Clinical Features

• Deafness
• Tinnitus
• Episodic vertigo
• Autonomic Nausea, vomiting, Diaphoresis
• Aural pressure

58
Managrment

• Medical-Vestibular sedatives
• Vascular-Increase blood
  supply-Betahistine
•
  Carbogen
• Alter electrolytic
  balance-Frusemide,Glycerol
•
  Hydrochlorothiadize
• Surgical-Endolymphatic sac decompression,
• Vestibular neurectomy, Ultrasonic destruction
• Reassurance
• Vestibular rehabilitation exercises

59
Benign Paroxysmal Positional Vertigo

• BPPV results from freely moving crystals of
  calcium carbonate (Otoconia) usually within the
  semicircular canals
• BPPV develop with change in position
• This type of vertigo can be sequelae of head
  trauma or vestibular neuritis
• Most common in age group of 60-70 years

60
BPPV
61
DIX-HALL-PIKES TEST
62
EPLEYS MANEUVER
63
General management of vertigo

• Management of patients suffering from vertigo or
  vertiginous syndrome should consist of.
• Elimination of the underlying cause
• Symptomatic relief.
• Methods
• Drug treatment
• Vestibular rehabilitation exercises
• Surgical

64
Drug treatment

• Labyrinthine suppressant/ Ca entry blocker
• Cinnarizine
• Vasodilators
• Betahistine
• Antihistaminics
• Meclizine, Promethazine
• Sedatives / tranquilizers
• Diazepam

65
Cinnarizine

• Selective Antivasoconstrictant, Ca entry
  blocker
• Antivertiginous activity due to
• Suppressant action on vestibular labyrinth.
• Anti-vasoconstrictant activity.
• Lowering of blood viscosity by improving the
  flexibility of the RBCs.

66
Cinnarizine

• Presentation Tablet of 25 mg / 75 mg
• Dosage
• 1-2 tablets of 25 mg two to three times a day or
  as directed by the physician.
• Children (5 - 12 yr.) 1/2 tablet three times a
  day

67
Betahistine

• Histamine analogue.
• Vasodilator-increases blood flow
• Indicated for vertigo.
• Side effects headache, rash, g.i. disturbances.
• Steal effect
• Contraindicated in asthma, peptic ulcer
• Dose 8 to16 mg. tid

68
Vestibular Rehabilitation Exercises

• Co-ordinated head, body eye movement helps to
  ameliorate the patients symptoms
• Exercises should be performed 5 - 10 minutes
  twice or thrice daily.
• Exercises of eye movement
• Exercises in sitting position like
• Shrugging rotating shoulders
• Bending forward picking up the objects from the
  floor
• Exercises in standing position like
• Changing from sitting to standing initially with
  eyes open then with eyes shut repeatedly for 15
  times

69
Vestibular Rehabilitation Exercises (contd.)
70
Vestibular Rehabilitation Exercises (contd.)
71
(No Transcript)
72
ANATOMY OF BALANCE AND VERTIGO
