Industrial Air Pollution Control

1
Industrial Air Pollution Control

• Sell, N.J. (1992) Industrial Pollution Control.
  2nd Edition. Van Nostrand Reinhold, New York

2
Methods used to control air pollutants

• Destroys
• Masks
• Counteracts
• Traps

3
Air pollution control equipment used depends upon

• Size
• Shape
• Density
• Stickiness
• Electrical properties
• Temp., Moisture content, quantity, economic
  factors

4
Physical Principles for particulate collection

• Gravity settling
• Inertial forces
• Filtration
• Electrostatic attraction
• Particle enlarging

In general, the simpler, less energy-intensive
devices are less efficient, making them suitable
mainly for large, dense particulates. Finer
particulate and other types of air pollutants
require the more sophisticated collection
devices.
5
Dry Mechanical Collectors

• Gravity Settling Chambers particles between
  40-100 µm

6
Dry Mechanical Collectors (cont.)

• Recirculating Baffle Collectors particles
  between 10-50 µm

7
Dry Mechanical Collectors (cont.)

• Cyclones Best for 15-50 µm particles. More
  efficient with heavier loads due to the increased
  interparticle interactions.

8

• Cyclone efficiency can be calculated using cut
  diameter, dc particle diameter at which 50
  are removed

9
Dry Mechanical Collectors (cont.)

• Multiple Cyclones

10
Dry Mechanical Collectors (cont.)

• Dynamic Precipitators operated on the
  centrifugal force. Unsuitable for sticky or
  fibrous materials. Remove 5-20 µm

11
Dry Mechanical Collectors (cont.)

• Fabric Collectors lt0.5 µm particles can be
  removed thanks to the filter cake

• The fabric must be cleaned Intermittently,
  Periodically, or Continuously
• Various materials can be used to construct the
  fabric, but polyesters are the most widely used
  as they can tolerate high temperature and
  abrasion resistance

12
Manual or powered shaking
13
Air jet
14
Blow ring
15
Wet Scrubbers
Pros
Cons

• Use a stream of water to increase the collection
  efficiency
• No limit for inlet air stream temperature and
  moisture content
• Other liquid than water can be used, which could
  neutralise the corrosive air pollutants, e.g. SO2


• High operating cost, especially for the
  high-efficiency systems
• Required treatment of the scrubbing liquids and
  disposal of the wet sludge
• Corrosion of structure
• The presence of a highly visible white plume,
  cause by steam discharged to the atmosphere

16
(No Transcript)
17
Low-energy Types Wet Scrubbers

• Spray Chambers

18
Low-energy Types Wet Scrubbers (cont.)

• Spray Towers

• Open Spray Tower
• Best for coarse particulates (gt10 ?m), e.g. in
  the iron pyrite roasting step of steel production
• Good for heavy particulate loads

• Packed Spray Tower
• Suitable for gas cooling and absorption, e.g. for
  fluorine compounds
• Has little solids-handling capacity, and hence is
  not suitable for heavy dust loads

19
High-energy Types Wet Scrubbers

• Venturi Scrubbers

• Very efficient (gt99 removal of 0.5 ?m particles)
• Typically used in the steel industry for fine
  particulates, for acid mists, and for lime and
  coal dust
• High operating cost

20
(No Transcript)
21
Electrostatic Precipitators

• Can operate at over 1000?F
• Can be used for dry particulates or fumes, and
  well as mists
• The dirty gas is channelled between a
  high-voltage electrode (-40,000 V and -50,000 V)
  and a grounded collecting electrode
• Efficiency (?) is estimated by
• 99.9 efficiency, good for hot, corrosive
  substances

22
(No Transcript)
23
Electrostatic Precipitators (cont.)

• Dust resistivity is also a limiting factor
• The resistivity of dust such as that generated by
  low-sulfur coal can be reduced by adding
  substances, e.g. moisture, ammonia, acid mists,
  and SO3

24
Fume Incineration

• HCN is an extremely poisonous, colourless gas,
  used in the production of, e.g. nylon
• Incineration will destroy the toxicity, producing
  a non-toxic product, i.e. CO2, N2, and H2O
• Moreover, incineration is also suitable for
  destroying of paint solvents and odours

25
Sorption Techniques
Adsorption
Absorption

• Employs materials, e.g. activated carbon, silica
  gel, or alumina
• Used for VOC removal, sulfur-bearing materials
  and mercury
• Efficiency increases with molecular weight of the
  material adsorbed, degree of cyclisation, polarity

• Utilises water or an organic liquid, e.g.
  low-volatile hydrocarbon or mineral oil
• Occurs whenever the conc. of the organic species
  in the liquid is less than the equilibrium conc.
• Can be used in conjunction with spray chambers,
  packed towers, and venturi scrubbers
• Maximum absorption occurs at low temp., large
  contacting surface area, high liquid-to-gas
  ratio, and conc. Streams
• Inlet conc. 5000 mg/l, gt98 removal can be
  achieved

26
Tall Stacks

• To diffuse the pollutants, e.g. SO2, CO2, NOx,
  not to reduce the quantity
• Tendency in causing the acid rain problems
• A rule of thumb the stacks should be 2.5 times
  the height of the tallest nearby building
• The air masses at 100 m have been reported to be
  more stable than had been assumed!!!!
