CCI through Firewall r11

1
CCI through Firewallr11

2
Objectives

• CCI Considerations for NSM r11 deployment in DMZ
• Review different deployment options
• Review potential Risks , primarily Denial of
  Service (DOS) attacks

3
DoS

• Any software deployed in DMZ requires protection
  against malicious access or denial of service
  attacks. This requires review of security
  solutions to prevent these attacks which is out
  of scope of this presentation

4
Agenda

• CCI Introduction
• CCI Layers
• DoS
• Different Deployment Options

5
The need for CCI

• Applications, such as Job Management Agent, Event
  Management, etc., need to communicate with one
  another across various servers and platforms.

6
The need for CCI

• Allows applications on various platforms to
  communicate with applications on any other using
  the mechanism of CCI.

7
CCI is available on...

• UNIX
• NT
• AS/400
• OpenVMS
• Tandem
• OS/390

8
What CCI does.

• Allows applications to communicate with one
  another without considering IPC / network
  programming issues.
• Presents set of APIs that allow programmers to
  focus on what an application needs to do and
  forget about IPC / network programming issues.

9
CCI Layers

• QUES Layer introduced the ability to connect at
  send time.
• RMT Layer connects at CCI start up time.
• RMT has auto-connect capability
• Auto-connect capability can be disabled with
  configuration setting

10
QUES Layer

• Eliminates need for configuration files
• New hosts may be brought into configuration with
  less effort
• Removal of host from configuration does not
  affect other hosts
• Connections between hosts are short lived
• Bi-Directional CCI Initialization

11
QUES Layer

• Requires 7001 port to be unblocked bi-directional
• CCI Initialization from DMZ and Private Network
• Potential risk for Denial of Service Attacks
• Syn Flooding
• Etc
• Port must be unblocked for the designated NSM
  servers and not for all hosts
• No predefined source port

12
QUES Layer

• Transport mechanism
• Connects with SYN Flag
• Send Data
• Disconnect
• No persistent connection

13
RMT Layer

• Persistent Connection
• Connection established at start up and remains
  open for duration of CCI
• Preferred option in Firewall deployment
• New hosts may be brought in with Auto Connect
  Feature

14
RMT Layer

• Port Usage
• Source Port can be configured by environment
  settings
• Destination port defaults to 1721 but can be
  configured

15
Syn Three-way Handshaking
SYN
SYN/ACK
ACK
16
How SYN Flooding Works

• A TCP connection request (SYN) is sent to the
  target computer. The source IP address in the
  packet can be "spoofed," or replaced with an
  address that is not in use on the Internet, or
  that belongs to another computer. An attacker may
  send many of these TCP SYNs to tie up as many
  resources as possible on the target computer to
  exhaust the resources
• Upon receiving the connection request, the target
  computer allocates resources to handle and track
  the new connection, then responds with a
  "SYN-ACK". In this case, the response is sent to
  the "spoofed" non- existent IP address.
• No response is received to the SYN-ACK. A
  default-configured Windows NT 4.0 computer will
  retransmit the SYN-ACK 5 times, doubling the
  time-out value after each retransmission. The
  initial time-out value is three seconds, so
  retries are attempted at 3, 6, 12, 24, and 48
  seconds. After the last retransmission, 96
  seconds are allowed to pass before the computer
  gives up on receiving a response, and deallocates
  the resources that were set aside earlier for the
  connection. This can be configured using registry
  changes

BLOCK 7001 port except for designated NSM servers
17
Firewall SYN Flood

• Review Firewall solution to prevent Syn Flood
  attacks or DoS
• Ensure, 7001 is only unblocked for the two NSM
  servers which requires CCI Connectivity

18
CCI Ports Windows

• Transporter
• Quenetd
• TCP destination port 7001 for Windows to Windows
  communication
• CCI will attempt TCP connection first
• If fails, will then attempt, RMT daemon on 1721

19
CCI

• Transporter Service - QUES Layer
• TCP 7001
• Verify Transport Protocols settings to TCP to
  avoid attempts to open 7003 or 7004
• Transport Protocol defaults to TCP

20
Firewall Setup
Secured
DMZ
21
Testing Environment
22
Deployment Options
23

Scenario 1

• We want to forward Event exception messages from
  DMZ without installing the Ingres Client in the
  DMZ environment
• How can we configure this?

24
Deployment - Scenario 1

• Install Event Agent
• Set Event Agent Proxy Node to NSM server inside
  the firewall
• Open up CCI 7001 port bi-directional.

25
DMZ Event DSB

• Event Agent Proxy Node
• Specify the node name of Central Server Event
  Manager
• DSB refreshed from Central Server

26
DMZ Event DSB

• If proxy node not required, then local dsb can be
  pushed to DMZ by other means

27
Windows -gt Windows
Secured Zone
TCP 7001
FIREWALL
TCP 7001
DMZ
7001 Unblocked both directions CCI may be
initiated from DMZ
28

Scenario 2

• We want to open CCI port for outbound traffic
  only and prevent CCI initialization from taking
  place in the DMZ
• How can we configure this?

29
Scenario 2

• RMT daemon provides persistent connection
• Customize ccirmtd.rc to start up connection from
  secured network
• Add the Windows servers to RMTHOSTNAME entries

30
Windows Windows RemoteRMTHOSTS
Secured Node
DMZ
Add Windows node to RMTHOSTS settings for DMZ and
secured servers
31
Windows Windows RemoteRMTHOSTS

• Update RMTHOSTS on both Windows nodes.
• If only one node is updated, the other Windows
  node will use the QUES layer. For example
• RMTHOSTS entry on DMZ node not updated to use RMT
  layer for secured zone node
• Secured server RMTHOSTS entry updated to use RMT
  layer for DMZ node.
• All requests from secured to DMZ will use RMT.
• Events from DMZ to secured will use QUES layer.
  This port would be blocked. It will then attempt
  to use RMT port.

32
ccirmtd.rc location

• ccirmtd.rc must reside in ca_appsw directory -
  NOT caiuser directory (as in previous releases)

33
Windows Windows RemoteSecured ccirmtd.rc
Add Windows node to ccirmtd.rc to prevent
potential first autoConnect attempt failure. The
CCIRMTD.rc in the secured network must be updated
to startup RMT connection
34
Windows Windows RemoteDMZ ccirmtd.rc

• CCIRMTD.rc file on the DMZ must have entry with
  nostart and retry0 (no retry).
• This prevents CCI initialization from DMZ
  environment

35
Windows Windows RemoteSource Port

• To pre-define source port for RMT connection, add
  environment variable CAI_CCI_PORT1

36
Source Port
37
Inbound CAM port Blocked
38
CAM Inbound
CAM inbound traffic denied if CAM not initiated
from secured zone
39
Windows -gt Windows Remote
Secured Network
MDB

FIREWALL
TCP 1721
7001 Blocked - Persistent Connection and traffic
initiated from Private network
DMZ
40
DMZ -gt Secured
41

Deployment - Scenario 3

• Client would like to use QUES Layer but wish to
  block 7001 port from DMZ to private network.
• What are the implications?

42
DMZ -gt Secured

• Execute cawto in DMZ environment to send message
  to Private network
• Cawto ltsecuredgt Sending message from DMZ to
  Private
• Message will be denied by Firewall
• Exception messages cannot be forwarded from DMZ
  to secured network

43
DMZ -gt Private with 7001 Blocked
44
Summary

• For Windows Windows, use Ques Layer with 7001
  unblocked for the selected NSM servers only. CCI
  Initialization from DMZ and Secured environment
• For Windows Windows , configure RMT layer to
  avoid by-directional unblocking of ports
• For Windows gt Unix or UNIX -gt Windows (including
  Linux) , RMT layer provides persistent connection

45
Questions and Answers
Any questions?
