Memory/Cache Optimization
  • Lochana Narayanan Suchitra Chandran

3
A Distributed BIST Control Scheme for Complex
VLSI Devices
  • Yervant Zorian
  • ATT Bell Laboratories
  • Princeton, NJ, 08540

4
Introduction
  • The problem in todays VLSI devices.
  • Power, noise and area overhead.
  • Solution BIST! (Built in self test)

5
How BIST does it?
  • It is used at all levels and reused at all
    consecutive levels.
  • Possible only when if BIST features are included
    in devices.
  • Devices are the building blocks higher BIST
    levels are built.
  • So, device level BIST realization takes into
    account the BIST requirements of all levels,
    device, MCM, board, system.
  • These requirements affect the BIST Execution
    Scheduling, hence the need for BIST Control
    Network.

6
Existing Scheduling approaches
  • Focus on optimizing the test time for random
    logic blocks.
  • Problems in executing BIST in parallel
  • Power and noise dissipation
  • Higher activity rate
  • Overpass the device package limits.
  • New BIST scheduling process
  • Power dissipation less
  • Global optimization block type, device floor
    plan and test
    time.

7
New BIST Control Scheme
  • Simplifies BIST Execution
  • Autonomous embedded block
  • Simple and uniform interface protocol to
    communicate b/w controller and embedded blocks
  • Distributed architecture
  • Minimize routing cost control elements placed
    close to BIST blocks
  • Minimal control signals

8
BIST Scheduling Process
  • Analysis process where no hardware modifications
    are allowed.
  • Prior to scheduling, 2 analysis processes are
    performed
  • Device partitioning
  • BIST scheme selection

9
Partitioning and BIST Control
  • ASIC Z is a 132 pin standard device
  • Partitioned into ten blocks
  • Based on different criterion
  • - Structural types 4 RAMs 2 ROMs and Register
    File (RF)
  • -Random Logic blocks RL1 and RL2
  • - High frequency blocks RL3

10
Partitioning and BIST Control Contd.
  • Each block requires
  • Test Pattern Generator (TPG)
  • Output Data Evaluator (ODE)
  • BIST Resource Controller (BRC)
  • RL1 and RL2 Pseudo random based TPG and
    polynomial based ODE
  • RF and 4 RAMs 100 fault coverage TPG
  • ODE(RF) - provides zero loss of fault
    coverage
  • ODE(RAM)- performs output data comparison
    and space compaction
  • 2 ROMs TPG and ODE -gt perform exhaustive test
    sets

11
BIST Scheduling attributes
  • Power dissipation of each block
  • Adjacency of blocks
  • Type of each block
  • Test time

12
Power Dissipation Analysis
  • BIST is executed at system clock rate
  • Adv. full benefit is obtained
  • Disadv. higher activity rate -gt excess power
    dissipation
  • PF.N.PG
  • F Frequency
  • N Block size number of grids
  • PG number of watts per active grid and
    activity rate (0.5 for BIST modes)
  • Different modes Normal, BIST active and BIST
    idle
  • BIST Active during execution of a block
  • BIST Idle during periods when it waits for
    other blocks to execute BIST.
  • Total power dissipation power from each block
    power from input and output buffers.

13
Power Dissipation Analysis Contd.
  • Package limit of ASIC Z is 900mW.
  • Based on the values in the table, the device
    power dissipation for parallel BIST execution is
    2.332W.
  • Hence BIST Scheduling for power optimization is
    necessary.

14
ii. Grouping and Ordering
  • Create groups and proper sequence of each stage
    BIST Execution
  • Grouping and Ordering is dependent on the
    physical distribution of the blocks on the floor
    plan of a device.
  • Grouping is done based on 2 conditions
  • BIST power dissipation has to be less than device
    limit
  • Blocks in a group have to be physically adjacent
  • on floor plan.
  • A profile which is the result of grouping and
    sequencing at device level is in a matrix format
  • Bij - block, i single BIST stage, j number of
    blocks
  • For our example, we have

15
iii. Sharing and Test Time Optimization
  • Sharing reduces hardware area by reducing
    redundancies.
  • Sharing between blocks of same type RAMs, random
    logic, since their BRCs are identical and TPGs
    and ODEs are different in parameters.
  • Combine Boundary Scan with pseudo random TPGs on
    one hand and with ODEs on the other.
  • Test time is a limited amount of time that is
    dedicated per device.
  • BIST Execution takes only a minor fraction of the
    total test time as the other tests are far more
    time consuming.

16
BIST Control Architecture
  • Control operation has 4 functions
  • External access to device level BIST.
  • Control of BIST facilities of each block.
  • Control of device BIST.
  • Transfer of BIST response data.
  • These functions are realized in 3 types of
    hierarchical controllers
  • External BIST Access Port
  • BIST Resource Controllers (BRCs)
  • BIST Control Network.

17
External BIST Access Port
  • Boundary Scan TAP is the external access port for
    the device BIST.
  • For simple tests use 1 controller, TAP finite
    machine and boundary scan instructions.
  • For complex tests separate controllers are
    required for each one of BIST control functions.
  • BIST execution and BIST response data transfer
    are done via BS TAP no additional pins
    dedicated for external BIST access.

18
BIST Resource Controllers
  • Individual BRCs have to be allocated because
  • Number of blocks is in continuous growth.
  • BIST schemes of each block are different.
  • They are customized TPG and ODE
  • Sharing of non identical BRCs
  • low complexity FSM
  • Not cost effective

19
BIST Control Network
  • Executes the device BIST based on predetermined
    schedule.
  • Functions
  • Receives BIST execution via TAP and provides
    activation signals.
  • Collects and transfers BIST response when BIST
    completes.
  • Advantages
  • Division of control network each function
    controls subsequent BIST operation.

20
Distributed BIST Control Network
  • Centralized controllers for device level BIST
    control.
  • Problems
  • Routing area and number of control lines increase
    with the increase in the number of BRCs
  • For smaller number of blocks, centralized BIST
    control is possible.
  • Optimizes cost of control lines.

21
SBRIC Finite State Machine
  • Distributed network has control elements called
    Scheduled BIST Resource Interface Controllers

22
BIST control network
  • Disadvantages
  • Accumulates signatures of all BISTed blocks to a
    common compactor loss of diagnostic
    information.
  • Advantages
  • Provides not only group but also block level
    information.

23
Conclusions
  • - Generic BIST scheduling process and effective
    BIST control architecture.
  • - Scheduling provides power optimization.
  • - Control architecture provides autonomous BIST
    activation and capability to identify failed
    blocks.
  • Future Works- BIST network with additional
    diagnostic capabilities can be used for
    reconfiguration and repair operation.-
    Development of scheduling processes that take
    into account multi level test restrictions.

24
A Hybrid BIST Architecture and its Optimization
for SoC Testing Gert Jervan, Zebo Peng
Raimund Ubar, Helena Kruus Linköping University,
Sweden Tallinn Technical University, Estonia
25
A Hybrid BIST Architecture and its Optimization
for SoC Testing
OVERVIEW
25/42
26
A Hybrid BIST Architecture and its Optimization
for SoC Testing
INTRODUCTION
INTRODUCTION
26/42
27
A Hybrid BIST Architecture and its Optimization
for SoC Testing
BIST
27/42
28
A Hybrid BIST Architecture and its Optimization
for SoC Testing
HYBRID BIST
28/42
29
A Hybrid BIST Architecture and its Optimization
for SoC Testing
APPROACH OF THE PAPER
29/42
30
A Hybrid BIST Architecture and its Optimization
for SoC Testing
TARGET HYBRID BIST ARCHIETECTURE
30/42
31
A Hybrid BIST Architecture and its Optimization
for SoC Testing
TARGET HYBRID BIST ARCHIETECTURE
31/42
32
A Hybrid BIST Architecture and its Optimization
for SoC Testing
COST of HYBRID BIST
32/42
33
A Hybrid BIST Architecture and its Optimization
for SoC Testing
COST of HYBRID BIST
CGEN cost related to the time for generating L
pseudorandom test patterns (number of clock
cycles) CMEM related to the memory cost for
storing S pre-computed test patterns to improve
the pseudorandom test set ?, a constants to map
the test length and memory space to the costs of
the two parts of the test solutions to be mixed.
33/42
34
A Hybrid BIST Architecture and its Optimization
for SoC Testing
COST CALCULATION FOR PSEUDORANDOM TEST
BIST Analysis Data
34/42
35
A Hybrid BIST Architecture and its Optimization
for SoC Testing
COST CALCULATION FOR STORED TEST
ALGORITHM 1
Notations used
35/42
36
A Hybrid BIST Architecture and its Optimization
for SoC Testing
COST CALCULATION FOR STORED TEST
ALGORITHM 2
Notations used
36/42
37
A Hybrid BIST Architecture and its Optimization
for SoC Testing
TABU SEARCH
37/42
38
A Hybrid BIST Architecture and its Optimization
for SoC Testing
RESULTS
L length of pseudorandom sequence C fault
coverage CT total cost of BIST S number of
test patterns generated by deterministic ATPG to
be stored in BIST TG the time (sec) needed for
ATPG to generate the deterministic test set TA
the time(sec) needed for carrying out
manipulations on fault tables N number of
efficient patterns in the pseudorandom test
sequence T1,T1 the time (sec) needed for
calculating the cost curve by Algorithms 1 and
2 T3 the time (sec) to find the optimal cost by
using Tabu search Ts number of calculations in
Tabu search Acc percentage accuracy of Tabu
search solution compared to solution found from
cost curve
38/42
39
A Hybrid BIST Architecture and its Optimization
for SoC Testing
RESULTS
Percentage of test patterns in the optimized test
sets compared to the original test sets
39/42
40
A Hybrid BIST Architecture and its Optimization
for SoC Testing
RESULTS
Cost comparison of different methods. Cost of
pseudorandom test is taken as 100
40/42
41
A Hybrid BIST Architecture and its Optimization
for SoC Testing
SUMMARY
41/42
42
A Hybrid BIST Architecture and its Optimization
for SoC Testing
FUTURE WORK
42/42
43
A Hybrid BIST Architecture and its Optimization
for SoC Testing
QUESTIONS
