Title: Miscellaneous EKG Changes Chapter 14


1
(No Transcript)
2
Pulmonary Disease
  • Chronic Obstructive Pulmonary Disease
  • COPD disease of the lungs with airway
    obstruction, chronic bronchitis and emphysema
  • Cigarette smoking results in PACs, WAP,
    A-flutter, A-Fib
  • P Pulmonale
  • Acute Pulmonary Embolism
  • Blood Clot or other foreign matter lodges in a PA
    causing obstruction of blood flow to lungs
  • Originate from deep leg veins/pelvic veins
  • Chronic Cor Pulmonale
  • Enlargement of RV with RHF end stage results of
    Pulmonary Hypertension

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
Early Repolarization
  • A term used to describe a form of Myocardial
    repolarization in which the ST segment is
    elevated or depressed 1-3 mm above or below the
    base line.
  • Seen in Acute MIs

7
(No Transcript)
8
Hypothermia
  • Core body temperature of lt 95 degrees
  • Distinctive narrow positive wave the Osborn
    wave/J wave/J deflection/camels hump
  • Occurs at the junction of the QRS complex and ST
    segment

9
(No Transcript)
10
Preexcitation Syndromes
  • Accessory AV pathways (bundle of Kent)
  • Wolff-Parkinson White conduction
  • AV pathway between the Atrial and Ventricle
    bypasses the AV junction
  • Delta Wave
  • Atrio-His fibers (James fibers)
  • Atria with the lowermost part of the AV node
    bypassing the slower conducting AV node.
  • Atrio-His preexcitation
  • Nodoventricular fibers (Mahaim fibers)
  • Lower part of the AV node to the ventricles
  • Ventricular preexcitation

11
(No Transcript)
12
THE ENDOFCHAPTER 14
  • Hauszar Robert, Basic Dysrhythmias,
    Interpretation Management, Third Edition,
    Mosby, Inc. 2002, pp. 289-313.
