Game Playing

1
Game Playing
Kevin Chernishenko Nick Quach Mervyn Yong Terry
Yan
All information and figures provided by
Artificial Intelligence A Modern Approach
(Stuart Russell and Peter Norvig, 1995) unless
stated otherwise.
2
Introduction

• The state of a game is easy to represent and the
  agents are usually restricted to a small number
  of well-defined moves.
• Using games as search problems is one of the
  oldest endeavors in Artificial Intelligence.
• As computers became programmable in the 1950s,
  both Claude Shannon and Alan Turing had written
  the first chess programs.

3
Chess as a First Choice

• It provides proof that a machine can actually do
  something that was thought to require
  intelligence.
• It has simple rules.
• The world state is fully accessible to the
  program.
• The computer representation can be correct in
  every relevant detail.

4
Complexity of Searching

• The presence of an opponent makes the decision
  problem more complicated.
• Games are usually much too hard to solve.
• Games penalize inefficiency very severally.

5
Things to Come

• Perfect Decisions in Two-Person Games
• Imperfect Decisions
• Alpha-Beta Pruning
• Games That Include an Element of Chance

6
Perfect Decisions in Two-Player Games
7
Games a Search Problem

• Some games can normally be defined in the form of
  a tree.
• Branching factor is usually an average of the
  possible number of moves at each node.
• This is a simple search problem a player must
  search this search tree and reach a leaf node
  with a favorable outcome.

8
Tic Tac Toe
9
Components of a Game

• Initial state
• Set of operators
• Terminal Test
• Terminal State is the state the player can be in
  at the end of a game
• Utility Function

10
Two Player Game

• Two players Max and Min
• Objective of both Max and Min to optimize
  winnings
• Max must reach a terminal state with the highest
  utility
• Min must reach a terminal state with the lowest
  utility
• Game ends when either Max and Min have reached a
  terminal state
• upon reaching a terminal state points maybe
  awarded or sometimes deducted

11
Search Problem Revisited

• Simple problem is to reach a favorable terminal
  state
• Problem Not so simple...
• Max must reach a terminal state with as high a
  utility as possible regardless of Mins moves
• Max must develop a strategy that determines best
  possible move for each move Min makes.

12
Tic Tac Toe Revisited
13
Example Two-Ply Game
3 12 8 2 4 6 14 5 2
14
Minimax Algorithm

• Minimax Algorithm determines optimum strategy for
  Max
• Generate entire search tree
• Apply utility function to terminal states
• use utility value of current layer to determine
  utility of each node for the upper layer
• continue when root node is reached
• Minimax Decision - maximizes the utility for Max
  based on the assumption that Min will attempt to
  Minimize this utility.

15
Two-Ply Game Revisited
3
3
2
2
3 12 8 2 4 6 14 5 2
16
An Analysis

• This algorithm is only good for games with a low
  branching factor, Why?
• In general, the complexity is
• O(bd) where b average branching factor
• d number of plies

17
Is There Another Way?

• Take Chess on average has
• 35 branches and
• usually at least 100 moves
• so game space is
• 35100
• Is this a realistic game space to search?
• Since time is important factor in gaming
  searching this game space is highly undesirable

18
Imperfect Decisions
19
Why is it Imperfect?

• Many game produce very large search trees.
• Without knowledge of the terminal states the
  program is taking a guess as to which path to
  take.
• Cutoffs must be implemented due to time
  restrictions, either buy computer or game
  situations.

20
Evaluation Functions

• A function that returns an estimate of the
  expected utility of the game from a given
  position.
• Given the present situation give an estimate as
  to the value of the next move.
• The performance of a game-playing program is
  dependant on the quality of the evaluation
  functions.

21
How to Judge Quality

• Evaluation functions must agree with the utility
  functions on the terminal states.
• It must not take too long ( trade off between
  accuracy and time cost).
• Should reflect actual chance of winning.

22
Design

• Different evaluation functions must depend on the
  nature of the game.
• Encode the quality of a position in a number that
  is representable within the framework of the
  given language.
• Design a heuristic for value to the given
  position of any object in the game.

23
Different Types

• Material Advantage Evaluation Functions
• Values of the pieces are judge independent of
  other pieces on the board. A value is returned
  base on the material value of the computer minus
  the material value of the player.
• Weighted Linear Functions
• W1f1w2f2wnfn
• Ws are weight of the pieces
• Fs are features of the particular positions

24
Example

• Chess Material Value each piece on the board
  is worth some value ( Pawn , Knights 3 etc)
  www.imsa.edu/stendahl/comp/txt/gnuchess.txt
• Othello Value given to of certain color on
  the board and of colors that will be converted
  lglwww.epfl.ch/wolf/java/html/Othello-desc.html

25
Different Types

• Use probability of winning as the value to
  return.
• If A has a 100 chance of winning then its value
  to return is 1.00

26
Cutoff Search

• Cutting of searches at a fixed depth dependant on
  time
• The deeper the search the more information is
  available to the program the more accurate the
  evaluation functions
• Iterative deepening when time runs out return
  the program returns the deepest completed search.
• Is searching a node deeper better than searching
  more nodes?

27
Consequences

• Evaluation function might return an incorrect
  value.
• If the search in cutoff and the next move results
  involves a capture then the value that is return
  maybe incorrect.
• Horizon problem
• Moves that are pushed deeper into the search
  trees may result in an oversight by the
  evaluation function.

28
Improvements to Cutoff

• Evaluation functions should only be applied to
  quiescent position.
• Quiescent Position Position that are unlikely
  to exhibit wild swings in value in the near
  future.
• Non quiescent position should be expanded until
  on is reached. This extra search is called a
  Quiescence search.
• Will provide more information about that one node
  in the search tree but may result in the lose of
  information about the other nodes.

29
Alpha-Beta Pruning
30
Pruning

• What is pruning?
• The process of eliminating a branch of the search
  tree from consideration without examining it.
• Why prune?
• To eliminate searching nodes that are potentially
  unreachable.
• To speedup the search process.

31
Alpha-Beta Pruning

• A particular technique to find the optimal
  solution according to a limited depth search
  using evaluation functions.
• Returns the same choice as minimax cutoff
  decisions, but examines fewer nodes.
• Gets its name from the two variables that are
  passed along during the search which restrict the
  set of possible solutions.

32
Definitions

• Alpha the value of the best choice so far along
  the path for MAX.
• Beta the value of the best choice (lowest
  value) so far along the path for MIN.

33
Implementation

• Set root node alpha to negative infinity and beta
  to positive infinity.
• Search depth first, propagating alpha and beta
  values down to all nodes visited until reaching
  desired depth.
• Apply evaluation function to get the utility of
  this node.
• If parent of this node is a MAX node, and the
  utility calculated is greater than parents
  current alpha value, replace this alpha value
  with this utility.

34
Implementation (Contd)

• If parent of this node is a MIN node, and the
  utility calculated is less than parents current
  beta value, replace this beta value with this
  utility.
• Based on these updated values, it compares the
  alpha and beta values of this parent node to
  determine whether to look at any more children or
  to backtrack up the tree.
• Continue the depth first search in this way until
  all potentially better paths have been evaluated.

35
Example Depth 4
MIN MAX
36
Effectiveness

• The effectiveness depends on the order in which
  the search progresses.
• If b is the branching factor and d is the depth
  of the search, the best case for alpha-beta is
  O(bd/2), compared to the best case of minimax
  which is O(bd).

37
Problems

• If there is only one legal move, this algorithm
  will still generate an entire search tree.
• Designed to identify a best move, not to
  differentiate between other moves.
• Overlooks moves that forfeit something early for
  a better position later.
• Evaluation of utility usually not exact.
• Assumes opponent will always choose the best
  possible move.

38
Games that Include an Element of Chance
39
Chance Nodes

• Many games that unpredictable outcomes caused by
  such actions as throwing a dice or randomizing a
  condition.
• Such games must include chance nodes in addition
  to MIN and MAX nodes.
• For each node, instead of a definite utility or
  evaluation, we can only calculate an expected
  value.

40
Inclusion of Chance Nodes
41
Calculating Expected Value

• For the terminal nodes, we apply the utility
  function.
• We can calculate the expected value of a MAX move
  by applying an expectimax value to each chance
  node at the same ply.
• After calculating the expected value of a chance
  node, we can apply the normal minimax-value
  formula.

42
Expectimax Function

• Provided we are at a chance node preceding MAXs
  turn, we can calculate the expected utility for
  MAX as follows
• Let di be a possible dice roll or random event,
  where P(di) represents the probability of that
  event occurring.
• If we let S denote the set of legal positions
  generated by each dice roll, we have the
  expectimax function defined as follows
• expectimax(C) Si P(di) maxs ?S(utility(s))
• Where the function maxs ?S will return the move
  MAX will pick out of all the choices available.
• Alternately, you can generate an expextimin
  function for chance nodes preceding MINs move.
• Together they are called the expectiminimax
  function.

43
Application to an Example
MAX
Chance
3.56
.6
.4
MIN
3.0
4.4
Chance
3.0
5.8
4.4
3.6
.6
.4
.6
.6
.6
.4
.4
.4
MAX
4
3
7
3
5
6
2
3
2
1
2
3
5
2
3
1
4
3
2
2
7
5
6
1
44
Chance Nodes Differences

• For minimax, any order-preserving transformation
  of leaves do not affect the decision.
• However, when chance nodes are introduced, only
  positive linear transformations will keep the
  same decision.

45
Complexity of Expectiminimax

• Where minimax does O(bm), expectiminimax will
  take O(bmnm), where n is the number of distinct
  rolls.
• The extra cost makes it unrealistic to look too
  far ahead.
• How much this effects our ability to look ahead
  depends on how many random events that can occur
  (or possible dice rolls).

46
Wrapping Things Up
47
Things to Consider

• Calculating optimal decisions are intractable in
  most cases, thus all algorithms must make some
  assumptions and approximations.
• The standard approach based on minimax,
  evaluation functions, and alpha-beta pruning is
  just one way of doing things.
• These search techniques do not reflect how humans
  actually play games.

48
Demonstrating A Problem

• Given this two-ply tree, the minimax algorithm
  will select the right-most branch, since it
  forces a minimum value of no less than 100.
• This relies on the assumption that 100, 101, and
  102 are in fact actually better than 99.

49
Summary

• We defined the game in terms of a search.
• Discussion of two-player games given perfect
  information (minimax).
• Using cut-off to meet time constraints.
• Optimizations using alpha-beta pruning to arrive
  at the same conclusion as minimax would have.
• Complexity of adding chance to the decision tree.
