Biology II Lab Practical Review Part II

1
Biology II Lab Practical ReviewPart II
Last updated 11-29-07
2
Fungi
Phyla Chytridiomycota Zygomycota Glomeromycota
Ascomycota Basidiomycota
3
Aspergillis Ascomycota - mold
Ascomycota
Basidiomycota
http//www2.muw.edu/mharvill/index.html
Zygomycota - Rhizopus
Ascomycota
4
Name the phylum and explain the pictures.
http//www.ffp.csiro.au/research/mycorrhiza/vam.ht
ml

• Answer Glomeromycota. They are
  endomycorrhizae. The tips of the hyphae push
  into plant root cells and branch into tiny
  treelike structures known as arbuscles.

5
Fungi Reproduction
Basidia
Zygoyte Rhizopus
Ascospores Inside Ascus
Conidia - Asexual Ascomycota
Yeast budding
6
Lichen

• Lichen are a symbiotic association composed of
• a. mycorrhizae and green algae
• b. nodules and cyanobacteria
• c. fungi, cyanobacteria and/or green algae
• d. chlorophyta and green algae
• e. a. and b.
• Answer c.

7
Fruticose
Foliose
Crustose
Crustose
Fruticose
8
Embryology
9
What is the difference between phylogeny and
ontology?

• Answer One is the study of evolutionary
  relationships among organisms and the other is
  the development of an individual organism from
  egg to adult.

10
Cell Division
Mesenchyme
Archenteron
Morula
Gastrula
Blastocoel
Blastula
11
midbrain
Locate on diagram forebrain somite eye midbrain
pharynx heart neural tube somite ear hindbrain
eye
hindbrain
forebrain
ear
heart
pharynx
somite
neural tube
somite
48 hr. chick dorsal view
12
Chorion
Embryo
Amnion
Allantois
Yolk sac
Yolk
13
Extraembryonic Membranes

• What are the functions of the extraembryonic
  membranes?
• Answer
• Amnion - protects the embryo
• Chorion - gas exchange
• Allantois - waste disposal gas exchange
• Yoke sac - surrounds yoke for nutrients

14
Germ Layers

• What are the three germ layers?
• Answer Ectoderm, Endoderm, Mesoderm
• What body tissues are derived from each?
• Answer
• Ectoderm - epidermis of skin, mouth rectum
  lining, eye, nervous system, tooth enamel
• Endoderm lining of digestive tract and
  respiratory system, liver, pancreas, thyroid,
  lining of reproductive system
• Mesoderm notocord, skeleton, muscles,
  circulatory system, reproductive system,
  excretory system, skin dermis, body cavity lining

15
Invertebrates
16
Porifera
What are the body plans below?

• Answer ascon, sycon, leucon

17
Cnidaria
Anthozoa
Scyphozoa
Hydrozoa
Ctenophora
Comb Jelly
Cubozoa
18
Platyhelmenthes
Trematoda
Turbellaria
Turbellaria
Cestoda
Monogenea
19
Nemertea
Rotifera
20
Nematoda
Male or female?
Answer Male
21
Arthropoda

• Crustacea and Insecta are distinct from each
  other in that
• a. Crustacea have segmented legs
• b. Insects have segmented legs
• c. Crustacea have two pairs of antenna
• d. Insects have two pairs of antenna
• e. a. b.
• Answer c

22
Arthropoda Classes
Myriapoda Subclass Diplopoda
Myriapoda Subclass Chilopoda
Arachnida
Crustacea
Insecta
23
Match the letter to the number

• 1. Porifera
• 2. Cnidaria
• 3. Ctenophora
• 4. Platyhelmenthes
• 5. Mollusca
• 6. Nematoda
• 7. Annelida
• 8. Arthropoda
• 9. Echinodermata

• a. Diplopoda
• b. Roundworm
• c. Cephalopoda
• d. Turbelaria
• e. Hydrozoa
• f. Comb jelly
• g. Ophiuroidea
• h. Oligochaeta
• i. Ascon body type

• Answers 1(i), 2(e), 3(f), 4(d), 5(c), 6(b),
  7(h), 8(a), 9(g)

24
a.
d.
Echinodermata

1. Asteroidea

b. Holothuroidea
c. Crinoidea
d. Ophiurodea
e. Echinoidea
b.
e.
f. Echinoidea
g. Concentricycloidea
f.
c.
g.
25
a.
d.
Echinodermata

1. Asteroidea

b. Holothuroidea
c. Crinoidea
d. Ophiurodea
e. Echinoidea
b.
e.
f. Echinoidea
f.
c.
26
Mollusca
Polyplacophora
Gastropoda
Bivalvia
Cephalopoda
Cehpalopoda
Cephalopoda
27
Annelida
Oligochaeta
Hirudinia
Polychaeta
28
Match the letter with the number. Answers may be
used more than once.

• 1. Platyhelmenthes
• 2. Roundworms
• 3. Earthworm
• 4. Mouth first
• 5. Anus first
• 6. lack tissue
• 7. true tissue

• a. parazoa
• b. acoelomate
• c. pseudocoleomate
• d. deuterostome
• e. protostome
• f. eumetazoa
• g. coelomate

• Answer 1b, 2c, 3g, 4e, 5d, 6a, 7f

29
Vertebrates
30
What are the four main characteristics of
Chordata?

• Answer
• Notocord. Flexible, rod-like. Replaced by
  vertebrae of backbone in vertebrates.
• Pharyngeal gill slits from throat to exterior
• Dorsal hollow nerve cord whose main cord is solid
• Post-anal tail

31
The subphyla of Chordata are?

• a. Urochordata, Asteroidea, Cephalochordata
• b. Vertebrata, Cephalochordata, Agnatha
• c. Cephalochordata, Agnatha, Actinistia
• d. Urochordata, Cephalochordata, Vertebrata
• e. None of the above
• Answer d
• Which subphylum do Tunicates belong?
• Answer Urochordata

32
Match the letter with the number.Answer only used
once.

• 1. Shark
• 2. Perch
• 3. Frog
• 4. Pig

• a. Class Actinopterygii
• b. Class Mammalia
• c. Class Chondrichthyes
• d. Order Anura

• Answer 1c, 2a, 3d, 4b

33
Reptilia
Order Crocodilia
Order Squamata
Order Chelonia
Order Sphenodontia
Order Squamata
34
Orders of Placental Mammals
Sirenia
Rodentia
Proboscidea
Primates
Perissodactyla
Insectavora
Lagomorpha
Chiroptera
Perissodactyla
Cetacea
Artiodactyla
Artiodactyla
35
Mammals
Order Monotremata
Order Marsupials
Class Aves
Carinates
Ratites
36
Frog
c.
Heart
a.
Fat bodies
b.
Liver
d.
Stomach
e.
Small intestines
37
c.
male or female?
female
b.
heart
a.
cloaca
Shark
38
Pig
a.
heart
c.
lung
b.
liver
39
swim bladder
b.
gills
a.
e.
ovary
c.
liver
d.
stomach
f.
intestine
40
Good Luck It's almost over!
