Solutions Chapter 6

1
SolutionsChapter 6

• Dr. Michael P. Gillespie

2
Properties of Solutions

• A solution is a homogenous (uniform) mixture of
  two or more substances.
• A solution is composed of one or more solutes,
  dissolved in a solvent.
• The solute is a compound of a solution that is
  present in lesser quantity than the solvent.
• The solvent is the solution component that is
  present in the largest quantity.
• An aqueous solution is one in which water is the
  solvent.

3
Solution
4
Example of a Solution

• When sugar (the solute) is added to water (the
  solvent), the sugar dissolves in the water to
  produce a solution.
• This mixture is an aqueous solution because water
  is the solvent.

5
Types of Solutions

• The dissolution of a solid into a liquid is the
  most common example of solution formation
  however, it is possible to form solutions in
  gases and solids as well as liquids.
• Air is a gaseous mixture, but it is also a
  solution. Oxygen and some other trace gasses
  are dissolved in the gaseous solvent nitrogen.
• Many important biochemical reactions occur in
  liquid solutions, so our emphasis will be placed
  there.

6
Properties of Liquid Solutions

• Liquid solutions are clear and transparent with
  no visible particles of solute.
• They can be either colored or colorless.

7
Electrolyte and Nonelectrolyte Solutions

• An electrolyte is a material that dissolves in
  water to produce a solution that conducts an
  electrical current.
• Solutions of electrolytes are formed from solutes
  that are soluble ionic compounds.
• Good conductors of electricty
• Sodium Chloride dissolving in water
• Solutions of nonelectrolytes are formed from
  nondissociating molecular solutes.
• Nonconducting
• Sugar dissolving in water

8
Electrolyte
9
True Solutions

• A true solution is a homogenous mixture with
  uniform properties throughout.
• The solute cannot be isolated from the solution
  by filtration.
• The particle size of the solute and solvent are
  about the same and both pass directly through the
  filter paper.
• Solute particles will not settle out over time.

10
True Solutions

• All of the molecules of solute and solvent are
  intimately mixed.
• The particles are in continuous motion and
  therefore maintain a homogenous, random
  distribution of solute and solvent particles.
• Volumes of solute and solvent are not additive.
• 1 L of alcohol mixed with 1 L of water does not
  result in exactly 2L of solution.
• It depends upon how the molecules fit together.

11
Solution, Pure Substance, or Colloidal Suspension?

• A beaker containing a clear liquid may be a
  pure substance, a true solution, or a colloid.

12
Solution Vs. Pure Substance

• Only chemical analysis can distinguish between a
  pure substance and a true solution.
• A pure substance has only one component.
• A true solution has more than one substance, with
  the tiny particles homogenously intermingled.

13
Colloidal Suspension

• A colloidal suspension also consists of solute
  particles distributed throughout a solvent
  however, the distribution is not completely
  homogenous, due to the size of the colloidal
  particles.
• Particles smaller than 1 nm are solution
  particles.
• Particles between 1 nm and 200 nm are colloids.
• Particles larger than 200 nm are precipitates
  (solid in contact with solvent).

14
Solution Vs. Colloidal Suspension

• To the naked eye, a colloidal suspension and a
  true solution appear identical. Neither the
  solute nor the colloid can be seen by the naked
  eye.
• Colloid particles are large enough to scatter
  light, whereas solute particles are not.
• When a beam of light passes through a colloidal
  solution, the large particles scatter light, and
  the liquid appears hazy. Similar to sunlight
  passing through fog.
• Tyndall effect the light-scattering ability of
  solutions.

15
Suspension

• A suspension is a heterogeneous mixture that
  contains particles much larger than a colloidal
  suspension.
• These particles can settle out over time.

16
Colloidal Suspension
17
Polarity and Solubility

• Like dissolves like.
• Polar solutes are soluble in polar solvents.
• Nonpolar solutes are soluble in nonpolar solvents.

18
Degree of Solubility

• The degree of solubility is a measure of how much
  solute can dissolve in a given quantity of
  solvent.
• Factors influencing degree of solubility.
• The magnitude of difference between polarity of
  solute and solvent. (Inverse relationship)
• Temperature. (Usually increases solubility)
• Pressure. (Greater influence on gases)

19
Saturation

• A saturated solution contains all of the solute
  that can be dissolved at a particular
  temperature.
• Decreasing the temperature typically decreases
  the amount of solute the solution can hold.
• The excess solute falls to the bottom of the
  container as precipitate (a solid in contact with
  a solution).
• Sometimes the excess solute stays in solution for
  a period of time. The solution is then said to
  be supersaturated (this is an unstable condition).

20
Precipitation
21
Solubility and Equilibrium

• When an excess of solute is added to a solvent,
  it begins to dissolve and continues to do so
  until it reaches a dynamic equilibrium between
  dissolved and undissolved solute.
• The rate of dissolution and precipitation
  eventually become equal.
• There is a continual exchange of particles
  between solid and liquid phases.

22
Henrys Law

• Henrys Law states that the number of moles of a
  gas dissolved in a liquid at a given temperature
  is directly proportional to the partial pressure
  of the gas.
• The gas solubility is directly proportional to
  the pressure of that gas in the atmosphere that
  is in contact with the liquid.
• Gases are most soluble at low temperatures.
• Henrys law has a direct application to
  respiration in the lungs.

23
Henrys Law
24
Henrys Law
25
Concentration Based on Mass

• A solution concentration is the amount of solute
  dissolved in a given amount of solution.
• The concentration of a solution affects its
  physical properties such as melting and boiling
  points.
• The concentration also affects its chemical
  properties influencing its reactivity.

26
Weight / Volume Percent

• Concentration amount of solute / amount of
  solution
• Concentration grams of solute / milliliters of
  solution
• concentration grams of solute / milliliters
  of solution 100

27
Molarity

• Molarity (M) is the number of moles of solute per
  liter of solution.
• A Mole is a collection of atoms.
• 1 mol of atoms 6.022 X 1023 atoms of an
  element. This number is Avogadros number.
• The mass of 1 mol of atoms is defined as the
  molar mass.
• One mole of atoms of any element contains the
  same number of atoms (6.022 X 1023 atoms).

28
Dilution

• Laboratory reagents are often purchased as
  concentrated solutions for safety, economic, and
  space limitation reasons.
• We often must dilute the solution to prepare a
  less concentrated form for our experiment.

29
Dilution
30
Colligative Properties

• Colligative properties are properties of
  solutions that depend on the concentration of the
  solute particles, rather than the identity of the
  solute.
• 1. vapor pressure lowering
• 2. freezing point depression
• 3. boiling point elevation
• 4. osmotic pressure

31
Vapor Pressure Lowering (Raoults Law)

• Raoults law states that, when a nonvolatile
  solute is added to a solvent, the vapor pressure
  of the solvent decreases in proportion to the
  concentration of the solute.
• This has a direct effect on the freezing and
  boiling points of a solution.
• The freezing point decreases.
• The boiling point increases.

32
Freezing Point DepressionBoiling Point Elevation

• The solute molecules interfere with the rate at
  which liquid water molecules associate to form
  the solid state.
• Salt is spread on ice in the winter because it
  lowers the freezing point of water.
• 1 mol of glucose ? 1 mol of particles in solution
• 1 mol of sodium chloride ? 2 mol of particles in
  solution

33
Osmotic Pressure

• Some membranes are semipermeable. They all small
  solvent molecules such as water to cross
  however, larger solute particles are too large to
  get through the small pores of the membrane.
• Osmosis is the diffusion of a solvent from a
  dilute solution to a more concentrated solution
  through a semipermeable membrane.
• Pressure must be applied to the more concentrated
  solution to stop the flow. Osmotic pressure is
  the amount of pressure required to stop the flow.

34
Osmosis
35
Hypertonic, Hypotonic, Isotonic

• Hypertonic Water leaves a cell via osmosis.
  The cell undergoes crenation (shrinkage).
• Hypotonic Water enters a cell via osmosis. The
  cell undergoes hemolysis (ruptures).
• Isotonic Two solutions are isotonic if they
  have identical osmotic pressures.

36
Crenation Hemolysis
37
Water as a Solvent

• Water is often referred to as the universal
  solvent.
• It is the principle biological solvent.
• Water is a polar molecule. Much of the matter on
  earth is polar. Like dissolves like.

38
Properties of Water

• Water is the only common molecule that exists in
  all three physical states of matter (solid,
  liquid, and gas) under natural conditions on
  earth.
• Water is essential for all life.
• Water is the most abundant molecule in living
  systems (70-95).
• Water covers 70 of the earths surface.

39
Properties of Water

• Water has an unusually high specific heat and can
  therefore resist changes in temperature. It
  stabilizes temperatures on both earth and in the
  body.
• Water has a very high heat of vaporization.
• As water evaporates, the surface of the liquid
  cools. Perspiration helps to prevent overheating
  on a hot day or during strenuous exercise.
• The solid state of water is less dense than the
  liquid state (about 10 less dense).

40
Solutes in Blood

• An electrolyte is a material that dissolves in
  water to produce a solution that conducts an
  electrical current.
• The concentration of cations, anions, and other
  substances in body fluids is critical to health.
• The kidneys carefully regulate these levels.
• Na and K are the two most important cations in
  body fluids.
• Sodium is more abundant in intercellular fluids
  and potassium is more abundant in intracellular
  fluids. (Active transport)
• If potassium levels become too high from cell
  death (leakage) or too low from excessive
  sweating, heart failure can ensue.

41
Solutes in Blood

• The major anions in blood are Cl- and HCO3-.
• Chloride anion helps with acid-base balance,
  osmotic pressure, and oxygen transport by
  hemoglobin.
• Bicarbonate anion helps transport CO2 in the
  blood.
• Plasma proteins blood clotting factors,
  immunoglobulins (antibodies), and albumins (carry
  non-polar substances).
• Nutrients and waste products.

42
Hemodialysis

• Dialysis the kidneys remove waste products such
  as urea and uric acid as well as excess salts
  from the blood. This process is known as
  dialysis.
• Hemodialysis is the use of an artificial kidney
  to remove waste products from the blood.

43
Hemodialysis
