TRAUMATIC CARDIAC INJURIES

1
TRAUMATIC CARDIAC INJURIES

• SHORT CASE STUDY
• HENNIE LATEGAN

2
(No Transcript)
3
CASE HISTORY

• 25 YEAR OLD, PENETRATING STAB TO THE CHEST (6th
  intercostal space, 1.5cm left lateral to sternum)
• BP 70 systolic
• Pulse poor volume, 65bpm
• GCS 12/15
• Ward Hb 7g/dl
• Fluid challenge 3 litres of lactated ringers
  plus 500ml of voluven. Poor response to
  resucitative efforts.
• Heart sounds muffled

4
WHAT NOW?

• If at GSH C14 Thoracotomy of course!
• Tygerberg Trauma? Argue with the nurses as to
  indications, outcome, yes they do it at C14 and
  yes you are able to possibly do it.
• Victoria Hospital Thora..what? No no no Dr.
  over here we transfer to GSH C14.
• GF Jooste well the nurse who normally does it
  is on tea, but I will help you

5
General Cardiac Injuries

• Blunt cardiac injuries
• Penetrating cardiac injuries

6
Blunt Injuries

• Cardiac contusion commonest
• Usually partial thickness injury as rupture is
  fatal
• High speed deceleration
• Often assoc. with rib fractures, sternal and
  thoracic spine fractures.

7

• Clinical Features
• Low BP with Bradycardia
• Raised JVP
• Arrhythmias, MI type syndrome
• Tamponade

8

• ECG Changes
• S-T segment raised or depressed
• Q waves in anterior leads
• Brady or Tachyarrhythmias

9
Penetrating Injuries

• Several presentations
• Exsanguinating haemorrhage
• Tamponade group
• Asymptomatic cardiac injury

10
Pericardial included in Penetrating

• 1. Unstable cardiac tamponade
• 2. Stable cardiac tamponade
• 3. Asymptomatic/Subclinical pericardial injuries
• Commonest cause is a precordial stab.

11

• Clinical Features
• STABLE TAMPONADE
• PERIOD OF HYPOTENSION
• REVERSED WITH 500-1000ML OF CRYSTALLOID
• BUT ELEVATED CVP/JVP

12

• Unstable Cardiac Tamponade
• Shock with hypotension and tachycardia
• Dyspnoea
• Raised venous pressures JVP/CVP
• Pulsus paradoxus
• Unreliable distant heart sounds and impalpable
  apex.

13

• Subclinical Pericardial Injuries
• Pericardial rub
• Pneumopericardium
• Raised ST
• J waves
• Straight left cardiac border
• Globular heart
• Note ECG screening tool
• U/S no value, no fluid present

14
INDICATIONS

• The patient fits into 1 of 3 groups
• 1. Accepted indications
• 2. Relative indications
• 3. Contraindications

15

• This decision needs to be made very quickly.
• Some of the following slides may help!

16
Gunshot Chest
17
Underground Rock Fall
18
Gunshot Chest
19
Stab Back
20
(No Transcript)
21
(No Transcript)
22
Gunshot neck with cardiac injury
23
Crush injury
24
Blunt chest trauma, MVA
25
Accepted Indications

• PENETRATING
• Traumatic arrest with previously witnessed
  cardiac activity (pre-hospital or in-hospital)
• Unresponsive hypotension ( systolic lt 70 )
• BLUNT
• Unresponsive hypotension (systolic lt 70)
• Rapid exsanguination from chest tube (gt1500ml)

26
Relative Indications

• Penetrating thoracic
• Traumatic arrest without previously witnessed
  cardiac activity.
• Penetrating non-thoracic
• Traumatic arrest with previously witnessed
  cardiac activity. (pre-hospital or in-hospital)

27

• Rel. Indications Contd.
• Blunt Thoracic Injuries
• Traumatic arrest with previously witnessed
  cardiac activity. ( pre-hospital or in-hospital)

28
Contraindications

• Blunt Injuries
• Blunt thoracic with no witnessed cardiac activity
• Multiple blunt trauma
• Severe head injury

29
So did this patient fit the criteria?

• Yes.
• Ultrasound machine was on hand to confirm Dx.
• Cardiac Ultrasound video

30
(No Transcript)
31
What other diagnostic modalities could be used?

• ECG
• Diagnostic pericardiocentesis
• CT

32
What ECG changes?

• Penetrating
• Electrical alternans
• J waves( more pericardial injury)
• Blunt
• MI changes
• Multiple PVCs
• Sinus tachycardia
• Atrial fibrilation
• Bundle branch blocks

33
(No Transcript)
34

• Previous slide Electrical alternans
• Next slide J waves

35
(No Transcript)
36
So we have the criteria, why actually do it?what
is the evidence?

• Survival is btw. 4-33 (protocol dependant)
• GSH 50 survival for penetrating
• Blunt trauma survival rates 0-2.5
• Stab wounds Greater survival than gunshot
  wounds.
• Isolated thoracic stab wounds causing cardiac
  tamponade highest survival rate 70

37
Blunt? Should it be done?

• According to literature, YES
• When?
• Isolated blunt trauma undergoing arrest in the
  AE
• Debate arresting in the prehospital setting.

38
Location of the cardiac injury

• Most survivors are of the isolated injury type
• Cardiac highest survival rates
• Great vessels poor
• Pulmonary hila even poorer

39
Back to the patient

• A supine anterolateral thoracotomy was performed.
• Video of procedure to follow

40
Briefly the step by step

• If the patient is reasonably stable
• CVP insertion
• Intubation/RSI
• Peripheral IV
• CXR
• Chest Drain
• Cross match 4 units blood
• Ultrasound
• Subxiphisternal window to look directly if no US

41

• Incision Left anterolateral. 5th intercostal
  space from the nipple to the ant/mid axillary
  line.
• Rib retractor to open up
• Enter the 5th interspace and open the pericardial
  sac longitudinally
• Note anterior to the phrenic nerve
• Once open scoop out the clot

42

• Usually a clinical improvement is evident
• Locate the ?hole in the heart
• Place a finger in the hole
• Either insert foleys catheter with 5mls of saline
  or suture close.
• Prolene thread
• Pledgets of dacron can be used
• Avoid coronary vessels when suturing

43

• Check for through and through wounds
• Tie off internal mammary if it has been cut
• Look for any other injuries
• At GSH the patients if they have survived are
  taken to theatre for closure of the thoracotomy.

44
Incision and pericardial splitting
45
Rib retraction/suturing
46
Pericardial opening
47
Pledgets
48
Cross Clamping
49

• The patient in the video survived and walk out of
  the unit 6 days later.

50
References

• 1.Emergency Department Thoracotomy Karim Brohi,
  trauma.org 66, June 2001
• 2.Trauma Manaul UCT 2002 Edition. Editor
  Peter Bautz
• 3.ATLS Student course manual, 7th Edition
• 4.Atlas of Emergency Medicine, Peter Rosen MD
• 5. Basic surgical skills manual, Royal College
  of Surgeons, 2007
