ALARM

1
ALARM

• Property Risk Engineering for the Public Sector
• January 2006
• Derick Milner
• Senior Risk Engineer
• Property Division

2
Risk Engineering

• Identification of risk - (vital first stage)
• Evaluate risk- (evaluation of frequency
  severity)
• Accept the risk (residual risk considered OK)
• Transfer risk consequences (contractual)
• Elimination of risk - (risk avoidance or
  transfer)
• Control of risk - (reduce risk or provide
  protection)-
• Management of Risk Housekeeping, Permit to
  Work Self Inspection, Smoking etc.
• Physical Risk Control Sprinklers, Fire Alarms,
  CCTV Construction, Fencing etc.

3
Loss Statistics - The UK Arson Problem?
October 2003 to September 2004
Add these?
4
Loss Statistics Local Authority Type Risks
10/03 to 9/04 No Loss Amount
Education 18 11.39 29,002,250 14.61
Local/National Government 14 8.86 16,475,430 8.30
Community Centre 4 2.53 2,005,000 1.01
Care Home 1 0.63 405,000 0.20
Library 1 0.63 5,500,000 2.77
Other 120 75.95 145,137,948 73.11
Total 158 100.00 198,525,628 100.00

Local Authority Type Risks 38 24.05 53,387,680 26.89
Source FPA reported losses over 250,000
5
Risk Engineering Key Risk Areas

• Arson Malicious Damage
• Hot Work fires (and contractor control)
• Housekeeping issues
• Smoking related fires
• Electrical fires
• Cooking

6
Risk Engineering Arson
Roll top wheelie bin Cardiff City Centre A
common sight? Consider fire spread to facilities
from external storage
7
Risk Engineering Arson

• Discussion
• Key Protection Issues
• Denial of access security / surveillance
• Perimeter Security
• CCTV
• Lighting
• Guarding
• Intruder Alarm
• Limit external fuel keep away from buildings
• Fire Protection alarms, sprinklers,
  construction etc.

8
Risk Engineering Arson
Community Centre (disused) Unused partly
boarded up Evidence of entry to building
9
Risk Engineering Arson
Community Centre (disused) Internal Photo Large
quantity of combustible items present.
10
Risk Engineering Arson
Community Centre (disused) Malicious damage
Arson potential VERY HIGH

• Security
• Weekly Inspections
• Remove fuel
• Isolate services unless for alarm etc

11
Risk Engineering Hot Work Permit

• DiscussionKey Points
• Applicable to both own employees and contractors
• Welding, Braising, Grinding, Cutting, Tar Burners
  etc.
• Applicable to work undertaken outside of a
  designated workshop
• Issued for Maximum 1-shift
• Remove combustibles from immediate area
• Provide specific fire fighting equipment
• Fire watch minimum 1-hour after work ceases
• Designated person responsible to manage the
  system

12
Risk Engineering Hot Work Permit
13
Risk Engineering Contractor Control
Contractors cabin next to glazed
windows. Combustible construction. Controls? Sup
ervision?
14
Risk Engineering Contractor Control
Inside contractors cabin. Fire inception hazard
VERY HIGH Fire spread risk VERY HIGH
15
Risk Engineering Housekeeping

• Discussion who is responsible? cause
  effect? how can we improve?
• Self-Inspection!

• Responsibility cascade to local management
• Engage and involve all building users
• Formalised process
• Cross department checks / audits
• Checklist form for ease of use
• Rectification feedback loop
• Engender Risk Ownership at site level

16
Risk Engineering Self-Inspection
Simple tick box approach Quick and easy to
use Minimal training required Positive results
17
Risk Engineering Housekeeping
Poor housekeeping. Items also blocking easy
access to hose-reel and sprinkler
valvesets. Fire escape blocking?
18
Risk Engineering Housekeeping
Poor housekeeping. Workshop store area. General
untidieness and spilled oils.
19
Risk Engineering Smoking

• Discussion
• Key Points
• Still a major cause of fires
• Site ban vs Designated smoking areas
• Disposal of smoking material
• Formulate policy rules
• Audit effectiveness of policy
• Disciplinary Procedures for infringement

20
Risk Engineering Electrical

• Discussion
• Key Points
• Electricity at Work Regulations 1989 (EAWR)
• IEE BS7671
• Periodic Inspection Testing by competent
  person
• Visual examination (prior to testing)
• Testing
• Periodic Inspection Reports Certification
• Rectification of faults
• NICEIC approved contractors recommended
• (National Inspection Council for Electrical
  Installation Contracting)

21
Risk Engineering Electrical

• Recommended Initial Frequencies of Inspection
  (extract)

22
Risk Engineering Electrical
Thermographic Surveys Non-invasive / non-contact
diagnostic tool for checking Hot Spots on
electrical equipment.
23
Risk Engineering Electrical
Common fault found on 13Amp plug.
24
Risk Engineering Electrical
Who needs a plug anyway? Contractors extension
lead and plug.
25
Risk Engineering Cooking

• Deep fat frying
• Grease build up in extract ducting
• Need to consider following
• Filter cleaning
• Extract duct deep cleaning
• Fixed suppression system
• Power / fuel emergency shut down
• Staff training

26
Risk Engineering Cooking
Deep fat frying Resultant fires are difficult to
tackle manually. Extract duct-work is a route
for fire spread and can result in extensive loss.
27
Risk Engineering Protection
Portable Fire Extinguishers

• Are extinguishers located in accessible
  positions?

• Is the correct type of extinguisher available?

• Have staff received training / instruction in
  use?

28
Risk Engineering Protection
Automatic Fire Detection

• Different types of detector for different
  environment
• Recommend P1 / P2 type systems to BS
• Offsite signalling to approved Alarm Receiving
  Centre Recommend monitored BT RedCare Line
• Break Glass manual call points
• Fire alarms will notify you in the event of an
  activation and summon fire brigade where offsite
  signalling installed.

29
Risk Engineering Sprinklers

• Automatic Sprinklers

Fixed automatic sprinklers provide an excellent
means of controlling fire growth and have a
proven track record of significantly reducing
fire losses. Sprinkler systems should be
installed to recognised standard BS5306 Part 2
LPC Tech Bulletins prEN12845 LPC Tech
Bulletins
30
Risk Engineering Sprinklers

• Automatic Sprinklers
• Key Facts from British Automatic Sprinkler
  Association (basa)

• Fire brigades use up to 10,000 times more water
  to do same job as sprinklers.
• 99 of fires in sprinklered buildings controlled
  by sprinklers alone.
• 60 of fires in sprinklered buildings were
  controlled by 4 sprinklers or less.
• Accidental discharge of water according to LPC is
  1 in 500,000 per year of service (1 in 14m for
  manufacturing defects LPC FM)

31
Risk Engineering Sprinklers

• Sprinklers in Schools
• Relatively straightforward for a new build
• Retrofitting to existing schools requires careful
  planning to reduce disruption
• Malicious damage can be reduced by
• Using concealed heads above flush fitting
  ceiling plate
• Installing heads above an open grid suspended
  ceiling
• Installing any pumps and valvesets in a secure
  area
• Fitting protective guards to heads
• Experience with sprinklers in schools very
  positive

32
Risk Engineering Sprinklers
Metal guard protector on sprinkler head Guard
successfully prevented the head from being
damaged and causing water damage
33
Risk Engineering Sprinklers

• Worcester CC Report dated April 2004
• Quote From Sprinklers in Schools Other
  Council Buildings
• Conclusion (Key Findings)
• Sprinklers are an important safeguard.
  Installing sprinklers is
• therefore worthwhile, providing that the costs
  are contained
• and measured against risk. Further consideration
  needs to be
• given to existing measures and levels of training
  to relevant
• staff.

34
Risk Engineering

• AIG is committed to providing risk management and
  consulting products and services that make a
  difference for our customers and business
  partners.
• ISO90012000 accredited

35
ALARM

• Thank You
• Derick Milner
• Senior Risk Engineering
• Property Division
