Title: Intraoperative ECG Lead Placement


1
Intraoperative ECG Lead Placement
  • Brian Matthews SRNA
  • Nicholas Stoddard SRNA
  • David Perkins SRNA

2
Monitoring Basics
  • Impulse toward positive is an up swing away from
    positive is down.
  • J point, or junction point, is located at
    junction of S wave and start of ST segment.
  • ST segment is Measured 60 milliseconds from
  • the J point.
  • 1mm change from baseline suggests myocardial
    injury.

3
Leads Bipolar and Augmented Placement(Frontal
plane)
  • Bipolar leads read from negative to positive.
  • Bipolar leads are Lead I, II, and III also
    referred to as the limb leads.
  • Augmented leads read from center to specific
    lead and are unipolar.
  • Augmented leads are aVR, aVL, and aVF.

4
Precordial Lead placement (Horizontal plane)
  • Unipolar leads, reading from center to outward.
  • V1 right sternal boarder 4th intercostal space
  • V2 left sternal border 4th intercostal space
  • V3 halfway between V2 and V4
  • V4 left 5th intercostal space, mid-clavicular
    line
  • V5 horizontal to V4, anterior axillary line
  • V6 horizontal to V5, mid-axillary line

5
Which lead(s) is/are best?
6
Incidence/Indications
  • The pooled results from the studies evaluating
    patients who had or were at risk of cardiac
    disease suggest that 3.9 (95 CI 3.34.6) of
    these patients experience major perioperative
    cardiac events.

7
Cardiac Events in Noncardiac Surgery
8
London et al 1988
  • n-105 with CAD
  • Single lead monitoring unacceptable low
  • Leads II and V5 had 80 sensitivity
  • Leads II, V4, and V5 had a sensitivity of 96 for
    detecting ischemic events

9
Landesberg et al 2002
  • n-185 major vascular surgery
  • Continual 12 lead monitoring during surgery
  • We conclude that as a single lead, V4 discloses
    ischemia earlier, more frequently, and with a
    greater relative ST depression than the
    conventional V5
  • Two lead monitoring is required to approach 95
    sensitivity.

10
Martinez et al 2003
  • n-149 Post-op ICU
  • The majority of ischemia occurred in leads V2,
    V3, and V4, suggesting that the routine practice
    of monitoring leads II and V5 may not be optimal.

11
Martinez et al 2003
  • Given that in routine ICU care leads II and V5
    are usually monitored, we estimated that if all
    ischemic episodes occurring in either or both of
    these leads were detected, the maximal possible
    sensitivity of standard monitoring is 41 for
    detecting the first
  • episode of ECG evidence suggestive of prolonged
  • Ischemia

12
12-lead Fingerprinting
  • First and foremost, if a preoperative 12-lead
    ECG has been done, fingerprinting of the
    tracing should serve as the primary guide for
    lead selection during the perioperaive period.
    If the baseline 12-lead shows significant primary
    ST-segment changes in leads V3,V4 and V5, then
    this lead set should be prioritized for
    continuous display in the operating room.
    (Nagelhout, Plaus, 2010)
  • A preoperative resting 12-lead ECG is
    recommended for patients with at least one
    clinical risk factor who are undergoing vascular
    surgical procedures and for patients with known
    CAD, peripheral arterial disease, or
    cerebrovascular disease who are undergoing
    intermediate-risk surgical procedures. A
    perioperative ECG is reasonable in persons with
    no clinical risk factors who are about to undergo
    vascular surgical procedures and may be
    reasonable in patients with at least one clinical
    risk factor who are undergoing intermediate-risk
    operative procedures (Barash, et al. 2009)

13
Recommendations
  • If no pre-op 12 lead then monitor Leads II and
    V3/V4.
  • With pre-op 12 lead available and normal then
    the electrocardiographic lead with the most
    isoelectric ST level out of leads V3, V4, and V5
    on the preoperative electrocardiogram is
    recommended or monitoring of ischemia.
  • If 12 lead available with ST changes,
    fingerprinting, monitor those specific leads.

14
Works Cited
  • Barash, P, Bruce, C, Robert, S, Cahalan, M,
    Stock, M. (2009). Clinical anesthesia.
    Philidelphia Lippincott Williams Wilkins.
  • Devereaux, P, Goldman, L, Yusurf, S, Gilbert, K,
    Leslie, K. et al (2005). Surveillance and
    prevention of major perioperative ischemic
    cardiac events in patients undergoing noncardiac
    surgery a review. JMAC, 173(7), 779-788.
  • Landesberg, G, Mosseri, M, Wolf, Y, Vesselov, Y,
    Weissman, C. (2002). Perioperative myocardial
    ishecmia and infarction. Anesthesiology, 96,
    264-270.
  • London, M, Hollenberg, M, Wong, M, Levenson, L,
    Tubau, J. et.al.(1988). Intraoperative myocardial
    ishemia localization by continuous 12-lead
    electrocardiography. Anesthesiology, 69, 232-241.
  • Martinez, E, Kim, L, Faraday, N, Rosenfeld, B,
    Bass, E. (2003). Sensitivity of routine intensive
    care unit surveillance for detecting myocardial
    ischemia. Critical care medicine, 31(9),
    2302-2308.
  • Nagelhout, J, Plaus, K. (2009). Nurse
    anesthesia. St. Louis, Missouri W B Saunders Co.
