Dr Graham Ogg

1
Dermatological Danger
Dr Graham Ogg MRC Programme Leader,
Oxford Consultant Dermatologist
2
Cutaneous inflammatory patterns
3
Aim To understand role of human cutaneous T
cells in mechanisms of disease, treatment and
vaccination
exogenous antigens eg atopic
HLA class II
HLA class I
endogenous antigens eg varicella zoster virus
4
T cell recognises antigen presented by HLA class
I/II
TCR
CD4/CD8
HLA
5
HLA class II comprises 2 chains
6
T cell receptor and HLA class II
7
HLA class II
8
How does the antigenic peptide get to HLA class
II?
9
Endosomes fuse with vesicles containing
proteolytic enzymes
10
These fuse with vesicles containing receptive HLA
class II
HLA class II
Invariant chain
11
Each HLA class II binds peptides carrying
preferred motifs
12

• CD4 T cell recognition of target cell leads to
• Cytokine production
• Proliferation of T cell (clonal expansion)

Th2
vs
Th1
IFNg production CD8 T cell help Macrophage
activation IgG class switching
IL-4 production IgE class switching Eosinophil
recruitment
13
HLA class I
14
T cell receptor/HLA class I
T cell receptor
MHC class I
15
HLA Class I (T cell receptor view)
16
HLA class I antigen presentation
proteasome
17
Some degraded peptides enter the endoplasmic
reticulum
18

• CD8 T cell recognition of target cell leads to
• Lysis of target cell
• Cytokine production
• Proliferation of T cell (clonal expansion)

19
ELISpot can be used to detect cytokine secreting
cells
positive control
negative control
pep 4
pep 12
Bateman et al JACI 2006
20
HLA-peptide tetrameric complexes
Ogg et al Science 1998 Champagne/Ogg et al Nature
2001 Seneviratne et al J Clin Invest 2002
21
HLA tetramers allow us to look at T cells that
are specific for a particular antigen
Tissue
Blood
22
Cells in the skin that might present antigen to T
cells
Keratinocytes Fibroblasts Melanocytes Others
Langerhans cells Dermal dendritic
cells Keratinocytes (under inflamm conditions)
HLA class I
HLA class II
23
Atopic dermatitis (eczema)

• Cumulative prevalence up to 15-20
• Onset usually by age 2-6 months
• 50-75 of children clear by age 10 years
• 50 have associated asthma and/or hayfever
• Staphylococcus aureus presence common (cf
  impetigo)
• 80 have IgE and/or skin test reactivity to
  common environmental allergens
• FLG null mutations common

24
Atopic dermatitis genetics and environment

• Genome screens detected linkage to eg 3q21, 1q21,
  17q25 and 20p (similar to psoriatic
  susceptibility loci). Numerous candidate gene
  analyses eg FceRI, IL-4, IL-10, IL-13, SPINK5,
  TLR2.
• Null mutations in FLG are commonly associated
  with atopic dermatitis

Palmer et al Nature Genetics 2006
25
Filaggrin expression is variable and is inhibited
by Th2 cytokines
Howell et al JACI 2007
26
Severe atopic dermatitis is associated with
common FLG null mutations in our cohort
Cohort 2282del4 hetero 2282del4 homo R501X hetero R501X homo Total gt1 null mut
32 3 0 3 2 8
27
Working model of disease
Barrier
Allergen
Infection
28
Individuals with atopic dermatitis have high
frequencies of circulating allergen-specific Th2
cells
Non-atopics
Atopics
Der p 1 peptides
29
Allergen-specific CD4 T cells proliferate in
vitro
Ex vivo
Cultured ELISpot
Ardern-Jones et al 2007 PNAS
30
T cell epitope hunting
31
HLA-peptide tetrameric complexes
Ogg et al Science 1998 Champagne/Ogg et al Nature
2001 Seneviratne et al J Clin Invest 2002
32
Individuals with atopic dermatitis have higher
frequencies of circulating Der p 1-specific CD4
T cells than non-atopics (short term culture)
PATIENTS
CONTROLS
1.65
5.3
0.02
CD4
AD5
AD18
A
2.34
0.54
0.01
AD9
AD10
A
9.9
0.44
0.03
AD6
N
AD14
0.02
19.13
0.29
AD22
J
AD25
Tetramer
33
What about other forms of barrier compromise
34
Wasp venom specific T cells responses
Aslam et al Clin Exp Allergy 2006
35
Dominant T cell antigens within wasp venom are
co-incident with main IgE binding proteins

• Hyaluronidase
• Antigen V
• Phospholipase

Aslam et al CEA 2006
36
Mapping Ves V5 epitopes
37
(No Transcript)
38
Antigen-specific CD4 T cells infiltrate skin
after antigen challenge
PBMC
Skin
0.04
10
DRB11501/IE63 tetrameric complex
39
IFNg increases class I, class II and ICAM-1
expression by keratinocytes
40
IFNg treated keratinocytes can engulf fluorescent
latex particles
41
IFNg treated keratinocytes can present antigen to
CD4 T cells using either peptide or recombinant
protein
Black et al EJI 2007
42
Keratinocyte killing
43
(No Transcript)
44
Increase in number of IL-4-producing T cells
using combined stimulation of Der p 1-specific
line with peptide and Staphylococcal enterotoxin B
sfu/40,000 cells
stimulus
45
Supernatant from SEB/PBMC enhances antigen
presenting capacity of keratinocytes
46
IFNg within supernatant of SEB-treated PBMC
enhances class II and ICAM-1 expression by
keratinocytes and enhances presentation to
allergen-specific CD4 T cells
Ardern-Jones et al
47
Depletion of IFNg from supernatant of SEBPBMC
diminishes ability of supernatant to promote
keratinocyte presentation of peptide
48
IL-4 depletion significantly reduces the
production of cytokines by allergen-specific CD4
T cells
Ardern-Jones et al
49
SEB-reactive T cells produce IFNg and IL-4 which
enhances responsiveness of allergen-specific T
cells
Allergen-specific T cell
SEB-reactive T cell
IL-4
IFN-g
SEB
50
(No Transcript)
51

• Conclusions
• FLG mutations associate with increased
  circulating airborne allergen-specific Th2 cells.
• FLG mutations do not associate with circulating
  wasp venom-specific Th2 cells.
• These suggest that barrier factors plus Th2
  susceptibility important for allergic responses.
• Keratinocytes can promote Th2 responses
• Antigen-specific CD4 T cells can infiltrate
  skin
• Combined presence of S.aureus and allergen
  enhances allergic inflammation.
• Handling of concurrent adjuvant is likely to be
  an important co-factor in determining Th1/Th2
  response to a given antigen
• MRC Experimental Medicine proof of concept
  clinical trial

52
Acknowledgements
Louise Jones Neelika Malavige Antony Black Tess
McPherson Aamir Aslam Michael Ardern-Jones Laura
Crack Hsien Chan Carol Hlela Elizabeth Bateman
UCL
Milica Vukmanovic-Stejic Arne Akbar
Funding MRC NIHR
