Advanced Algebra Chapter 13

1
Advanced Algebra Chapter 13

• Trigonometric Ratios and FUNctions

2
Right Triangle Trigonometry13.1
3
Getting Started

• The Greek Alphabet!

4
Getting Started

• Right Triangles
• Sides
• Hypotenuse
• Adjacent
• Opposite
• Angles
• Right Angle
• Theta
• Other angle
• The sum of all angles in any triangle is

5
Getting Started

• What else do we know about right triangles?
• There was a guy with a theorem!

6
Trig

• Six Trig functions
• Sine
• Cosine
• Tangent
• Cotangent
• Cosecant
• Secant

7
Trig FUNctions
8
Soh Cah Toa
9
Trig FUNctions
10
Evaluate all six trigonometric FUNctions for the
given triangle
11
Evaluate all six trigonometric FUNctions for the
given triangle
12
Evaluate all six trigonometric functions for the
given triangle
13
Angles of Elevation or Depression

• Elevation
• Looking Up
• Depression
• Looking Down

14
Angles

• A support cable from a radio tower makes an angle
  of 56 degrees with the ground. If the cable is
  250 feet long, how far above the ground does it
  meet the tower?

15
Angles

• An airplane flying at 20,000 feet is headed
  toward an airport. The landing systems sends
  radar signals from the runway to the airplane,
  recording a 5 degree angle of elevation. About
  how many miles is the airplane from the runway?

16
p.77215-40
17
General Angles and Radian Measure13.2
18
Define

• Angle
• Formed by two rays sharing a common endpoint
  known as the vertex

19
Standard Position

• Standard Position
• Initial Side
• Terminal Side
• Positive v. Negative

20
Angles

• 210 degrees

21
Angles

• -45 degrees

22
Angles

• 30 degrees
• -330 degrees
• 390 degrees
• Coterminal Angles

23
Finding Coterminal Angles

• Two angles are coterminal iff one angle can be
  found my adding or subtracting multiples of 360
  degrees

24
Coterminal Angles

• Find 2 positive and 2 negative angles coterminal
  to the following
• 70 degrees
• 115 degrees
• -5 degrees

25
Circles

• What if we think about distance around a circle
  as a total of its angles?
• Circumference of a circle
• So,

26
Circles
27
The Unit Circle
28
Converting from one to another

• 1 Radian is how many degrees
• Rewriting Degrees as Radians
• Rewriting Radians as Degrees

29
Converting

• Convert 110 degrees to radians

30
Converting

• Convert radians to degrees

31
Why Radians?

• Work great with circles
• Already in terms of circumference so finding arc
  length is easy
• Whats arc length?
• Arc length (s) is the distance around a portion
  of a circle called a sector
• Whats a sector?
• Is a region of a circle bounded by two radii and
  the arc of the circle
• The angle formed is called the central angle

32
Arc Length and Area of a Sector

33
p.78028-58 Every 3rd
34
Trig FUNctions of Any Angle13.3
35
Consider our Unit Circle again

• Make a list of all of the x- and y-values
• What do you notice about these?
• What about pos/neg?
• Well come back to this

36
Consider our Unit Circle again

• Could we find a short cut to this stuff?
• In other words, do we need the entire circle?

37
Consider our Unit Circle again

• Everything we need happens in the 1st quadrant!
• So, we use reference angles
• Reference angle
• Acute angle formed by the terminal side of the
  angle and the x-axis
• i.e. use the shortest distance to the x-axis as
  your reference angle

38
Find the reference angles for

39
Why reference angles and ordered pairs?

• When on the unit circle
• Y-values Sine values!
• X-values Cosine values!

40
Define trig functions as





41
Signs of Trig Functions
Quadrant Positive Functions Negative Functions
I All None
II Sin, csc Cos, sec, tan, cot
III Tan, cot Sin, csc, cos, sec
IV Cos, sec Sin, csc, tan, cot
42
Signs of Trig Functions
All Students Take Calculus
All
Sine
Tells us which values are positive
Tangent
Cosine
43
Using reference angles

• Find the sin of the following

44
Using reference angles

• Find cos of the following?

45
Using reference angles,

• Find tan of the following

46
p.78834-36, 38-60 Even
47
Inverse Trig FUNctions13.4
48
Domain and Range

• Domain
• The numbers you plug IN to a function
• Range
• The numbers you get OUT of a function

49
Inverse FUNctions

• To get an inverse, we switch the domains and
  ranges!
• For our new function
• The old range becomes our new domain
• The old domain becomes our new range

50
Inverse FUNctions

• Consider the sine function
• Domain
• Range
• How about inverse sine or
• Domain
• Range

51
Inverse FUNctions

• Consider the cosine function
• Domain
• Range
• How about inverse cosine or
• Domain
• Range

52
Inverse FUNctions

• Consider the tangent function
• Domain
• Range
• How about inverse tangent or
• Domain
• Range

53
Inverse

• Evaluate the following expression

54
Inverse

• Evaluate the following expression

55
Inverse

• Evaluate the following expression

56
Inverse

• Solve the equation where

57
Inverse

• Solve the equation where

58
p.79522-31,41-47
59
The Law Of Sines13.5
60
Why?

• Allows us to find missing parts of triangles that
  are NOT right triangles
• Often more practical then breaking triangles down
  into separate parts to get right angles

61
Law of Sines

• In any triangle the lengths of the sides are
  proportional to the sines of the corresponding
  opposite angles

62
The Law of Sines
63
Solving Oblique Triangles
64
Why SSA??

• Cant use for congruence or similar triangles BUT
  we can use SSA using the law of sines
• SoWe need to be careful!

65
Law of Sines
66
Law of SinesThe Ambiguous Case
2 solutions
67
Law of SinesThe Ambiguous Case

• No Solution

68
Law of SinesThe Ambiguous Case
Unique Solution
69
The Ambiguous Case

• When can it exist?
• When the given angle is less than 90 degrees
• Ex Angle A 40 degrees, side a 18, side b 25

So B 63 or B 180-63 117
70
The Ambiguous CaseCase 1
Angle B is 63 degrees so
71
The Ambiguous CaseCase 2
Angle B is 117 Degrees
72
Area of a Triangle

• The area of any triangle is given by one half the
  product of the lengths of any two sides times the
  sine of their included angle

73
Area of a triangle
74
Area of a triangle
75
p.80427-36,47-52
76
The Law of Cosines13.6
77
The Law of Cosines
78
The Law of Cosines

• Advantage of The Law of Cosines?
• Do not need to know an angle
• NOW we can use SSS

79
The Law of Cosines
80
The Law of Cosines
81
The Law of Cosines
82
Law of Sines or Cosines?

• Sines is much easier, however we cant use it all
  the time
• Use law of cos when you have to
• Otherwise, you can use law of sines

83
Herons Formula

• The area of the triangle with sides of length a,
  b, and c iswhere
• The variable s is called the semiperimeter, or
  the half perimeter of the triangle

84
Herons Formula
85
p.81015-45 Ev 3rd
