MEDICAL MYSTERIES

1
MEDICAL MYSTERIES

• Using Hematology Instrument Data to Troubleshoot

DR PETER JOHN LOGA, PhD MS MSc BSc SDMLT
DMLT FIBMS FZIMLS
2
OBJECTIVES

• Review instrument technology compare contrast
  normal vs abnormal
• Apply this technology / knowledge to a variety of
  cases
• SOLVE the medical mystery

3
(No Transcript)
4
PROVEN BECKMAN COULTERTECHNOLOGIES
5
The Coulter Principle
Vacuum
Detail of Aperture
Aperture Current Pathway
Internal Electrode
External Electrode
Suspension of Cells
External Housing (Aperture Bath)
Aperture
Aperture Housing
6
Aperture Impedance SystemSystem with Sweep Flow

• Eliminates recirculation of cells
• Cells pushed away by diluent
• More accurate counts

7
Coincidence Correction

• Electronic pulse-editing coincidence
  correction
• Provides accurate histograms and cell sizing for
  reliable RBC and PLT indices

Pulse to be edited
Diluent stream
8
Aperture Impedance System

• Triplicate Counting
• Ensures Precision
• Reduces Repeats

9
The Coulter Principle
A red cell passes through RBC aperture
Red Blood Cell
Sensing Zone
Oscilloscope
10
RBC HISTOGRAM
NORMAL
11
RBC HISTOGRAM
MACROCYTIC, TARGET CELLS, DI RBC
COLD AGGLUTININ
DI RBCs
Post Transfusion
RBC FRAGMENTS, MICROCYTIC RBCs, Giant PLT
12
PLT HISTOGRAMS
NORMAL
13
PLT Curve Fitting

• The Curve Fitting Process Allows More Accurate
  Counts When Platelets of Larger Than 20 fL Are
  Present

14
PLT Counting Sizing

• Coulter impedance counting has a PATENTED CURVE
  FITTING process that is used in conjunction with
  WBC histogram review for platelet clump and giant
  platelet flags

15
PLT HISTOGRAMS

• Giant Platelets

• Small Platelets

16
The Coulter Principle
A white cell passes through WBC aperture
Neutrophil
Sensing Zone
Oscilloscope
17
Coulter WBC Histogram
Monos 90 -160 fL
Neuts 160 - 450 fL
Lymphs 50 90 fL
Eos
Baso
18
WBC HISTOGRAMS
ImmNE1 ImmNE2
Lymphocytosis
Variant Lymph
ImmNE2
Eosinophilia
Blasts
19
WBC Interference

• Percentage of interference analyzed for
  statistical significance
• Flagging based on all three histograms instead
  of one
• Histogram positional parameters used for further
  definition

Cellular Interference
20
AccuCount Technology

• LH700 Series
• WBC 0 400,000
• RBC 0 8,000,000
• HGB 0 - 25
• PLT 0 3,000,000
• AccuCount WBC and AccuCount Plt Counts have been
  validated by Reference Flow Cytometry

21
VCS TECHNOLOGY

• Automated Differential Analysis

22
Near Native WBC Analysis

• Red Cells Removed From Sample Dilution Using a
  Lytic Process
• Second Agent Prevents Alteration of the White
  Cells
• Hydrodynamically Focused Flowcell
• Laminar Flow Ensures Single File Cell Passage
• Coincidence Effects Are Minimized

23
Flow Cytometry

• Technique for counting, examining and sorting
  microscopic particles suspended in a stream of
  fluid. It allows simultaneous multiparametric
  analysis of the physical and/or chemical
  characteristics of single cells flowing through a
  detection apparatus.

24
BioPhysical Flow Cytometry

• Cells are hydrodynamically focused
• An electro-optical flow cytometer provides
  concurrent electronic and optical measurements

25
The Triple Transducer Module
RF Detector Pre-Amp
Laser
Lens Block
Flow Cell
LS Sensor
Light Scatter Pre-Amp

• A major advance in technology
• An electro-optical flow cytometer
• Provides concurrent electronic and optical
  measurements

26
VCS Technology
Volume
Total Cell Volume
Total Cell Volume
Nuclear Volume Nuc/Cyto Ratio
Cell Surface Characteristics
Light Scatter
Conductivity
27
The 3-D VCS Scatterplot
NUCLEAR SHAPE AND COMPOSITION
GRANULES
CYTOPLASM
CELL SIZE
28
COULTER VCS TECHNOLOGY

• VOLUME SIZE
• CONDUCTIVITY INTERNAL COMPOSITION
• LIGHT SCATTER CELL SHAPE / SURFACE

29
VOLUME

• DC Measures Total Cell Volume Using the Reference
  Method of Direct Current Impedance
• Unaffected by cell orientation

30
CONDUCTIVITY

• RF Measures Internal Cell Structure Using
  Radiographic Imaging Similar to Ultrasound
• Conductivity Is a Proprietary Technology

31
LASER LIGHT SCATTER

• Light Scatter Measures Cell Surface Granularity
  Using a Broad Range of Angles. Over 60 angles of
  light scatter are analyzed.

32
3-D Cellular Analysis - VCS
VOLUME (Y)
CONDUCTIVITY (Z)
LIGHT SCATTER (X)
The 3 probes (DC, RF and Scatter)
interrogate each of the 8192 cells simultaneously.
Every cell is treated in the same manner and
each cell is given an X, Y, and Z coordinate
on the dataplot with 16 million points in the
matrix.
ALL cell populations are DIRECTLY measured
33
AccuGate Software Technology

• Population Boundaries Curve Around Clusters
• Overlapping Clusters Are Separated
• Each Population Is Independently Categorized
• Rare Event Clusters Are Easily Identified
• Older samples more accurately evaluated

34
Better Abnormal Cell Detection

• 1 Mono-Blasts
• 2 Myelo-Blasts
• 3 Immature Granulocytes
• 4 Band Neutrophils
• 5 Lympho-Blasts
• 6 Variant Lymphocytes
• 7 Low Volume Lymphocytes
• 7a NRBCs
• 8 PLT Clumps
• 9 Giant Platelets
• 10 RBC Parasites (Malaria, etc)

35
DIFF TECHNOLOGY
36
CONFUSED????
37
NORMAL
38
NORMAL
39
NORMAL DATAPLOT
MONOCYTES
NEUTROPHILS
EOSINOPHILS
V O L U M E
BASOPHILS
LYMPHOCYTES
NRBC, PLT CLUMPS, GIANT PLT, MALARIAL PARASITES,
DEBRIS, ETC
C O N D U C T I V I T Y
S C A T T E R
40
CUBE ROTATION
VOLUME
CONDUCTIVITY
SCATTER
VOLUME
RED VOLUME SIZE GREEN SCATTER
SURFACE BLUE CONDUCTIVITY INTERNAL
SCATTER
CONDUCTIVITY
41
LH 700 SeriesThe 6-Part Diff
NRBC enumeration automatic with differential

• Fully automated
• No reflex or repeat testing required
• No additional reagent packs required
• WBC count
• automatically corrected

42
Decision Rules
UNLIMITED RULES!
4 Rule Types
And/Or Joins
Automatically Make Slide
Message-Action To Be Taken
43
Research Population Data (RPD)

• When VCS 3D Dataplot is optimized
• There is a change in the WBC Research Population
  Data
• This appears to correlate with the presence of
  abnormal cells in previously undiagnosed patients

44
Research Population Data
Mean and SD are typically consistent from one
normal population to the next
45
Research Population Data
NE1
The increasing SD corresponds to a more immature
population of cells
46
Research Population Data (RPD)

• WBC Research Population Data has been studied in
  the following clinical cases
• CLL
• Left Shift
• Malaria
• Lymphoproliferative Disorders
• Myelodysplasia
• Sepsis

47
CLINICAL APPLICATION
Steve Marionneaux Laboratory Manager The Saint
Vincents Comprehensive Cancer Center New York,
New York
48
MYSTERY 1
49
CBC Results8 Year Old Female
50
DataPlot Results
51
MANUAL DIFF RESULTS
MANUAL DIFF Seg 20 Band 2 Lymph 51 Blast
27
52
Diff Cube Rotation
VOLUME
VOLUME
SCATTER
CONDUCTIVITY
SCATTER
CONDUCTIVITY
PRE-B CELL Acute Lymphoblastic Leukemia
53
PRECURSOR B-CELL ALL

• Low WBC, neutropenia
• Anemic
• Mononuclear population with smooth chromatin
• CD34, TdT population

54
MYSTERY 2
55
WBC PLTHISTOGRAMSAUTODIFF RESULTS
56
RBC HISTOGRAM
57
CBC / RBC RESULTS
58
MYSTERY 3
59
46 Year Old Female
60
46 / Female
61
Acute Promyelocytic Leukemia (Microgranular)
VOLUME
CONDUCTIVITY
SCATTER
MANUAL DIFF Lymph 2 Mono 1 Blast 97
CONDUCTIVITY
SCATTER
62
MYSTERY 4
63
Medical Mystery 4
64
Chronic Lymphocytic Leukemia
MANUAL DIFF Seg 6 Lymph 92 Mono 2
65
CLL WITH SMUDGE CELLS
66
CHRONIC LYMPHOCYTIC LEUKEMIA

• Typically gt60 years of age
• Initially asymptomatic
• Increased WBC
• Increased of small, normal lymphs (as disease
  progresses, more immature lymphs appear
• Smudge cells

67
MYSTERY 5
68
12 Month Old Male
HGB 7.0
69
12 Month Old Male
RBC Morphology 2 Poik 3 Aniso 4 Hypo 4
Micro 1 Target 2 Ellipto 1 Teardrop 1
Poly
70
MANUAL DIFF Seg 42 Lymph 46 Mono 5 Eo
5 Baso 2 NRBC 1
71
?????
Iron Deficiency Thalassemia
72
RETIC RESEARCH POPULATIONS
Sickle Thalassemia Low Volume Lymphs CLL

73
MYSTERY 6
74
Case Study History

• 74 year old female
• 20lb unexplained weight loss
• Fever
• Malaise
• Sore throat
• Muscle aches

2 weeks duration
75
Blasts or large lymphs
HISTOGRAM DATA
76
Auer rods are defined as a coalescence of the
azurophilic granules and are only seen in
non-lymphocytic leukemias
???????
AUER ROD
77
Manual Differential

• Seg 4
• Band 1
• Lymph 17
• Mono 3
• BLAST 75 w/ occ Auer rod

78
ACUTE MYELOCYTIC LEUKEMIA

• Sudden onset
• Anemic
• Variable WBC
• Decreased PLT count
• gt10 Blasts in peripheral blood
• Special Stains Flow markers for myelogenous
  cell lines

79
FLOW CYTOMETRY DATA PLOTS
CD45 is a generic marker for all cell lines.
CD117 is considered a myelocytic marker. If a
patient is positive for this marker, they are
considered a good candidate for a newer
chemotherapeutic drug called GLEVEC.
80
IMMUNOPHENOTYPIC RESULTS

• 60 population of myeloid blasts
• CD34 CD11b (partial)
• CD64, CD33, CD15, CD56
• CD117, MPO
• Negative for HLA-DR, CD7, CD19, CD20, CD22, CD3,
  CD8, and TDT

81
MYSTERY 7
82
Case StudyHistory

• 83 year old male
• Unexplained weight loss
• Malaise
• Night sweats
• Slight hepatosplenomegaly

83
(No Transcript)
84
(No Transcript)
85
LAB RESULTS

• Manual Diff
• Seg 33
• Band 15
• Lymph 19
• Mono 6
• Meta 11
• Myelo 10
• Blast 6

86
???
87
VCS 3-D Data Plot

• Neutrophil Series
• Neutrophils
• Bands
• Metas
• Myelos
• Pros
• Ne Blasts

88
VCS 3-D Data Plot

• Monocytes
• Monoblasts

89
FLOW CYTOMETRY DATA PLOT
CD14 CELLS
CD14 Monocytic Cells
90
FLOW CYTOMETRYPATHOLOGIST INTERPRETATION

• The immunophenotypic findings reveal increased
  monocytes (26) and 52 granulocytes with a shift
  toward immaturity and diminished side scatter.
  There is no evidence of increased blasts, a
  monoclonal B cell or aberrant T cell process.
• The immunophenotypic findings are suggestive of a
  myeloproliferative process. Acute monocytic
  leukemia cannot be entirely excluded. Clinical
  pathologic correlation is required for final
  diagnosis.

91
MYELOPROLIFERATIVE DISORDERS

• Defined as a hypercellular bone marrow with
  increased quantities of one or more of the cells
  lines erythrocytes, leukocytes or platelets in
  the peripheral blood.
• It is thought to be a neoplastic, clonal
  proliferation of a single multipotential stem
  cell w/ one cell line predominating and often
  transforming into another.

92
SUMMARY

• Look at ALL the information provided by the
  instrument
• CBC parameters
• WBC Histograms
• RBC Histograms
• PLT Histograms
• Dataplots
• Suspect Flags
• Research Parameter

93
SUMMARY

• Combine this information with what you see at the
  microscope
• Ask for a second opinion from a peer
• Create an abnormal file

SAVED LIST FOLDER
94
Questions ???????
95
ANY QUESTIONS
96
Case Study History

• 14 year old female
• Hgb SS
• Asthmatic
• Admitted in crisis

97
Lab Results

• CBC Results
• WBC 11.5 corrected for NRBCs
• RBC 2.10
• HGB 6.6 corrected for icterus
• PLT 349
• RDW 25.4

• Morphology
• 3 Aniso
• 3 Poik
• 2 Poly
• 3 Sickle
• 3 Pappenheimer Bodies
• 1 Target Cells

98
Lab Results

• Chemistry
• Glucose 104
• Sodium 142
• Potassium 3.9
• BUN 3 L
• Creatinine 0.5 L
• CO2 28
• Chloride 108
• Calcium 8.3

99
Sickle Cell Pappenheimer bodies
100
Cellular interference with corrected and
uncorrected WBC
101
NRBCs Giant platelets Platelet clumps RBC
fragments Lyse resistant RBCs Malaria very small
lymphs
Manual Differential 55 Seg 1 Band 36 Lymph 7
Mono 1 Eo 6 NRBC
102
NRBC Enumeration Cells must be present in BOTH
the signature position of the scatterplot as well
as a population of events consistent with NRBCs
at 35fl on the WBC threshold.
Threshold Interference
Signature Position
103
Derivation of NRBCs

• WBC Histogram
• Presence of high take-off
• Standard deviation and shape of lymphocyte
  population
• Lymphocyte mean channel

THE WBC IS ONLY CORRECTED FOR NRBCs gt35fl

• VCS Dataplot
• Volume and light scatter mean channels
  differentiate suspected NRBCs from lyse resistant
  RBCs
• Conductivity channel differentiates NRBCs from
  PLT clumps and giant platelets

104
RETICULOCYTE COUNT
WBCs
Retics
Mature RBCs
Platelets/Debris
105
Sickle Cell Disease

• Leukocytosis
• Howell-Jolly Bodies
• Increased NRBCs
• Increased bilirubin
• Numerous Target cells

• Anemia
• Numerous sickle cells
• Pappenheimer bodies
• Retic 10-40
• Hgb Electrophoresis
• Hgb S (gt50)
• Hgb F (variable)

106
medical
technologists
107
Research Population Data
NE2
The increasing SD corresponds to a more immature
population of cells
108
Research Population Data
NE BLAST
The increasing SD corresponds to a more immature
population of cells
109
Bonus - RBC Grading

• Accurately measure MCV
• Accurately measure RDW
• Detect dimorphic populations

• Graded RBC morphology
• Anisocytosis , ,
• Microcytosis , ,
• Macrocytosis , ,
• Hypochromia , ,
• Dimorphic RBC Population
• Micro RBCs/RBC Fragments
• RBC Agglutination
