Presentation Dagin Marine Technology

1
(No Transcript)
2
DAGIN Marine Technology
WWW.DAGIN.NL

• Group of 7 Dutch companies, very experienced in
  the shipbuilding industry.
• Design and production of advanced goods,
  valuable for many types of ships.
• Synergy and cooperation to the advantage of our
  customers.

3
DAGIN Marine Technology
WWW.DAGIN.NL
The associated companies

• 1. Börger
• 2. Benes Machinefabriek
• 3. Eefting Engineering
• 4. Eekels Elektrotechniek
• 5. Gebr. De Haan
• 6. SMST Rodenstaal
• 7. Scheen

4
DAGIN Marine Technology
WWW.DAGIN.NL

• In 2008
• gt600 employees
• Turnover gt100 mill. Euro

5
DAGIN Marine Technology
Reference list (Partial)

• Owner Yard
• Arklow Shipping, Ireland Barkmeijer Stroobos
• Wijnne Barends, Netherlands Niestern Sander
• Hartmann, Germany Schlömer Leer
• Seatrade, The Netherlands Van Diepen
• Amasus Shipping, The Netherlands Damen Shipyards
• Many owners in Netherlands and abroad Peters
  Kampen
• Spanish Navy IZAR Spain
• Dutch Navy De Schelde
• Feederlines, Germany Damen Shipyards
• Carisbrooke Shipping Damen Shipyards
• Arpeni, Indonesia Volharding Shipyards
• Royal Boskalis Westminster , Netherlands Merwede
• Bockstiegel, Germany Jiong Dong Shipyard, China
• UK Navy Kvaerner Govan
• Rensen Shipbrokers Hong Ha, Vietnam
• Several owners via Conoship, Netherlands Chowgule,
  India
• Partenreedereien, Germany Bahrati, India

6
boot
7
Börger
WWW.MF-BORGER.NL

• Börger manufactures a wide range of standard
• and tailor-made products
• -Ladders, Stairs, Platforms
• -Gangways
• -Hatches and Louvers
• -Watertight doors
• -Oiltanks
• -Bollards
• -Masts
• -Housings
• And many more products

8
Börger
WWW.MF-BORGER.NL

• Deliveries to many types of vessels
• Well known for exact delivery times
• High quality
• Strong in supplying complete packages
• Steel, stainless steel, aluminium
• Competitive prices

9
Engine Room Floors
10
Hatches
Doors
Stairs and Ladders
11
Benes Machinefabriek
WWW.BENESGROEP.NL

• Internationally renowned for the design
• and production of manoeuvring modules with
• many types of rudders like
• (Semi-)Spade Rudders
• Balanced rudders
• Flaprudders (High Lift)
• Fish-Tail Rudders
• and many more

12
Benes Machinefabriek
WWW.BENESGROEP.NL

• Complete ruddersections with
• rudderstock, trunk, fairwater,
• machined for all types of rudder-actuator.
• Sternrollers, winches and all kinds of
• other general constructionwork.

13
Benes Machinefabriek
WWW.BENESGROEP.NL

• Strong in designing the best steering
• solutions for your vessel
• More than 85 years experience
• Thousands of rudders and sections
• Other steel constructions
• Many satisfied customers all around the world

14
FLAPRUDDERS
MV NAUTIC with Flaprudder
15
Production of flaprudder make Barke
Classic Balance Rudder
Flaprudder
Sterntube
16

Fishtail rudder
Flaprudder
Machining
Trunk, Fairwater
Machining shaft
17
Eefting Engineering
WWW.EEFTINGENGINEERING.NL

• Eefting Engineering is specialised in (heavy)
  fuel
• oil systems (Booster Units)
• Compact modules with dual pipe connections.
• Easy access to valves and necessary equipment
• Clear control panels
• Different types of heaters - steam
• - electrical
• - thermal oil

18
Eefting Engineering
WWW.EEFTINGENGINEERING.NL

• Holding 15 of the European market
• Competitive in price and quality
• High standard
• Reliable

19
Eefting Engineering
WWW.EEFTINGENGINEERING.NL

• Conversions (MDO to HFO) are also possible
• Compact modules for a.o. oil, water separators
• etc.

20
EEFTING ENGINEERING
Heavy Fuel Booster Units
Tested, ready for delivery
21
Finishing and testing
22
Eekels
WWW.eekels.com

• a history of more than 100 years of experience in
  the field of installation work.
• - Installations in the range of inland navi
  gation till highly specialised sea ships.
• - Consultancy, design, maintenance, service,
  inspection

23
Eekels
www.eekels.com

• Eekels Elektrotechniek BV designs and produces
  Eekels made
• Switchboards
• control- and signalling panels
• motor control centers (MCC)
• control desks and alarm installations
• according to customers specifications or Eekels
  standard profile

24
Eekels
www.eekels.com

• alarm systems equipment (Eekels)
• automation (Eekels)
• ballast pump (Eekels)
• bilge pump (Eekels)
• bow thruster control unit (Eekels)
• control systems (Eekels)
• converters (Eekels)
• engineering (Eekels)
• frequency converter (Eekels)
• power management (Eekels)
• repair services (Eekels)
• ship's telegraphs (Eekels)
• switchboard (Eekels)
• telegraph, emergency (Eekels


25
Cabinet
Frequency converters
26
MV ALTENA
27
Gebr. De Haan
WWW.DEHAANHVAC.NL

• De Haan is well known in many countries for
• their expertise in the field of HVAC.
• De Haan can supply the engineering and
• assembly kits of the complete HVAC and sanitary
• systems on board of ships and mega-yachts

28
Gebr. De Haan
WWW.DEHAANHVAC.NL

• De Haan exports to various countries in
• Europe and Asia.
• - Engineering ( AutoCad / Nupass Cadmatic )
• Supply of complete systems
• Supply of components and units
• Support during installation
• Commissioning
• Turn-key projects by De Haan

29
Self contained AC-unit
Hydrofore
AC-unit in engine room
30
Sanitary Equipment
Mist Eliminator
31
Commissioning
Workshop
References
32
SMST Rodenstaal
WWW.SMST.NL

• Well known manufacturer and designer of all kinds
• and types of ships hatches, like
• Hydraulic Folding
• Single pull
• Pontoon
• StackPack
• Tweendeck hatches
• Grain Bulkheads

33
SMST Rodenstaal
WWW.SMST.NL

• SMST Rodenstaal can design and engineer all types
  of
• hatches for your ship.
• The choice is for the customer to decide where to
• produce the hatches
• At the yard
• At another steel construction company
• At SMST Rodenstaal

34
SMST Rodenstaal
WWW.SMST.NL

• When SMST Rodenstaal supplies design and
• engineering they also deliver the necessary
  parts
• cleats, rubber, cylinders etc.
• We also deliver the gantry crane when pontoon
• hatches will be chosen.

35
Special design hatches
Folding Hatches with close up of cylinders
36
Folding Hatches
Hatch cover crane
Hatch cover crane
Three ships in the Eemshaven with RODENSTAAL
Hatches
37
SMST Rodenstaal
WWW.SMST.NL

• SMST Rodenstaal is also well known supplier of
• Navy hangar doors
• Navy hull and stern doors
• Navy fly deck hatches
• Equipment for Jack-ups, Drillships
  Semi-submersible Rigs
• Pipelay equipment
• Exploration and production equipment

38
Offshore products
39
Navy equipment
40
Scheen bv
WWW.SCHEENBV.NL

• Core-business of Scheen bv is the interior- and
• shipboarding.
• Besides that the company makes furniture of all
• kind for every shiptype and every room or cabin
  in
• the ship.

41
Scheen bv
WWW.SCHEENBV.NL

• - Furniture.
• Cupboard- and ceiling system and inner doors.
• Insulation sets and draughtmanship.
• Sub floors according to class set-up.
• Upper floors.
• Decoration.

42
Scheen bv
WWW.SCHEENBV.NL

• One of the oldest specialities of Scheen is the
• boarding of yachts.
• As a result it is possible to get the highest
• standards for merchant vessels as well combined
• with the best prices.

43
Bridge furniture
44
Messroom
45
Member of Holland Marine Equipment

• Holland Marine Equipment (HME) represents the
  interests of the Dutch suppliers of marine
  technology and services. Core activities are
  networking, projectmanagement, member events, and
  government contacts. The member companies are
  active in the fields of maritime engineering
  contracting, fabrication of installations and
  components, the supply of maritime services and
  ship repair. New members are carefully screened
  on their reputation in the marine sector before
  they may enter the association.
• For more information about Holland Marine
  Equipment please visit www.hme.nl
• We are proud to be one of the members of HME.
  Please take a look at our HME-certificate at the
  next page

46
(No Transcript)
47
Dagin Marine Technology

• CONTACT ADDRESS AND PERSON
• Dagin Marine Technology
• Mr. H. Th. Pronk
• Paterswoldseweg 810
• 9728 BM Groningen
• The Netherlands
• Tel. [phone]
• Fax [phone]
• Email harrypronk_at_dagin.nl
• Website www.dagin.nl (click on Marine
  Technology)
