Sparse Kernel Machines

1
Sparse Kernel Machines

• Christopher M. Bishop,
• Pattern Recognition and Machine Learning

2
Outline

• Introduction to kernel methods
• Support vector machines (SVM)
• Relevance vector machines (RVM)
• Applications
• Conclusions

3
Supervised Learning

• In machine learning, applications in which the
  training data comprises examples of the input
  vectors along with their corresponding target
  vectors are called supervised learning

(x,t) (1,60,pass) (2,53,fail) (3,77,pass) (4,34,fa
il) ?
y(x)
output
4
Classification
x2
ylt0
ygt0
y0
t1
t-1
x1
5
Regression
t
1
0
-1
x
new x
0
1
6
Linear Models

• Linear models for regression and classification
• if we apply feature extraction,

model parameter
input
7
Problems with Feature Space

• Why feature extraction? Working in high
  dimensional feature spaces solves the problem of
  expressing complex functions
• Problems
• - there is a computational problem (working
  with very large vectors)
• - curse of dimensionality

8
Kernel Methods (1)

• Kernel function inner products in some feature
  space ? nonlinear similarity measure
• Examples
• - polynomial
• - Gaussian

9
Kernel Methods (2)

• Many linear models can be reformulated using a
  dual representation where the kernel functions
  arise naturally ? only require inner products
  between data (input)

10
Kernel Methods (3)

• We can benefit from the kernel trick
• - choosing a kernel function is equivalent
  to
• choosing f ? no need to specify what
• features are being used
• - We can save computation by not explicitly
• mapping the data to feature space, but
  just
• working out the inner product in the
  data
• space

11
Kernel Methods (4)

• Kernel methods exploit information about the
  inner products between data items
• We can construct kernels indirectly by choosing a
  feature space mapping f, or directly choose a
  valid kernel function
• If a bad kernel function is chosen, it will map
  to a space with many irrelevant features, so we
  need some prior knowledge of the target

12
Kernel Methods (5)

• Two basic modules for kernel methods

General purpose learning model
Problem specific kernel function
13
Kernel Methods (6)

• Limitation the kernel function k(xn,xm) must be
  evaluated for all possible pairs xn and xm of
  training points when making predictions for new
  data points
• Sparse kernel machine makes prediction only by a
  subset of the training data points

14
Outline

• Introduction to kernel methods
• Support vector machines (SVM)
• Relevance vector machines (RVM)
• Applications
• Conclusions

15
Support Vector Machines (1)

• Support Vector Machines are a system for
  efficiently training the linear machines in the
  kernel-induced feature spaces while respecting
  the insights provided by the generalization
  theory and exploiting the optimization theory
• Generalization theory describes how to control
  the learning machines to prevent them from
  overfitting

16
Support Vector Machines (2)

• To avoid overfitting, SVM modify the error
  function to a regularized form
• where hyperparameter ? balances the
  trade-off
• The aim of EW is to limit the estimated functions
  to smooth functions
• As a side effect, SVM obtain a sparse model

17
Support Vector Machines (3)
Fig. 1 Architecture of SVM
18
SVM for Classification (1)

• The mechanism to prevent overfitting in
  classification is maximum margin classifiers
• SVM is fundamentally a two-class classifier

19
Maximum Margin Classifiers (1)

• The aim of classification is to find a D-1
  dimension hyperplane to classify data in a D
  dimension space
• 2D example

20
Maximum Margin Classifiers (2)
support vectors
support vectors
margin
21
Maximum Margin Classifiers (3)
small margin
large margin
22
Maximum Margin Classifiers (4)

• Intuitively it is a robust solution
• - If weve made a small error in the
  location of the boundary, this gives us least
  chance of causing a misclassification
• The concept of max margin is usually justified
  using Vapniks Statistical learning theory
• Empirically it works well

23
SVM for Classification (2)

• After the optimization process, we obtain the
  prediction model
• where (xn,tn) are N training data
• we can find that an will be zero except for
  that of the support vectors ? sparse

24
SVM for Classification (3)
Fig. 2 data from twp classes in two dimensions
showing contours of constant y(x) obtained from a
SVM having a Gaussian kernel function
25
SVM for Classification (4)

• For overlapping class distributions, SVM allow
  some of the training points to be misclassified ?
  soft margin

penalty
26
SVM for Classification (5)

• For multiclass problems, there are some methods
  to combine multiple two-class SVMs
• - one versus the rest
• - one versus one ? more training time

Fig. 3 Problems in multiclass classification
using multiple SVMs
27
SVM for Regression (1)

• For regression problems, the mechanism to prevent
  overfitting is e-insensitive error function

quadratic error function
e-insensitive error funciton
28
SVM for Regression (2)

Error y(x)-t- e
No error
Fig . 4 e-tube
29
SVM for Regression (3)

• After the optimization process, we obtain the
  prediction model
• we can find that an will be zero except for
  that of the support vectors ? sparse

30
SVM for Regression (4)
Fig . 5 Regression results. Support vectors are
line on the boundary of the tube or outside the
tube
31
Disadvantages

• Its not sparse enough since the number of
  support vectors required typically grows linearly
  with the size of the training set
• Predictions are not probabilistic
• The estimation of error/margin trade-off
  parameters must utilize cross-validation which is
  a waste of computation
• Kernel functions are limited
• Multiclass classification problems

32
Outline

• Introduction to kernel methods
• Support vector machines (SVM)
• Relevance vector machines (RVM)
• Applications
• Conclusions

33
Relevance Vector Machines (1)

• The relevance vector machine (RVM) is a Bayesian
  sparse kernel technique that shares many of the
  characteristics of SVM whilst avoiding its
  principal limitations
• RVM are based on Bayesian formulation and
  provides posterior probabilistic outputs, as well
  as having much sparser solutions than SVM

34
Relevance Vector Machines (2)

• RVM intend to mirror the structure of the SVM and
  use a Bayesian treatment to remove the
  limitations of SVM
• the kernel functions are simply treated as
  basis functions, rather than dot-product in some
  space

35
Bayesian Inference

• Bayesian inference allows one to model
  uncertainty about the world and outcomes of
  interest by combining common-sense knowledge and
  observational evidence.

36
Relevance Vector Machines (3)

• In the Bayesian framework, we use a prior
  distribution over w to avoid overfitting
• where a is a hyperparameter which control
  the model parameter w

37
Relevance Vector Machines (4)

• Goal find most probable a and ß to compute the
  predictive distribution over tnew for a new input
  xnew, i.e.
• p(tnew xnew, X, t,
  a, ß)
• Maximize the likelihood function to obtain a and
  ß
• p(tX, a, ß)

Training data and their target values
38
Relevance Vector Machines (5)

• RVM utilize the automatic relevance
  determination to achieve sparsity
• where am represents the precision of wm
• In the procedure of finding am, some am will
  become infinity which leads the corresponding wm
  to be zero ? remain relevance vectors !

39
Comparisons - Regression
SVM
RVM (on standard deviation predictive
distribution)
40
Comparisons - Regression
41
Comparison - Classification
SVM
RVM
42
Comparison - Classification
43
Comparisons

• RVM are much sparser and make probabilistic
  prediction
• RVM gives better generalization in regression
• SVM gives better generalization in classification
• RVM is computationally demanding while learning

44
Outline

• Introduction to kernel methods
• Support vector machines (SVM)
• Relevance vector machines (RVM)
• Applications
• Conclusions

45
Applications (1)

• SVM for face detection

46
Applications (2)
Marti Hearst, Support Vector Machines ,1998
47
Applications (3)

• In the feature-matching based object tracking,
  SVM are used to detect false feature matches

Weiyu Zhu et al., Tracking of Object with SVM
Regression , 2001
48
Applications (4)

• Recovering 3D human poses by RVM

A. Agarwal and B. Triggs, 3D Human Pose from
Silhouettes by Relevance Vector Regression 2004
49
Outline

• Introduction to kernel methods
• Support vector machines (SVM)
• Relevance vector machines (RVM)
• Applications
• Conclusions

50
Conclusions

• The SVM is a learning machine based on kernel
  method and generalization theory which can
  perform binary classification and real valued
  function approximation tasks
• The RVM have the same model as SVM but provides
  probabilistic prediction and sparser solutions

51
References

• www.support-vector.net
• N. Cristianini and J. Shawe-Taylor, An
  Introduction to Support Vector Machines and Other
  Kernel-based Learning Methods, Cambridge
  University Press,2000
• M. E. Tipping, Sparse Bayesian Learning and the
  Relevance Vector Machine, Journal of Machine
  Learning Research, 2001

52
Underfitting and Overfitting
underfitting-too simple
overfitting-too complex
new data
Adapted from http//www.dtreg.com/svm.htm
