Title: Tutorial of CIM Model Exchange


1
(No Transcript)
2
A Family of CIM EMS Exchange Standards based on
CIM/XML (61970-552)- Static Network Model
Exchange (61970-452)- Dynamic Model Exchange?-
Schematic Layout Exchange (61970-453)- Solved
State Exchange (61970-456)- EMS Static Model
Update (proposed)- - Contingency Definition?-
  • Jay Britton
  • jay.britton_at_areva-td.com

3
The Basic Model Exchange Business Problem
  • The members of an interconnection share a mutual
    necessity to achieve
  • Accurate assessment of grid reliability.
  • Appropriate, timely response to insecure
    conditions.
  • A pre-requisite to the above are
  • Accurate, up-to-date network models.
  • Consistent network models (at each responsible
    site).
  • In an interconnection, this requires
  • Exchange of models.
  • Exchange of solved analytical results.
  • 2008 NERC Real-Time Best Practices Report
  • Although defining the elements represented in
    internal network models is relatively
    straightforward, the task force finds that
    defining the elements to be represented in
    external models is much more complex.
  • Issue 5 External Modeling and Data Exchange
    Practices Should be Improved by Explicit
    Reference to the Definition of the Wide-Area-View
    Boundary. A consistent, uniform set of modeling
    and data exchange practices, procedures, and
    standards are needed to support creation and
    maintenance of accurate external models
  • These requirements apply in operations and
    planning contexts.

4
There is high-level consensus about the right
approach.
  • Basic Modeling
  • Each TSO is the authority for data about its own
    territory.
  • Each TSO exports its internal model to its
    neighbors and/or regional authority, and keeps it
    up to date.
  • Regional authorities assemble internal regional
    models from member TSO internal models.
  • All parties assemble external models from the
    internal models of other sites.
  • Analysis
  • Responsibility is usually distributed among
    cooperating sites.
  • Solution exchange is required, depending on the
    problem.
  • Exchanged solutions should be based on consistent
    underlying models.
  • These goals apply to both operations and
    planning.
  • Operations focus is on as-built and near future
    changes.
  • If operations and planning share the same
    as-built base model, then the planning focus is
    on exchange of plans.

5
Contributing Use Cases
  • Exchange of network models.
  • EMS A and B are neighbors in an interconnection
    and therefore each needs to represent the other
    as part of its external model.
  • Requires exchange of internal models.
  • Scope is limited to network data and measurement
    placements.
  • Exchange of schematics with models is desirable.
  • Common Modeling Source between planning and
    operations.
  • One modeling application for the enterprise.
  • An EMS requires a model that covers any point in
    time.
  • Other targets require data for a specific case.
  • Exchange of solved cases. Several variations
  • Real-time exchange among different applications.
  • Real-time cases to study or planning.
  • Exchange of study or planning cases between
    different tools.
  • Import of study cases to EMS.
  • ENTSO-E DACF.
  • Study cases are generated for the next day by
    each TSO representing the expected state of their
    internal network.

6
A Generic Model Exchange Business
Process(ENTSO-E, ERCOT, WECC, )
7
Preview We are working toward defining model
partitioning into non-overlapping XML submodels
that satisfy all of the use cases.
8
The initial CIM model exchange (61970-452)
standard focused only on transfer of complete
models
CIM Exchange (full, partial, incremental update)
CIM import / export
CIM import / export


System A Import Model
System B Import Model
a
b
Proprietary / Home grown Extract / Merge Tools
Proprietary / Home grown Extract / Merge Tools
A Internal Model
Bs Model of A
System A Local Vendor Model
System B Local Vendor Model
As model of B
B Internal Model
System B EMS
System A EMS
9
A More Desirable Process
  • Site A makes a change
  • A changes its ModelAuthoritySet using its CIM
    modeller.
  • A imports the change into its EMS.
  • A exports the change to B.
  • B receives the change (full or incremental),
    updating As ModelAuthoritySet within its CIM
    modeller.
  • B renames any new elements and repeats any
    reduction of As ModelAuthoritySet.
  • B imports the new model into its EMS.

10
Merge/Extract with Model Authority Sets
  • Each object is in one and only one set.
  • Simple labeling technique for assigning
    responsibility.
  • Associations connect some objects that are in
    different sets.
  • Currently directional from n to 1 (foreign key
    convention) under discussion.
  • Regional Sets
  • No associations with other regional sets.
  • External associations to boundary sets only.
  • Boundary Sets
  • External associations from regional sets.
  • External associations with other boundary sets.
  • A regional set may be referentially validated
    independent of other regional sets.
  • Modeling processes can proceed independently in
    each region.
  • Goal
  • Maximize independence.
  • Design boundary sets to achieve
  • Minimum data
  • Infrequent change

11
Typical North American Operations Boundary
12
Typical ENTSO-E Operations Boundary
13
Hierarchical Process Definition for an
Interconnection
  • Bottom level.
  • No significant differences.
  • Export changes as the model authority.
  • Import externals from the full interconnection
    model.
  • Upper level
  • Manages boundary sets.
  • Creates the full interconnection model.
  • Model quality evaluation.
  • Study state estimation.
  • Derives operational model in the same manner as
    lower levels.
  • Different reduction criteria.
  • Design extends to any number of hierarchical
    levels.

14
Consolidating Planning with Operations
  • Full interconnection model is the common source
    for all models.
  • Interconnection planning shown on diagram.
  • No procedural difference required to support
    analytical functions running at any level for any
    purpose.
  • Planning adds other requirements.
  • New information modeling in CIM.
  • Accommodate bus-oriented apps.
  • Add short circuit, dynamics, etc.
  • Incremental model standard expands to model
    plans.
  • CIM modeling applications need to have a temporal
    axis.
  • 2007 EPRI CIM for Planning project.
  • Goal is eliminate duplication of modeling.

15
The Naming Problem
16
Evolving Support for Analytical Processes
  • The original 61970-452 standard exchanged EMS
    models.
  • Did not deal with planning (bus-branch models).
  • Did not support power flow solution exchange (or
    any other type of analytical result).
  • Several recent efforts defined other needed
    support.
  • 2007 EPRI CIM for Planning
  • 2008-2010 ENTSO-E Day Ahead Congestion Analysis
  • 2008-2009 EPRI CIM for Dynamics
  • Recent IEC WG13 Accomplishments
  • 61970-452 now supports planning models in
    addition to operations.
  • Draft 61970-456 defines solved power system state
    exchange.
  • Operations and planning share the same standard.
  • ENTSO-E DACF supported.
  • Draft 61970-454 defines display layout exchange.
  • Update of 61970-552 includes header
    specifications.
  • Current WG13 Agenda
  • Unify distribution and transmission network
    modeling.
  • Object registry specification 61970-453.

17
Current Modularity
  • 61970-452 Static Model.
  • Equipment Profile.
  • Identifies equipment and describes basic
    characteristics.
  • Describes electrical connectivity that would be
    input to topology processing. (Optional for
    planning.)
  • Describes input to functions that derive
    parameters for a specific point in time.
    (Optional for planning.)
  • Dynamics Profile.
  • Describes dynamic characteristics.
  • 61970-456 Solved Power System State
  • Topology Profile.
  • The result of topology processing. i.e.
    Description of how equipment connects into buses
    and how buses makeup connected systems.
  • Analogs Profile.
  • The set of SCADA values for analog measurements
    for a particular point in time.
  • Status Profile.
  • The state of switches input to topology
    processing.
  • State Variables Profile.
  • This is the set of state variables used in the
    mathematical formulation that the algorithms work
    with.
  • Used to represent starting conditions or ending
    conditions of analysis.
  • 61970-454 Display Layouts
  • The position of objects within a schematic or
    geographic presentation.

18
61970 Profiles
19
Dependency Relationships to be Expressed in
Headers
20
DACF Process
21
Combining profiles into a complete solution
description.
22
Partitioning into Files by TSO
23
Complete View of Partitioning Into Files
24
ENTSO-E Interconnection Solution
25
Partitioning of EMS Static Model
26
Partitioning of EMS Solved Cases
27
61970-453 Display Layout Exchange
  • Purpose
  • To exchange schematic display layouts
    accompanying model or solution exchanges.
  • Corresponds to the part of display maintenance
    work that normally goes with model maintenance.
  • Defines graphic objects used in the senders
    displays
  • Usually linked to a model object, but can also be
    background.
  • One or more location coordinates. (Optional glue
    points.)
  • Graphic style reference.
  • Does not define Interpretation of graphic style
    references.
  • Usage
  • Sender describes diagram.
  • Senders disclose the way their system uses
    graphic styles.
  • Object placements describe senders diagram as
    is.
  • Receiver must decide how to render the diagram in
    its system.
  • Create interpretation of senders styles.
  • Receivers are not expected to duplicate
    functionality.
  • Receivers may break apart complex styles or
    combine simpler styles.
  • Receiver provides the graphic style
    interpretation models for their display
    management software.
  • Result
  • Layouts and names of things should be familiar.

28
Display Layout UML Proposal
29
ENTSO-E Case Display Layout Exchange
