Animal Body Plans

1
Animal Body Plans
2
Major Body Plan Characteristics of Animals

• Symmetry
• Primary Germ Layers
• Gut Organization
• Body Cavity
• Segmentation
• Skeletal Systems
• Circulatory Systems
• Appendages
• Coloniality

3
Symmetry

• Asymmetry
• Radial Symmetry
• Bilateral Symmetry

4
Symmetry
Bilateral Symmetry
Radial Symmetry
5
Radial Symmetry
JellyfishPhylum Cnidaria
6
Pentamerous Radial Symmetry
Sea StarsPhylum Echinodermata
7
Bilateral Symmetry
SlugPhylum Mollusca
8
Bilateral Symmetry
SquidPhylum Mollusca
9
Primary Germ Layers
Mesoderm

• None
• Diploblastic
• Triploblast

gut
Ectoderm
Endoderm
10
Fates of the Primary Germ Layers

• Ectoderm
• hair, nails, epidermis, brain, nerves
• Mesoderm
• notochord (in chordates), dermis, blood vessels,
  heart, bones, cartilage, muscle
• Endoderm
• internal lining of the gut and respiratory
  pathways, liver, pancreas

11
The Formation of Primary Germ Layers
12
The Formation of Primary Germ Layers
13
Germ Layer Patterns
Endoderm
Diploblastic
gut
Ectoderm
14
Diploblastic- two germ layers
Phylum Cnidaria
15
Germ Layer Patterns
Mesoderm
Triploblastic 3 germ layers
gut
Ectoderm
Endoderm
acoelomate
16
Gut Organization

• No Gut
• Blind Sac Gut
• Complete Gut

17
No Gut
SpongesPhylum Porifera
18
No Gut
SpongesPhylum Porifera
19
Blind Sac Gut
Phylum Cnidaria
20
Complete Gut
21
Body Cavities

• Acoelomate
• Eucoelomate
• Pseudocoelomate

22
Body Cavities
Mesoderm
Acoelomate- lacks cavity between gut and outer
body wall
gut
Ectoderm
Endoderm
23
Body Cavities
coelom
Mesoderm
Eucoelomate- body cavity completely lined with
mesoderm
Ectoderm
Endoderm
24
Body Cavities
pseudocoelom
Mesoderm
Pseudocoelomate body cavity partially lined with
mesoderm
Endoderm
Ectoderm
25
Advantages of aFluid-Filled Body Cavity

• hydrostatic skeleton
• greater freedom for internal organs
• greater body size because of body fluid
  circulation

26
Segmentation
27
Segmentation
CentipedePhylum Arthropoda
28
Segmentation
LobsterPhylum Arthropoda
Cephalothorax
Antennae (sensory reception)
Head
Thorax
Abdomen
Mouthparts (feeding)
Swimming Appendages
Pincers (defense)
Walking legs
29
Skeleton
30
Functions of the Skeleton

• supports basic body form
• protection of soft internal tissues and organs
• facilitates locomotion

31
Skeleton

• Hydrostatic Skeletons
• Hard Skeletons
• Exoskeletons
• Endoskeletons

32
Hydrostatic Skeleton
Sea AnemonePhylum Cnidaria
33

• Hydrostatic Skeleton
• A non compressible fluid held under pressure in a
  closed body compartment.
• Uses antagonistic muscles for movement.
• The gastrovascular cavity of the jellyfish acts
  as hydrostatic skeleton against which contractile
  cells can work.

34
Hydrostatic Skeleton
EarthwormPhylum Annelida
35
Exoskeleton
ChitonPhylum Mollusca
36
Exoskeleton
Stony CoralPhylum Cnidaria
37
Endoskeletons
Vertebrates Phylum Chordata
38
Types of Appendages
39
Functions of Appendages

• locomotion
• feeding
• sensory
• protection

40
Tentacles
Sea AnemonePhylum Cnidaria
41
Jointed Appendages
Bee Appendages Phylum Arthropoda
42
Circulatory Systems
43
Functions of Circulatory Systems

• transport of nutrients and metabolic wastes
• maintains water and solute balance
• defense against pathogens

44
Circulatory System

• None (simple diffusion)
• Body Cavity Circulation
• Closed Circulatory System
• Open Circulatory System

45
No Circulatory System
Comb JellyPhylum Ctenophora
46
Circulation in a Moon Jellyfish
Phylum Cnidaria
47
Closed Versus Open Circulatory Systems
48
Nervous Systems
49
Functions of Nervous systems

• integration of animal behavior
• processing and interpretation of sensory
  information
• elicits external and internal responses

50
Types of Nervous Systems
51
Coloniality
52
Coloniality
CoralPhylum Cnidaria
53
Coloniality
Sea FanPhylum Cnidaria
54
Coloniality
Man-of-WarPhylum Cnidaria
55
Polymorphism in the Portuguese Man- of-War
