How Fuel Cells Work

1
How Fuel Cells Work

• Fuel Cells (????)
• Making power more efficiently and with less
  pollution.

2
Fuel Cell- an electrochemical energy conversion
device

• To convert the chemicals hydrogen and oxygen into
  water, and in the process it produces
  electricity.
• Battery (??) the other electrochemical device
  that we are all familiar.
• A battery has all of its chemicals stored inside,
  and it converts those chemicals into electricity
  too.
• This means that a battery eventually "goes dead"
  and you either throw it away or recharge it.

3
For a fuel cell

• Chemicals constantly flow into the cell so it
  never goes dead.
• As long as there is a flow of chemicals into the
  cell,
• the electricity flows out of the cell.
• Most fuel cells in use today use hydrogen and
  oxygen as the chemicals.

4
Fuel Cell Descriptions

• Fuel Cells generate electricity through an
  electrochemical process
• In which the energy stored in a fuel is converted
  directly into DC electricity.
• Because electrical energy is generated without
  combusting fuel,
• Fuel cells are extremely attractive from an
  environmental stand point.

5
Attractive characteristics of Fuel Cell

• High energy conversion efficiency
• Modular design
• Very low chemical and acoustical pollution
• Fuel flexibility
• Cogeneration capability
• Rapid load response

6
A functioning cell in a Solid Oxide Fuel Cell
stack
7
(No Transcript)
8

• It consists of three components - a cathode, an
  anode, and an electrolyte sandwiched between the
  two.
• Oxygen from the air flows through the cathode
• A fuel gas containing hydrogen, such as methane,
  flows past the anode.
• Negatively charged oxygen ions migrate through
  the electrolyte membrane react with the hydrogen
  to form water,
• The reacts with
• the methane fuel
• to form hydrogen (H2)
• carbon dioxide (CO2).

9

• This electrochemical reaction generates
  electrons, which flow from the anode to an
  external load and back to the cathode,
• a final step that both completes the circuit and
  supplies electric power.
• To increase voltage output, several fuel cells
  are stacked together to form the heart of a clean
  power generator.

10
Cool Fuel Cells

• Fuel cells promise to be the environmentally-frien
  dly power source of the future,
• but some types run too hot to be practical.
  NASA-funded research may have a solution.

11
All fuel cells have the same basic operating
principle.

• An input fuel is catalytically reacted (electrons
  removed from the fuel elements) in the fuel cell
  to create an electric current.

• Fuel cells consist of an electrolyte material
  which is sandwiched in between two thin
  electrodes (porous anode and cathode).
• The input fuel passes over the anode (and oxygen
  over the cathode) where it catalytically splits
  into ions and electrons.
• The electrons go through an external circuit to
  serve an electric load while the ions move
  through the electrolyte toward the oppositely
  charged electrode.
• At the electrode, ions combine to create
  by-products, primarily water and CO2. Depending
  on the input fuel and electrolyte, different
  chemical reactions will occur.

12
Basic Configuration
13
PEMFC
14
Animation of PEMFC
15
(No Transcript)
16

• U

17
(No Transcript)
18

• With thousands of diaphragm compressor
  installations worldwide, you can trust PPI to
  handle the difficult applications. PPI has the
  hydrogen compressor engineering and manufacturing
  experience you can count on.

19
SUSTAINABLE Transport
20
(No Transcript)
21

• I

22
(No Transcript)
23
SOLID OXIDE FUEL CELL STACK PROVIDER

• HTceramix's SOFConnexTM based stack

24
(No Transcript)
25
Applications of Fuel cells
26
Woking Park Fuel Cell CHP schematic
27

• U

28
Four primary types of fuel cells

• They are based on the electrolyte employed
• Phosphoric Acid Fuel Cell
• Molten Carbonate Fuel Cell
• Solid Oxide Fuel Cell
• Proton Exchange Membrane Fuel Cell

29
Phosphoric Acid Fuel Cells -PAFCs

• The most mature fuel cell technology in terms of
  system development and commercialization
  activities.
• Has been under development for more than 20 years
• Has received a total worldwide investment in the
  development and demonstration of the technology
  in excess of 500 million.
• The PAFC was selected for substantial development
  a number of years ago because of the belief that,
  among the low temperature fuel cells,
• It was the only technology which showed relative
  tolerance for reformed hydrocarbon fuels and thus
  could have widespread applicability in the near
  term.

30
PAFC Design and Operation

• The PAFC uses liquid phosphoric acid as the
  electrolyte.
• The phosphoric acid is contained in a Teflon
  bonded silicone carbide matrix.
• The small pore structure of this matrix
  preferentially keeps the acid in place through
  capillary action.
• Some acid may be entrained in the fuel or oxidant
  streams and addition of acid may be required
  after many hours of operation.
• Platinum catalyzed, porous carbon electrodes are
  used on both the fuel (anode) and oxidant
  (cathode) sides of the electrolyte.

31

• Fuel and oxidant gases are supplied to the backs
  of the porous electrodes by parallel grooves
  formed into carbon or carbon-composite plates.
• These plates are electrically conductive and
  conduct electrons from an anode to the cathode of
  the adjacent cell.
• In most designs, the plates are "bi-polar" in
  that they have grooves on both sides - one side
  supplies fuel to the anode of one cell, while the
  other side supplies air or oxygen to the cathode
  of the adjacent cell.
• The byproduct water is removed as steam on the
  cathode (air or oxygen) side of each cell by
  flowing excess oxidant past the backs of the
  electrodes.
• This water removal procedure requires that the
  system be operated at temperatures around 375oF
  (190oC).
• At lower temperatures, the product water will
  dissolve in the electrolyte and not be removed as
  steam. At approximately 410oF (210oC), the
  phosphoric acid begins to decompose.

32

• The byproduct water is removed as steam on the
  cathode (air or oxygen) side of each cell by
  flowing excess oxidant past the backs of the
  electrodes.
• This water removal procedure requires that the
  system be operated at temperatures around 375oF
  (190oC).
• At lower temperatures, the product water will
  dissolve in the electrolyte and not be removed as
  steam. At approximately 410oF (210oC), the
  phosphoric acid begins to decompose.
• Excess heat is removed from the fuel cell stack
  by providing carbon plates containing cooling
  channels every few cells.
• Either air or a liquid coolant, such as water,
  can be passed through these channels to remove
  excess heat.

33
Electrochemical reactions in PAFC

• At the anode
• Hydrogen is split into two hydrogen ions (H),
  which pass through the electrolyte to the
  cathode, and
• two electrons which pass through the external
  circuit (electric load) to the cathode.
• At the cathode
• the hydrogen, electrons and oxygen combine to
  form water.

34
Electrochemical reactions in PAFC
35
PAFC Performance Characteristics

• PAFC power plant designs show electrical
  efficiencies in the range from 36 (HHV) to 42
  (HHV).
• The higher efficiency designs operate with
  pressurized reactants.
• The higher efficiency pressurized design requires
  more components and likely higher cost.
• PAFC power plants supply usable thermal energy at
  an efficiency of 37 (HHV) to 41 (HHV).
• A portion of the thermal energy can be supplied
  at temperatures of 250oF to 300oF.
• However, the majority of the thermal energy is
  supplied at 150oF.
• The PAFC has a power density of 160-175 watts/ft2
  of active cell area

36
Molten Carbonate Fuel Cells - MCFC

• A molten carbonate salt mixture is used as its
  electrolyte.
• They evolved from work in the 1960's aimed at
  producing a fuel cell which would operated
  directly on coal.
• While direct operation on coal seems less likely
  today,
• The operation on coal-derived fuel gases or
  natural gas is viable.

37
Molten Carbonate Salt used as Electrolyte in MCFC

• A molten carbonate salt mixture is used as its
  electrolyte.
• The composition of the electrolyte (molten
  carbonate salt mixture) varies, but usually
  consists of lithium carbonate and potassium
  carbonate.
• At the operating temperature of about 650oC
  (1200oF), the salt mixture is liquid and a good
  ionic conductor.
• The electrolyte is suspended in a porous,
  insulating and chemically inert ceramic (LiAlO3)
  matrix.

38
Reactions in MCFC

• The anode process involves a reaction between
  hydrogen and carbonate ions (CO3) from the
  electrolyte.
• The reaction produces water and carbon dioxide
  (CO2) while releasing electrons to the anode.

• The cathode process combines oxygen and CO2 from
  the oxidant stream with electrons from the
  cathode to produce carbonate ions which enter the
  electrolyte.
• The need for CO2 in the oxidant stream requires a
  system for collecting CO2 from the anode exhaust
  and mixing it with the cathode feed stream.

39
Reactions in MCFC
40
Description of reactions in MCFCs

• The anode process involves a reaction between
  hydrogen and carbonate ions (CO3) from the
  electrolyte.
• The reaction produces water and carbon dioxide
  (CO2) while releasing electrons to the anode.
• The cathode process combines oxygen and CO2 from
  the oxidant stream with electrons from the
  cathode to produce carbonate ions which enter the
  electrolyte.
• The need for CO2 in the oxidant stream requires a
  system for collecting CO2 from the anode exhaust
  and mixing it with the cathode feed stream.

41

• As the operating temperature increases,
• the theoretical operating voltage for a fuel cell
  decreases and with it the maximum theoretical
  fuel efficiency.
• On the other hand, increasing the operating
  temperature increases the rate of the
  electrochemical reaction and
• Thus increases the current which can be obtained
  at a given voltage.
• The net effect for the MCFC is that the real
  operating voltage is higher than the operating
  voltage for the PAFC at the same current density.

• The higher operating voltage of the MCFC means
  that more power is available at a higher fuel
  efficiency from a MCFC than from a PAFC of the
  same electrode area.
• As size and cost scale roughly with electrode
  area, this suggests that a MCFC should be smaller
  and less expensive than a "comparable" PAFC.

42

• As size and cost scale roughly with electrode
  area, this suggests that a MCFC should be smaller
  and less expensive than a "comparable" PAFC.
• The MCFC also produces excess heat at a
  temperature which is high enough to yield high
  pressure steam which may be fed to a turbine to
  generate additional electricity.
• In combined cycle operation, electrical
  efficiencies in excess of 60 (HHV) have been
  suggested for mature MCFC systems.
• The MCFC operates at between 1110F (600C) and
  1200F (650C) which is necessary to achieve
  sufficient conductivity of the electrolyte.
• To maintain this operating temperature, a higher
  volume of air is passed through the cathode for
  cooling purposes.

43

• As mentioned above, the high operating
  temperature of the MCFC offers the possibility
  that it could operate directly on gaseous
  hydrocarbon fuels such as natural gas.
• The natural gas would be reformed to produce
  hydrogen within the fuel cell itself.
• The need for CO2 in the oxidant stream requires
  that CO2 from the spent anode gas be collected
  and mixed with the incoming air stream.
• Before this can be done, any residual hydrogen in
  the spent fuel stream must be burned.
• Future systems may incorporate membrane
  separators to remove the hydrogen for
  recirculation back to the fuel stream.

44

• At cell operating temperatures of 650oC (1200oF)
  noble metal catalysts are not required.
• The anode is a highly porous sintered nickel
  powder, alloyed with chromium to prevent
  agglomeration and creep at operating
  temperatures.
• The cathode is a porous nickel oxide material
  doped with lithium.
• Significant technology has been developed to
  provide electrode structures which position the
  electrolyte with respect to the electrodes and
  maintain that position while allowing for some
  electrolyte boil-off during operation.
• The electrolyte boil-off has an insignificant
  impact on cell stack life.

45

• A more significant factor of life expectancy has
  to do with corrosion of the cathode.
• The MCFC operating temperature is about 650oC
  (1200oF).
• At this temperature the salt mixture is liquid
  and is a good conductor.
• The cell performance is sensitive to operating
  temperature.
• A change in cell temperature from 650oC (1200oF)
  to 600oC (1110oF) results in a drop in cell
  voltage of almost 15.
• The reduction in cell voltage is due to increased
  ionic and electrical resistance and a reduction
  in electrode kinetics.

46
Solid Oxide Fuel Cells

• The Solid Oxide Fuel Cell (SOFC) uses a ceramic,
  solid-phase electrolyte which reduces corrosion
  considerations and eliminates the electrolyte
  management problems associated with the liquid
  electrolyte fuel cells.
• To achieve adequate ionic conductivity in such a
  ceramic, however, the system must operate at
  about 1000oC (1830oF).
• At that temperature, internal reforming of
  carbonaceous fuels should be possible, and the
  waste heat from such a device would be easily
  utilized by conventional thermal electricity
  generating plants to yield excellent fuel
  efficiency.

47

• The fuel cell will compete with many other types
  of energy conversion devices, including
• the gas turbine in city's power plant,
• the gasoline engine in your car and
• the battery in your laptop.
• Combustion engines like the turbine and the
  gasoline engine burn fuels and
• use the pressure created by the expansion of the
  gases to do mechanical work.
• Batteries converted chemical energy back into
  electrical energy when needed.
• Fuel cells should do both tasks more efficiently.

• A fuel cell provides a DC (direct current)
  voltage that can be used to power motors, lights
  or any number of electrical appliances.

48
Classification of Fuel Cells

• There are several different types of fuel cells,
  each using a different chemistry.
• Fuel cells are usually classified by the type of
  electrolyte they use.
• Some types of fuel cells work well for use in
  stationary power generation plants.
• Others may be useful for small portable
  applications or for powering cars.
• The proton exchange membrane fuel cell (PEMFC) is
  one of the most promising technologies.
• This is the type of fuel cell that will end up
  powering cars, buses and maybe even your house.
  Let's take a look at how they work...

49
Tiny Fuel Cell to Power Sensors

• A fuel cell prototype that is the size of a
  pencil eraser and can deliver small amounts of
  electricity was developed at Case Western Reserve
  University (CWRU).

• The fuel cells are 5 mm3 in volume and generate
  10 mW of power with short pulses of up to 100 mW.
• The cell power is so limited
• There is no practical consumer use yet.
• A cell phone, e.g., needs 500 mW.
• The first use will be in sensors for the
  military.

50
Microfuel cell

• The prototype microfuel cell uses an
  electrochemical process to directly convert
  energy from hydrogen into electricity.
• The fuel cell works like a battery, using an
  anode and cathode, positive and negative
  electrodes (solid electrical conductors), with an
  electrolyte.
• The electrolyte can be made of various materials
  or solutions. The hydrogen flows into the anode
  and the molecules are split into protons and
  electrons.
• The protons flow through the electrolyte, while
  the electrons take a different path, creating an
  electrical current.
• At the other end of the fuel cell, oxygen is
  pulled in from the air and flows into the
  cathode.
• The hydrogen protons and electrons reunite in the
  cathode and chemically bond with the oxygen atoms
  to form water molecules.
• Theoretically, the only waste product produced by
  a fuel cell is water.
• Fuel cells that extract hydrogen from natural gas
  or another hydrocarbon will emit some carbon
  dioxide as a byproduct, but in much smaller
  amounts than those produced by traditional energy
  sources.

51
PEMFC Proton Exchange Membrane Fuel Cell
Animation fuel-cell-animation.swf

• The cell uses one of the simplest reactions of
  any fuel cell.

52
Four Basic Elements in a PEMFC

• Anode the negative post of the fuel cell, has
  several jobs.
• It conducts the electrons that are freed from the
  hydrogen molecules
• so that they can be used in an external circuit.
• It has channels etched into it that disperse the
  hydrogen gas equally over the surface of the
  catalyst.
• Cathode the positive post of the fuel cell,
• has channels etched into it that distribute the
  oxygen to the surface of the catalyst.
• It also conducts the electrons back from the
  external circuit to the catalyst,
• where they can recombine with the hydrogen ions
  and oxygen to form water.

53
Four Basic Elements in a PEMFC

• The electrolyte is the proton exchange membrane.
• This specially treated material, which looks
  something like ordinary kitchen plastic wrap,
• only conducts positively charged ions.
• The membrane blocks electrons.
• The catalyst is a special material that
  facilitates the reaction of oxygen and hydrogen.
• It is usually made of platinum powder very thinly
  coated onto carbon paper or cloth.
• The catalyst is rough and porous so that the
  maximum surface area of the platinum can be
  exposed to the hydrogen or oxygen.
• The platinum-coated side of the catalyst faces
  the PEM.

54
Chemistry of a Fuel Cell

• Anode side 2H2 ? 4H 4e-
• Cathode side O2 4H 4e- ? 2H2O
• Net reaction 2H2 O2 ? 2H2O

55
Animation of a fuel cell workingfuel-cell-animati
on.swf

• The pressurized hydrogen gas (H2) entering the
  fuel cell on the anode side.
• This gas is forced through the catalyst by the
  pressure. When an H2 molecule comes in contact
  with the platinum on the catalyst, it splits into
  two H ions and two electrons (e-).
• The electrons are conducted through the anode,
  where they make their way through the external
  circuit (doing useful work such as turning a
  motor) and return to the cathode side of the fuel
  cell.

56

• Meanwhile, on the cathode side of the fuel cell,
  oxygen gas (O2) is being forced through the
  catalyst, where it forms two oxygen atoms.
• Each of these atoms has a strong negative charge.

• This negative charge attracts the two H ions
  through the membrane, where they combine with an
  oxygen atom and two of the electrons from the
  external circuit to form a water molecule (H2O).
• This reaction in a single fuel cell produces only
  about 0.7 volts.
• To get this voltage up to a reasonable level,
  many separate fuel cells must be combined to form
  a fuel-cell stack (???).

57

• PEMFCs operate at a fairly low temperature (about
  176oF80oC),
• It means they warm up quickly and don't require
  expensive containment structures.
• Constant improvements in the engineering and
  materials used in these cells have increased the
  power density to a level where a device about the
  size of a small piece of luggage can power a car.

58
Problems with Fuel Cells

• The fuel cell uses oxygen and hydrogen to produce
  electricity.
• The oxygen required for a fuel cell comes from
  the air.
• In fact, in the PEM fuel cell, ordinary air is
  pumped into the cathode.
• The hydrogen is not so readily available,
  however.
• Hydrogen has some limitations that make it
  impractical for use in most applications.
• For instance, you don't have a hydrogen pipeline
  coming to your house, and you can't pull up to a
  hydrogen pump at your local gas station.
• Hydrogen is difficult to store and distribute, so
  it would be much more convenient if fuel cells
  could use fuels that are more readily available.
• This problem is addressed by a device called a
  reformer.
• A reformer turns hydrocarbon or alcohol fuels
  into hydrogen, which is then fed to the fuel
  cell.
