Slide 1 of 39

1
Further Statistical Issues
Chapter 12
Last revision August 26, 2006, 2003
2
What Well Do ...

• Random-number generation
• Generating random variates
• Nonstationary Poisson processes
• Variance reduction
• Sequential sampling
• Designing and executing simulation experiments

• Backup material
• Appendix C A Refresher on Probability and
  Statistics
• Appendix D Arenas Probability Distributions

3
Random-Number Generators (RNGs)

• Algorithm to generate independent, identically
  distributed draws from the continuous UNIF (0, 1)
  distribution
• These are called random numbersin simulation
• Basis for generating observations from all other
  distributions and random processes
• Transform random numbers in a way that depends on
  the desired distribution or process (later in
  this chapter)
• Its essential to have a good RNG
• There are a lot of bad RNGs this is very tricky
• Methods, coding are both tricky

4
The Nature of RNGs

• Recursive formula (algorithm)
• Start with a seed (or seed vector)
• Do something weird to the seed to get the next
  one
• Repeat generate the same sequence
• Will eventually repeat (cycle) want long cycle
  length
• Not really random as in unpredictable
• Does this matter? Philosophically? Practically?
• Want to design RNGs
• Long cycle length
• Good statistical properties (uniform,
  independent) -- tests
• Fast
• Streams (subsegments) many and long (for
  variance reduction later)
• This is hard! Doing something weird isnt enough

5
Linear Congruential Generators(LCGs)

• The most common of several different methods
• But not the one in Arena (though its related)
  later
• Generate a sequence of integers Z1, Z2, Z3, via
  the recursion
• Zi (a Zi1 c) (mod m)
• a, c, and m are carefully chosen constants
• Specify a seed Z0 to start off
• mod m means take the remainder of dividing by m
  as the next Zi
• All the Zis are between 0 and m 1
• Return the ith random number as Ui Zi / m

6
Example of a Toy LCG

• Parameters m 63, a 22, c 4, Z0 19
• Zi (22 Zi1 4) (mod 63), seed with Z0 19
• i 22 Zi14 Zi Ui
• 0 19
• 1 422 44 0.6984
• 2 972 27 0.4286
• 3 598 31 0.4921
• 4 686 56 0.8889
• 61 158 32 0.5079
• 62 708 15 0.2381
• 63 334 19 0.3016
• 64 422 44 0.6984
• 65 972 27 0.4286
• 66 598 31 0.4921

• Cycling will repeat forever
• Cycle length m
• (could be ltlt m depending
• on parameters)
• Pick m BIG
• But that might not be enoughfor good statistical
  properties

7
Issues with LCGs

• Cycle length lt m
• Typically, m 2.1 billion ( 231 1) or more
• Which used to be a lot more later
• Other parameters chosen so that cycle length m
  or m 1
• Statistical properties
• Uniformity, independence
• There are many tests of RNGs
• Empirical tests
• Theoretical tests lattice structure (next
  slide )
• Speed, storage both are usually fine
• Must be carefully, cleverly coded BIG integers
• Reproducibility streams (long internal
  subsequences) with fixed seeds

8
Issues with LCGs (contd.)

• Regularity of LCGs (and other kinds of RNGs)
  For the earlier toy LCG
• Design RNGs dense lattice in high dimensions
• Other kinds of RNGs longer memory in recursion,
  combination of several RNGs

Plot of Ui vs. i
Plot of Ui1 vs. Ui
Random Numbers Fall Mainly in the Planes
George Marsaglia
9
Original (1983) Arena RNG

• LCG with m 231 1 2,147,483,647
• a 75 16,807
• c 0
• Cycle length m 1 2.1 ? 109
• Ten different automatic streams with fixed seeds
• In its day, this was a good, well-tested
  generator in an efficient code
• But current computer speed make this cycle length
  inadequate
• Exhaust in 10 minutes on 2 GHz PC if we just
  generate
• Can get this generator (not recommended)
• Place a Seeds module (Elements panel) in your
  model

10
Current Arena RNG

• Uses some of the same ideas as LCG
• Modulo division, recursive on earlier values
• But is not an LCG
• Combines two separate component generators
• Recursion involves more than just the preceding
  value
• Combined multiple recursive generator (CMRG)
• An (1403580 An-2 810728 An-3) mod 4294967087
• Bn (527612 Bn-1 1370589 Bn-3) mod 4294944443
• Zn (An Bn) mod 4294967087
• Seed a six-vector of first three Ans, Bns

Two simultaneous recursions
Combine the two
The next random number
11
The Current (2000) Arena RNG Properties

• Extremely good statistical properties
• Good uniformity in up to 45-dimensional hypercube
• Cycle length 3.1 ? 1057
• To cycle, all six seeds must match up
• On 2 GHz PC, would take 2.8 ? 1040 millennia to
  exhaust
• Under Moores law, it will be 216 years until
  this generator can be exhausted in a year of
  nonstop computing
• Only slightly slower than old LCG
• And RNG is usually a minor part of overall
  computing time

12
The Current (2000) Arena RNG Streams and
Substreams

• Automatic streams and substreams
• 1.8 ? 1019 streams of length 1.7 ? 1038 each
• Each stream further divided into 2.3 ? 1015
  substreams of length 7.6 ? 1022 each
• 2 GHz PC would take 669 million years to exhaust
  a substream
• Default stream is 10 (historical reasons)
• Also used for Chance-type Decide module
• To use a different stream, append its number
  after a distributions parameters
• For example, EXPO(6.7, 4) to use stream 4
• When using multiple replications, Arena
  automatically advances to next substream in each
  stream for the next replication
• Helps synchronize for variance reduction ... later

13
Generating Random Variates

• Have Desired input distribution for model
  (fitted or specified in some way), and RNG (UNIF
  (0, 1))
• Want Transform UNIF (0, 1) random numbers into
  draws from the desired input distribution
• Method Mathematical transformations of random
  numbers to deform them to the desired
  distribution
• Specific transform depends on desired
  distribution
• Details in online Help about methods for all
  distributions
• Do discrete, continuous distributions separately

14
Generating from Discrete Distributions

• Example probability mass function
• Divide 0, 1
• Into subintervals of length 0.1, 0.5, 0.4
• Generate U UNIF (0, 1)
• See which subinterval its in
• Return X corresponding value

15
Discrete Generation Another View

• Plot cumulative distribution function generate U
  and plot on vertical axis read across and down

• Inverting the CDF
• Equivalent to earlier method

16
Generating from Continuous Distributions

• Example EXPO (5) distribution
• Density (PDF)
• Distribution (CDF)
• General algorithm (can be rigorously justified)
• 1. Generate a random number U UNIF(0, 1)
• 2. Set U F(X) and solve for X F1(U)
• Solving analytically for X may or may not be
  simple (or possible)
• Sometimes use numerical approximation to solve

17
Generating from Continuous Distributions (contd.)

• Solution for EXPO (5) case
• Set U F(X) 1 eX/5
• eX/5 1 U
• X/5 ln (1 U)
• X 5 ln (1 U)
• Picture (inverting the CDF, as in discrete case)

Intuition (garden hose) More Us will hit F(x)
where its steep This is where the density f(x)
is tallest, and we want a denser distribution of
Xs
18
Nonstationary Poisson Processes

• Many systems have externally originating events
  affecting them e.g., arrivals of customers
• If process is stationary over time, usually
  specify a fixed interevent-time distribution
• But process could vary markedly in its rate
• Fast-food lunch rush
• Freeway rush hours
• Ignoring nonstationarity can lead to serious
  model and output errors
• Already seen this enhanced call center, Models
  5-2, 5-3

19
Nonstationary Poisson Processes Definition

• Usual model nonstationary Poisson process
• Have a rate function l(t)
• Number of events in t1, t2 Poisson with mean
• Issues
• How to estimate rate function?
• Given an estimate, how to generate during
  simulation?

l(t)
t
20
Nonstationary Poisson Processes Estimating the
Rate Function

• Estimation of the rate function
• Probably the most practical method is piecewise
  constant
• Decide on a time interval within which rate is
  fixed
• Estimate from data the (constant) rate during
  each interval
• Be careful to get the units right
• Other (more complicated) methods exist in the
  literature

21
Nonstationary Poisson Processes Generation

• Arena has a built-in method to generate, assuming
  a piecewise-constant rate function
• Arrival Schedule in Create module Models 5-2,
  5-3
• Method is to invert a rate-one stationary Poisson
  process against the cumulate rate function L
• Similar to inverting CDF for continuous
  random-variable generation
• Exploits some speed-up possibilities
• Details in Help topic Non-Stationary Exponential
  Distribution
• Alternative method thinning of a stationary
  Poisson process at the peak rate

22
Variance Reduction

• Random input Þ random output (RIRO)
• In other words, output has variance
• Higher output variance means less precise results
• Would like to eliminate or reduce output variance
• One (bad) way to eliminate replace all input
  random variables by constants (like their mean)
• Will get rid of random output, but will also
  invalidate model
• Thus, best hope is to reduce output variance
• Easy (brute-force) variance reduction just
  simulate some more
• Terminating additional replications
• Steady-state additional replications or a
  longer run

23
Variance Reduction (contd.)

• But sometimes can reduce variance without more
  runs free lunch (?)
• Key unlike physical experiments, can control
  randomness in computer-simulation experiments via
  manipulating the RNG
• Re-use the same random numbers either as they
  were, in some opposite sense, or for a similar
  but simpler model
• Several different variance-reduction techniques
• Classified into categories common random
  numbers, antithetic variates, control variates,
  indirect estimation,
• Usually requires thorough understanding of model,
  code
• Will look only at common random numbers in detail

24
Common Random Numbers (CRN)

• Applies when objective is to compare two (or
  more) alternative configurations or models
• Interest is in difference(s) of performance
  measure(s) across alternatives
• Model 7-2 (small mfg. system), total avg. WIP
  output two alternatives
• A. Base case (as is)
• B. 3.5 increase in business (interarrival-time
  mean falls from 13 to 12.56 minutes)
• Same run conditions, but change model into Model
  12-1
• Remove Output File Total WIP History.dat
• Add entry to Statistic module to compute and save
  to a .dat file the total avg. WIP on each
  replication

25
The Natural Comparison

• Run case A, make the change to get to case B and
  run it, then Compare Means via Output Analyzer
• Difference is not statistically significant
• Were the runs of A and B statistically
  independent?
• Did we use the same random numbers running A and
  B?
• Did we use the same random numbers intelligently?

26
CRN Intuition

• Get sharper comparison if you subject all
  alternatives to the same conditions
• Then observed differences are due to model
  differences rather than random differences in the
  conditions
• Small mfg. system For both A and B runs, cause
• The same parts arrive at the same times
• Be assigned same attributes (job type)
• Have the same process times at each step
• Then observed differences will be attributable to
  system differences, not random bounce
• There isnt any random bounce

27
Synchronization of Random Numbers in CRN

• Generally, get CRN by using the same RNG, seed,
  stream(s) for all alternatives
• Already are using the same stream, default
  stream 10
• But its usage generally gets mixed up across
  alternatives
• Must use the same random numbers for the same
  purposes across the alternatives
  synchronization of random-number usage
• Usually requires some work, understanding of
  model
• Usually use different streams in the RNG
• Usually different ways to do this in a given
  model
• Sometimes cant synchronize completely for
  complex models settle for partial
  synchronization

28
Synchronization of Random Numbers in CRN
(contd.)

• Synchronize by source of randomness (well do)
• Assign stream to each point of variate generation
• Separate random-number faucets extra
  parameter in r.v. calls
• Model 12-1 14 sources of randomness, separate
  stream for each (see book for details), modify
  into Model 12-2
• Fairly simple but might not ensure complete
  synchronization still usually get some benefit
  from this
• Synchronize by entity (wont do see Exercises)
• Pre-generate every possible random variate an
  entity might need when it arrives, assign to
  attributes, used downstream
• Better synchronization insurance but uses more
  memory
• Across replications, RNG automatically goes to
  next substream within each stream
• Maintains synchronization if alternatives
  disagree on number of random numbers used per
  stream per replication

29
Effect of CRN
Natural Comparison
Synchronized CRN

• CRN was no more computational effort
• Effect here is fairly dramatic, but it will not
  always be this strong
• Depends on how similar A and B are

30
CRN Statistical Issues

• In Output Analyzer, Analyze gt Compare Means
  option, have choice of Paired-t or Two-Sample-t
  for c.i. test on difference between means
• Paired-t subtracts results replication by
  replication must use this if doing CRN
• Two-Sample-t treats the samples independently
  can use this if doing independent sampling, often
  better than Paired-t
• Mathematical justification for CRN
• Let X output r.v. from alternative A, Y
  output from B
• Var(X Y) Var(X) Var(Y) 2 Cov(X, Y)

31
Other Variance-Reduction Techniques

• For single-system simulation, not comparisons
• Antithetic variates make pairs of runs
• Use Us on first run of pair, 1 Us on
  second run of pair
• Take average of two runs negatively correlated,
  reducing variance of average
• Like CRN, must take care to synchronize
• Control variates
• Use internal variate generation to control
  results up, down
• Indirect estimation
• Simulation estimates something other than what
  you want, but related to what you want by a fixed
  formula

32
Sequential Sampling

• Always try to quantify imprecision in results
• If imprecision is small enough, youre done
• If not, need to do something to increase
  precision
• Just saw one way variance-reduction techniques
• Obvious way to increase precision keep
  simulating one more step at a time, quit when
  you achieve desired precision
• Terminating models step another replication
• Cannot extend length of replications thats
  part of the model
• Steady-state models
• step another replication if using truncated
  replications, or
• step some extension of the run if using batch
  means

33
Sequential Sampling Terminating Models

• Modify Model 12-2 (small mfg., base case, with
  random-number streams) into Model 12-3
• Made 25 replications, get 95 c.i. on expected
  average Total WIP as 13.03 1.28
• Suppose the 1.28 is too big want to reduce to
  0.5
• Approximate formulas from Sec. 6.3 need 124 or
  164 total replications (depending on which
  formula) rather than 25
• Instead, just make one more at a time, re-compute
  c.i., stop as soon as half-width is less than 0.5
• Trick Arena to keep making more replications
  until c.i. half-width lt tolerance 0.5

34
Sequential Sampling Terminating Models
(contd.)

• Recall With gt 1 replication, automatically get
  cross-replication 95 c.i.s for expected values
  in Category Overview report
• Related internal Arena variables
• ORUNHALF(Output ID) half-width of 95 c.i.
  using completed replications (Output ID Avg
  Total WIP)
• MREP total number of replications asked for
  (initially, MREP Number of Replications in Run
  gt Setup gt Replication Parameters)
• NREP replication number now in progress ( 1,
  2, 3, )
• Use, manipulate these variables

35
Sequential Sampling Terminating Models
(contd.)

• Initially set MREP to huge value in Number of
  Replications in Run gt Setup gt Replication
  Parameters
• Keep replicating until we cut off when half-width
  0.5
• Add logic (in a submodel) to sense when done
• Create one control entity at beginning of each
  replication
• Control entity immediately checks to see if
• NREP 2 This is beginning of 1st or 2nd
  replication
• ORUNHALF(Avg Total WIP) gt 0.5 c.i. on completed
  replications is still too big
• In either case, keep going with this replication
  (and the next one too) control entity is
  Disposed and takes no action
• If both conditions are false, Control entity
  Assigns MREP NREP to stop after this
  replication, and is Disposed

36
Sequential Sampling Terminating Models
(contd.)

• Details
• This overshoots required number of replications
  by one
• In Assign module setting MREP to NREP, have to
  select Type Other since MREP is a built-in
  Arena variable
• Results Stopped with 232 total replications,
  yielding half width 0.49699 (barely less than
  0.5)
• Different from earlier number-of-replications
  approximations (theyre just that)
• Generalizations
• Precision demands on several outputs
• Relative-width stopping (half-width) / (pt.
  estimate) small

37
Sequential Sampling Steady-State Models

• If doing truncated-replications approach to
  steady-state statistical analysis
• Same strategy as above for terminating models
• Warm-up Period specified in Run gt Setup gt
  Replication Parameters
• Err on the side of too much warmup
• Point-estimator bias is especially dangerous in
  sequential sampling
• Getting tight c.i. centered in the wrong place
• The tighter the c.i. demanded, the worse the
  coverage probability

38
Sequential Sampling Steady-State Models
(contd.)

• Batch-means approach
• Model 12-4 modification of Model 7-4 (small mfg.
  system) want half-width on E(average WIP) to be
  lt 1
• Keep extending the run to reduce c.i. half-width
• Use automatic run-time batch-means 95 c.i.s
• Stopping criterion Terminating Condition field
  of Run gt Setup gt Replication Parameters
• Half-width variables are THALF(Tally ID) or
  DHALF(Dstat ID)
• For us, condition is DHALF(Total WIP) lt 1
• Remove all other stopping devices from model
• If Insuf or Corr would be returned because of
  too little data, half-width variables set to huge
  value keep going
• Could demand multiple smallness criteria,
  relative precision (TAVG, DAVG variables for
  point-estimate denominator)

39
Designing and Executing Simulation Experiments

• Think of a simulation model as a convenient
  testbed or laboratory for experimentation
• Look at different output responses
• Look at effects, interaction of different input
  factors
• Apply classical experimental-design techniques
• Factorial experiments main effects,
  interactions
• Fractional-factorial experiments
• Factor-screening designs
• Response-surface methods, metamodels
• CRN is blocking in experimental-design
  terminology
• Process Analyzer (PAN) provides a convenient way
  to carry out a designed experiment
• See Chapt. 6 for an example of using PAN for a
  factorial experiment
