NOISE CONTROLS FOR UNDERGROUND MINING

1
NOISE CONTROLSFOR UNDERGROUND MINING
2
SOURCE PATH RECEIVER
3
NOISE EXPOSURE CAN BE REDUCED BY

• APPLYING CONTROLS TO THE SOURCE (S)
• BLOCKING THE PATH (S)
• ENCLOSING THE RECEIVER

4
FLIGHTS CAN BE ISOLATED FROM PAN / CONVEYOR
WEAR STEEL
VIBRATION DAMPING MATERIAL
5
FLIGHTS ARE HELD IN PLACEON THE BOTTOM OF THE PAN
WEAR STEEL
VIBRATION DAMPING
6
THE MINED MATERIAL LAYS BETWEEN THE WEAR STRIPS
AND FURTHER HELPS TO REDUCE THE SOUND
7
VENTILATION FANSSHOULD BE KEPT ISOLATED FROM
FACE AREA
8
Fan Silencers Should be Inspected and Cleaned as
Necessary
9
SOUND ABSORPTIVE MATERIALS CAN BE INSTALLED
10
MUFFLERS CAN BE COVEREDDOORS CAN BE TREATED
11
EXHAUST SYSTEMS SHOULD BE MAINTAINED
12
Original Equipment Manufacturers Cabs
Jumbo Drill
L H D
13
OEM CABS ARE BECOMING MORE COMMONIN UNDERGROUND
MINING
LHD
SCALER
14
CABS CAN ALSO BE FABRICATEDAND ACOUSTICALLY
TREATED
15
BARRIERS CAN BE USED TO BLOCK SOUND LEVELS
EMITTED BY UNDERGROUND MINING EQUIPMENT
16
(No Transcript)
17
HERE ARE TWO EXAMPLES OF THE USE OF BARRIERS
JUMBO DRILL
SCALER
18
CENTRAL MONITORING OF UNDERGROUND LOCATIONS
19
Additional Resources
www.msha.gov/1999noise/Guides/SurftotalFinal.pdf
20
Your children can whisper to you now, Dont
make them shout at you in the future
