Tecniche per lanalisi di mutazioni

• Vincenzo Nigro
• Dipartimento di Patologia Generale, Seconda
  Università degli Studi di Napoli

Telethon Institute of Genetics and Medicine
(TIGEM)
2
What is a mutation?

• a variation of the DNA sequence.
• ..that is only found in affected individuals
• ..that is never found in non affected individuals
• ..that accounts for the pathological
  process/status
• ..that, when corrected in time, disease is
  rescued

3
..that is only found in affected and that is
never found in non affected

• incomplete penetrance

that is more often found in affected than in non
affected...
4
50.000 private variants innocuous differences
belonging to one family
5
1-allele diseases

• monoallelic mutations may be responsible for
  dominant or X-linked disorders
• new random mutations are the rule with an
  unpredictable pattern of distribution

6
gender effect in mutations

• For mutations other than point mutations, sex
  biases in the mutation rate are very variable
• Small deletions are more frequent in females
• Germline base substitution mutations occur more
  frequently in males than in females, especially
  in older males
• Point mutations at some loci occur almost
  exclusively in males, whereas others occur ten
  times more than in females

7
relative frequency of de novo achondroplasia for
different paternal ages
8
 Relative frequency of de novo neurofibromatosis
for different paternal ages
9
the number of male germ-cell divisions
10
(No Transcript)
11
2-allele diseases

• novel mutations are rare, usually mutations have
  a long history (100-1000 generations)
• mutations have an ethnical signature with a
  predictable pattern of distribution and frequency
• biallelic mutations may be responsible for
  autosomal recessive disorders
• polymorphisms and private variants are more
  easily discriminated vs true mutations

12
2-allele diseases

• consanguineity is a risk factor for homozygosity
• high carrier frequency is a risk factor for
  compound heterozygosity

13
The effect of an allele

• null or amorph no product
• hypomorph reduced amount / activity
• hypermorph increased amount / activity
• neomorph novel product / activity
• antimorph antagonistic product / activity

14
Mutation detection

• mutation scanning
• or resequencing methods for identifying
  previously unknown mutations
• genotyping
• methods for scoring previously known mutations or
  single nucleotide polymorphisms (SNPs)

15
Key questions for mutation detection strategy

• expected mutations are monoallelic or biallelic?
• is the gene well recognized for that disease?
• is the mutation pattern known? (deletion, dup,
  small mutations, etc.)
• which is the complexity of the gene?
• how many patients must be examined?
• how many controls should be examined?
• how many mutations and how many variations have
  already been identified in this gene?
• are there more members of the same gene family
  (or pseudogenes) in the genome?

16
Dimension of the mutation detection study
Number of patients
Gene size
X
Number of controls
17
General strategy for mutation detection
frequent mutations are known?
screening of recurrent mutations
YES
NO
mutation scanning
SEQUENCING
18
Log-PCR 4 multiplex-PCR (2x202x18) with
uniform spacing and gel position according to
chromosomal position
1 2 3 4 5 6
19
MLPA ligation

• Probes are ligated by a thermostable ligase

20
PCR amplification

• A universal primer pair is used to amplify all
  ligated probes
• The PCR product of each probe has a unique length
  (130 480 bp)

21
Separation and quantification by capillary
electrophoresis
Each peak is the amplification product of a
specific probe. Samples are compared to a
control sample. A difference in relative peak
height or peak area indicates a copy number
change of the probe target sequence
22
MLPA can be used to detect known mutations
Mismatch
Perfect match
Ligation of the two probe oligonucleotides ?
Amplification product
Mismatch at the probe ligation site ? No
ligation, no amplification product
23
MS-MLPA
Only undigested (methylated) and ligated probes
are exponentially amplified
24
Molecular inversion probe (MIP) genotyping

• MIP genotyping uses circularizable probes with 5'
  and 3' ends that anneal upstream and downstream
  of the SNP site leaving a 1 bp gap
• Polymerase extension with dNTPs and a
  non-strand-displacing polymerase is used to fill
  in the gap

25

• Ligation seals the nick, and exonuclease I is
  used to remove excess unannealed and unligated
  circular probes
• The resultant product is PCR-amplified and the
  orientation of the primers ensures that only
  circularized probes will be amplified
• The resultant product is hybridized and read out
  on an array of universal-capture probes

26
GoldenGate genotyping assay

• GoldenGate uses extension ligation between
  annealed locus-specific oligos (LSOs) and
  allele-specific oligos (ASOs)
• An allele-specific primer extension step is used
  to preferentially extend the correctly matched
  ASO (at the 3' end) up to the 5' end of the LSO
  primer
• Ligation then closes the nick

27
GoldenGate genotyping assay

• A subsequent PCR amplification step is used to
  amplify the appropriate product using common
  primers to built-in universal PCR sites in the
  ASO and LSO sequences
• The resultant PCR products are hybridized and
  read out on an array of universal-capture probes

28
PTTprotein truncation test

• Sensitivity 1000-bp fragment gt 85
• Detects only nonsense mutations
• Post PCR time 48-72 hours (translation/trascript
  ion, gel preparation, loading and run, analysis
  of results)
• Use of 35S radioactivity
• No special equipment required
• mRNA as starting template

29

30

31
Applications of PTT( of truncating mutations)

• Polycystic Kidney Disease PKD1 95
• Familial Adenomatous Polyposis APC 95
• Ataxia telangiectasia ATM 90
• Hereditary breast and ovarian cancer BRCA1-2 90
• Duchenne Muscular Dystrophy DMD 90
• Fanconi anemia FAA 80
• Hereditary non-polyposis colorectal cancer
  hMSH1-2 70-80
• Neurofibromatosis type 2 NF2 65
• Hunter Syndrome IDS 50
• Neurofibromatosis type 1 NF1 50
• Cystic Fibrosis CFTR 15

32
SSCP
33
Mutation detection by heteroduplex analysis the
mutant DNA must first be hybridized with the
wild-type DNAto form a mixture of two
homoduplexes and two heteroduplexes
34
Heteroduplex analysis
35
DHPLCdenaturing HPLC from Transgenomic
36
DHPLC analysis at different temperatures of the
column
37
DHPLC analysis of the CAPN3 gene (exon 11)
12
14
16
18
110
38
Sequencing artifacts

• FALSE POSITIVE (specificity)
• when searching for heterozygous DNA differences
  there are a number of potential mutations,
  together with sequence artifacts, compressions
  and differences in peak intensities that must be
  re-checked with additional primers and costs
• FALSE NEGATIVE (sensitivity)
• loss of information farther away or closer to the
  primer
• does not detect a minority of mutant molecules in
  a wild-type environment

39
Sanger DNA sequencing
40
(No Transcript)
41

• Massive parallel DNA sequencing

42
454 technology a water-in-oil emulsion is
created a single molecule of DNA with a single
bead
43
454 technology Beads with clones are selected
and assembled onto a planar substrate
44
(No Transcript)
45
454 technology Sequencing by synthesis pyrosequen
cing
Up to 100 Million bp in 8 hours can be
read Ambiguities arise for homopolymeric tracts
46
Emulsion PCR or Bridge PCR?
47
(No Transcript)
48
(No Transcript)
49
7.4 x coverage 234 runs 24.5 billions bp
50
NimbleGen sequence capture
51
11 genetic diseases !!
