Operations Management Layout Strategy Chapter 9

1
Operations ManagementLayout StrategyChapter 9
2
Outline

• Strategic Importance of Layout Decisions.
• Fixed-Position Layout.
• Office Layout.
• Process-Oriented Layout (Flow graphs).
• Retail Layout.
• Warehouse Layout.
• Product-Oriented Layout (Assembly line
  balancing).

3
What is Facility Layout

• Location or arrangement of everything within
  around buildings.
• Objectives are to maximize
• Utilization of space, equipment, people.
• Efficient flow of information, material,
  people.
• Employee morale safety.
• Trend is towards flexible and dynamic layouts.

4
Facility Layout

• Helps achieve competitive advantage
• Better, faster, cheaper.
• Determines productivity, cost, quality,
  flexibility, image, etc.
• May involve a blend of strategies.

5
Six Layout Strategies

• 1. Fixed-position layout.
• For large unique projects such as ships and
  buildings.
• 2. Office layout.
• Positions workers, equipment, and spaces/offices
  to provide for movement of information and
  material.
• 3. Process-oriented layout.
• For low-volume, high-variety production.

6
Six Layout Strategies - continued

• 4. Retail/service layout.
• Arranges facility and allocates shelf space in
  light of customer behavior.
• 5. Warehouse layout.
• Addresses trade-offs between space utilization
  and material handling.
• 6. Product-oriented layout.
• For repetitive or continuous production.

7
Layout Strategies
8
Layout Strategies
9
Requirements for a Good Layout

• Understand capacity and space requirements.
• Understand information flows.
• Understand cost of people and product flows.
• Select appropriate material handling equipment.
• Consider environment and aesthetics.
• Consider safety and regulations.

10
Constraints on Layout Objectives

• Product/service design.
• Volume of business.
• Process equipment capacity.
• Quality of work life.
• Building and site.

11
1. Fixed-Position Layout

• Project is stationary.
• Special purpose Construction, shipbuilding, etc.
• Workers and equipment come to site.
• Complicating factors.
• Limited space at site.
• Changing material needs.
• Unique projects.

12
2. Office Layout

• Positions people, equipment, offices.
• Usually for maximum information flow.
• Also can consider material flow.
• Arranged by process or product.
• Example Payroll dept. is by process.
• Different cultures have different expectations
  for space.
• Relationship (or proximity) chart used.

13
Relationship (Proximity) Chart

• Uses 6 levels to express desired proximity.
• A Absolutely necessary
• E Especially important
• I Important
• O Ordinary importance
• U Unimportant
• X Not desirable

14
Relationship (Proximity) Chart
15
Relationship (Proximity) Chart
Can determine layout using proximity diagram
16
Office Layout
Locate 5 offices in a rectangular space. Offices
2-5 are to be same size. Office 1 (Presidents)
is twice as large.
17
Office Layout
Presidents
Photocopiers
Secretary
(5)
(4)
President
Corridor
(1)
Engineering
Costing
(3)
(2)
18
3. Process-Oriented Layout

• Place departments with large flows of material or
  people close together.
• Similar processes and equipment are located in
  close proximity.
• For example, all x-ray machines in same area.
• Used with process-focused processes.
• Low volume, high variety.

19
Emergency Room Layout
20
Process-Oriented Layout Advantages

• Flexibility.
• Allows wide variety of products.
• Low fixed costs for general purpose equipment.
• Breakdown of one machine or worker does not stop
  processing.

21
Process-Oriented Layout Disadvantages

• Scheduling is difficult.
• High variable cost.
• High work-in-process inventory and waiting.
• High labor skills required.

22
Developing a Process-Oriented Layout by Hand

• Goal Minimize cost of moving between
  departments.
• Construct a from-to matrix.
• Determine space requirements for each department.
• Develop an initial layout and try to place
  departments with large flows close together.
• Determine the cost of this initial layout.
• Improve the initial layout (by hand or more
  sophisticated means).
• Consider factors in addition to transportation
  cost.

23
Cost of Process-Oriented Layout
24
Flows of Parts (loads/week)
to
from
25
Interdepartmental Flow of Parts
Number of loads/week between departments
26
Initial Layout
Room 1 Room 2 Room 3
Room 4 Room 5 Room 6
27
Initial Layout Flow Graph Showing Loads/Week
28
Cost of Initial Layout
Cost per load for adjacent locations 1 Cost
per load for non-adjacent locations 2
1-2 50 501 1-3 200 1002 1-6 40
202 2-3 30 301 2-4 50 501 2-5
10 101 3-4 40 202 3-6 100
1001 4-5 50 501 Total 570
29
Large Flows in Initial Layout
100
2
1
3
50
30
20
100
50
20
10
4
5
6
50
Largest Flows 100 for 1-3 3-6, so put 3 close
to 1 and 6. 50 for 1-2, 2-4 4-5 ,
30
Improved Layout Flow Graph
100
31
Improved Layout
Room 1 Room 2 Room 3
Printing
Assembly
Machine shop
Department
Department
Department
(2)
(1)
(3)
Receiving
Shipping
Testing
Department
Department
Department
(4)
(5)
(6)
Room 4 Room 5 Room 6
32
Cost of Improved Layout
Cost per load for adjacent locations 1 Cost
per load for non-adjacent locations 2
1-2 50 501 1-3 100 1001 1-6 20
201 2-3 60 302 2-4 50 501 2-5
10 101 3-4 40 202 3-6 100
1001 4-5 50 501 Total 480
30
2
3
1
100
50
100
20
50
20
10
4
5
6
50
33
Alternative Improved Layout
34
Cost of Alternative Improved Layout
Cost per load for adjacent locations 1 Cost
per load for non-adjacent locations 2
1-2 50 501 1-3 100 1001 1-6 40
202 2-3 30 301 2-4 50 501 2-5
20 102 3-4 20 201 3-6 100
1001 4-5 50 501 Total 460
Is this best?
35
Alternative Improved Layout
Room 1 Room 2 Room 3
Assembly
Machine shop
Testing
Department
Department
Department
(1)
(3)
(6)
Printing
Shipping
Receiving
Department
Department
Department
(2)
(5)
(4)
Room 4 Room 5 Room 6
36
Layout Example 2
Given the following tables of interdepartmental
flows and distances between locations A-E, locate
the five departments to minimize the total
distancexflow.
Interdepartmental flows
37
Layout Example 2
Largest flow 1-3 (flow18) should be in closest
locations CD Could have Solution 1 C1 and
D3 or Solution 2
C3 and D1
Interdepartmental flows
38
Layout Example 2
Next largest flow is 2-3, so 2 should be placed
in location closest to 3. Solution 1 D3 and
closest open location to D is B, so B2, C1,
D3. Solution 2 C3 and closest open
location to C is A, so A2, C3, D1.
Interdepartmental flows
39
Layout Example 2
Next largest flow is 1-2, but 1 and 2 are already
located. So consider next largest flow
2-5. Solution 1 B2 and closest open location to
B is E, so A4,B2,C1, D3,E5. Solution 2
A2 and closest open location to A is B, so
A2,B5,C3, D1,E4.
Interdepartmental flows
40
Layout Example 2
Solution 1 A4,B2,C1, D3,E5. Distance
13x9 18x4 3x8 15x6 6x7 4x14 4x14
457 Solution 2 A2,B5,C3, D1,E4. Distance
13x12 18x4 3x14 15x8 6x9 4x9 4x7
508
Solution 1 is best!
Interdepartmental flows
41
Computer Programs for Layout

• Many different programs
• CRAFT
• SPACECRAFT
• CRAFT 3-D
• CORELAP
• ALDEP
• All are heuristic - not necessarily optimal!!

42
Work Cells in Process Layouts

• Special case of product-oriented layout - in a
  process-oriented facility.
• Different machines brought together to make a
  product.
• Use when high volume warrants special
  arrangement.
• For 1 product or a small group of products.
• Temporary arrangement.
• Example Assembly line set up to produce 3000
  identical parts in a job shop.

43
Work Cell Floor Plan
44
Work Cell Advantages
Lower Inventory. Floor space. Direct labor
costs.
Higher Equipment utilization. Employee
participation. Quality.
45
Work Cells, Focused Work Centers and the Focused
Factory
Work Cell
A temporary assembly-line-oriented arrangement of
machines and personnel in what is ordinarily a
process-oriented facility.
Focused Work
A permanent assembly-line-oriented arrangement of
machines and personnel in what is ordinarily a
process-oriented facility.
Center
A permanent facility to produce a product or
component in a product-oriented facility.
Focused Factory
46
4. Retail/Service Layout

• Maximize product exposure to customers.
• Maximize profitability per square foot of floor
  space or per linear foot of shelf space.
• Decision variables
• Arrangement of store.
• Store flow pattern.
• Allocation of (shelf) space to products.

47
Retail Layouts - Rules of Thumb

• Locate high-draw items around the periphery.
• Use prominent locations (end aisle locations
  first or last aisle) for high-impulse and high
  margin items.
• Remove crossover aisles to prevent customers from
  moving between aisles.
• Distribute power items (that dominate a
  shopping trip) around store to increase the
  viewing of other items.
• Locate far apart.
• Locate on both sides of an aisle.

48
Grocery Store Layout
49
Retail Store Shelf Space

• Consider prominence of shelf location and number
  of facings.
• Can use computerized tools to manage shelf-space.
• Track sales and product location (scanner data).

50
Servicescape Considerations

• Ambient conditions.
• Background characteristics such as lighting,
  sound, smell, and temperature.
• Spatial layout and functionality.
• Customer circulation, aisle width, shelf spacing,
  etc.
• Signs, Symbols, and Artifacts.
• Various other characteristics of design
  (carpeting, greeters, etc.).

51
5. Warehouse Layout

• Balance space utilization handling cost.
• Similar to process layout.
• Items moved between loading docks various
  storage areas.
• Optimum layout depends on
• Variety of items stored.
• Number of items picked.

52
Space Utilization vs. Handling Costs

• High space utilization (for storage).
• Small, narrow aisles.
• Product stacked high and deep (not easily
  accessible).
• Ease of material handling.
• Wide, short aisles.
• Product easily accessible.
• Design facility to optimize space utilization and
  handling costs tradeoff.

53
Assigned vs. Random Stock Locations

• Assigned locations for products
• May be inefficient use of space.
• Easier order picking and re-stocking.
• Random locations
• More efficient use of space.
• Added costs to track location of inventory and
  open space.
• More difficult order picking and re-stocking.
• Stock products to optimize cost and efficiencies
  tradeoffs.

54
Cross Docking (Wal-Mart)

• Transferring goods
• From incoming trucks at receiving docks.
• To outgoing trucks at shipping docks.
• Avoids placing goods into storage.
• Requires suppliers provide effective addressing
  (bar codes) and packaging for rapid transshipment.

55
Order Picking

• Collecting items on a customer order from various
  locations in the warehouse.
• Sequence items to minimize travel time in
  warehouse to pick order.
• Also, should locate items to be efficient to
  pick.
• Combine several orders to reduce picking time.
• Zoning Assign separate pickers to different
  zones in the warehouse.
• Split order among several pickers.

56
6. Product-Oriented Layout

• Used with product-focussed processes.
• Facility organized around product.
• High volume, low variety.
• Types
• Fabrication line - Builds components.
• Assembly line - Assembles components into
  products.

57
Product-Oriented Layout

• Divide work into small tasks. To be done by
  workers or machines.
• Assign tasks to workstations.
• Balance output of each workstation.
• To smooth operations of the line.
• To make workload equal.
• To minimize idle time.
• To achieve desired output.

58
Product-Oriented Requirements

• Standardized product.
• High production volume.
• Stable production quantities.
• Uniform quality of raw materials components.

59
Product-Oriented Layout Advantages

• Lower variable cost per unit.
• Lower material handling costs.
• Lower work-in-process inventories.
• Rapid throughput.
• Easier training supervision.

60
Product-Oriented Layout Disadvantages

• Higher capital investment for special equipment.
• Any work stoppage stops whole process.
• Lack of flexibility in volume and product.

61
Repetitive Layout
Note 5 tasks or operations (T1-T5) 3 work
stations (orange rectangles)
62
Assembly Line Balancing Steps

• 1. Determine tasks (operations) task times.
• 2. Determine sequence of tasks.
• 3. Draw precedence diagram.
• 4. Calculate cycle time .
• 5. Calculate minimum number of work stations, N.
• 6. Assign tasks.
• 7. Calculate efficiency.

63
Assembly Line Balancing Data

• Usually we are given
• Production rate.
• Units of product to be produced per unit time.
• Production time available per day.
• Tasks (operations) task times.
• Sequence of tasks.

64
Assembly Line BalancingGeneral Procedure

• 1. Determine cycle time - The time between
  production of successive units. (May be measured
  in seconds, minutes, etc.)
• 2. Calculate the theoretical minimum number of
  workstations, denoted N. (May not be achievable.)

• 3. Assign tasks to workstations to balance the
  line. Compute the efficiency.

65
Assembly Line Balancing Equations

Production time available
Cycle time
Production rate
Minimum number of work stations
?? Task times
Rounded up

N

Cycle time
?? Task times
Efficiency
(Actual number of work stations)
(Cycle time)
66
Assembly Line Balancing Example
Suppose we want to produce 300 units/day and 8
hours are available each day.
67
Assembly Line Balancing Example
Suppose we want to produce 300 units/day and 8
hours are available each day.
So assign tasks A-E to 2 workstations, where
neither workstation should exceed 1.6 minutes.
68
Assembly Line Balancing Example
Suppose we want to produce 300 units/day and 8
hours are available each day.
Can not use only 2 workstations! Must use
3. Efficiency2.5/(31.6) 52.1
69
Assembly Line Balancing Example
Both of these can produce 300/day in 8 hours.
Efficiency2.5/(31.6) 52.1
Better balance!
Efficiency2.5/(31.6) 52.1
Note this line could produce 300 units in 5
hours (1 per minute) Efficiency2.5/(31.0)
83.3
70
Assembly Line Balancing Example
If 2 workstations were required, then it will
take more than 8 hours to produce 300 units.
Cycle time 1.7 minutes Efficiency2.5/(21.7)
73.5
Time to produce 300 units 1.7 min/unit300 units
510 minutes 8.5 hours
71
Assembly Line Balancing Heuristics

• Longest (or shortest) task time.
• Choose task with longest (or shortest) operation
  time.
• Most following tasks.
• Choose task with largest number of following
  tasks.
• Ranked positional weight.
• Choose task where the sum of the times for each
  following task is longest.
• Least number of following tasks.
• Choose task with fewest subsequent tasks.

72
Ranked Positional Weight Heuristic

• Positional weight Sum of times for a task and
  all tasks that must follow it.
• 1. Calculate positional weight for each task.
• 2. Assign task with largest positional weight to
  the earliest workstation where it fits.
• - Obey precedence relations.
• - Do not exceed cycle time.
• 3. Repeat step 2 until all tasks are assigned.

73
Line Balancing Example 2
Suppose we want to produce 450 units/day and 8
hours are available each day.
74
Line Balancing Example 2
Suppose we want to produce 450 units/day and 8
hours are available each day.
75
Precedence Diagram - Example 2
0.2
A
0.6
B
1.0
0.5
E
0.9
C
G
0.3
0.2
D
F
76
Example 2 - Positional Weight
77
Example 2 - Assign Tasks
Cycle time 1.07 min. N 4 workstations
WS1 WS2 WS3 WS4 C(0.5) A(0.2)
78
Example 2 - Assign Tasks (cont.)
Cycle time 1.07 min. N 4 workstations
WS1 WS2 WS3 WS4 C(0.5) B(0.6) A(0.2)
D(0.3)
79
Example 2 - Assign Tasks (cont.)
Cycle time 1.07 min. N 4 workstations
WS1 WS2 WS3 WS4 C(0.5) B(0.6) E(1.0)
G(0.9) A(0.2) F(0.2) D(0.3)
Efficiency 3.7/(41.07) 86.4
80
Precedence Diagram - Example 2
0.2
A
0.6
WS3
B
1.0
0.5
E
0.9
C
G
0.3
WS4
0.2
D
F
WS1
WS2
81
Example 2 - Final Comment
Could use a cycle time of 1 minute produce 450
units in 7.5 hours
Efficiency 3.7/(41.0) 92.5
WS1 WS2 WS3 WS4 C(0.5) B(0.6) E(1.0)
G(0.9) A(0.2) F(0.2) D(0.3)
