The Geosphere

1
The Geosphere
2
What is the GEOSPHERE?

• All solid parts of Earth
• Rocks, soils, minerals, sediments, magma

The Grand Canyon, AZ
3
Layers of the Earth

• Geologists classify Earths layers two ways
  chemically and physically
• Chemical by composition
• Physical- by structure

Chemical Layers of the Earth

1. Crust- O, Si, Al
2. Mantle- O, Si, Mg, Fe
3. Core- Fe, Ni

4
Remember

• CruManCo
• Chemical Company

5
Physical Layers of the Earth

• Lithosphere
• Crust and upper mantle combined
• Broken in chunks called tectonic plates
• Oceanic plates are thinner and denser than
  continental plates
• Asthenosphere
• Layer of Jello-like magma in the mantle
• Tectonic plates move due to convection currents
  in the asthenosphere

6
Physical Layers, cont.

• Mesosphere
• The rest of the mantle molten rock
• Outer Core
• Liquid metal
• Surrounds inner core
• Inner Core
• Densest layer
• Solid metal

7
Remember

• LAMOI,
• The physical trainer

8
(No Transcript)
9
Theory of Plate Tectonics

• Lithosphere (upper mantle and crust) is divided
  into pieces called tectonic plates.
• These plates glide across the underlying
  asthenosphere like ice drifts across a pond.
• Continents are located on tectonic plates and
  move around with them

10
(No Transcript)
11
(No Transcript)
12
Plate Boundaries

• The area where two plates meet is called a plate
  boundary.
• Most earthquakes and volcanoes occur at or near
  plate boundaries
• Three main types of plate boundaries
• Divergent- separating
• Convergent- colliding
• Transform- scraping past

13
Tectonic Plates
Earthquakes Worldwide
Active Volcanoes
14
(No Transcript)
15
Transform Boundaries

• 2 plates slide past each other
• This sliding is not smooth. Plates lock and
  build up tension. After too much tension builds,
  the plates snap and move against each.
• Causes earthquakes

16
(No Transcript)
17
Divergent Boundaries

• When two plates separate
• Most common on ocean floor
• Creates Mid-Atlantic Ridge which is visible on
  land in Iceland

18
Divergence Forms New Ocean Floor
19
Convergent Boundaries

• Three Main Types
• Continental Oceanic- causes deep ocean trench
  and land
• volcanoes Ex Andes Mountains
• 2. Oceanic Oceanic- causes deep ocean trench
  and island arc
• (chain of volcanic mountains) Ex Mariana
  islands and Mariana
• trench
• 3. Continental Continental- causes
• large land mountain ranges
• Ex Himalayan Mountains

20
Subduction Zone Continental Oceanic Crust
21
Subduction ZoneOceanic Oceanic Crust
22
Subduction Zone Oceanic Oceanic Crust (another
view)
23
Continental Continental Crust
24
Some videos for your viewing pleasure

• Plate Movement
• http//www.youtube.com/watch?vryrXAGY1dmEfeature
  endscreenNR1
• San Andreas Fault
• http//www.youtube.com/watch?NR1vZxPTLmg0ZCwfe
  atureendscreen
