Title: Harmonization of the Common Information Model and MultiSpeak


1
Harmonization of the Common Information Model and
MultiSpeak
  • Gary McNaughton, P.E.
  • Cornice Engineering, Inc.
  • Robert Saint, P.E.
  • National Rural Electric Cooperative Association

2
Acknowledgements
  • The authors gratefully acknowledge their
    co-authors of IEC 61968-MultiSpeak
    Harmonization, a paper accepted for presentation
    at CIRED 2011. Material from that paper is
    included here. Co-authors include
  • Gerald Gray, Guiding Principle Consulting (USA)
  • John Simmins, EPRI (USA)
  • David Haynes, Aclara (USA)
  • Alan McMorran, Open Grid Systems, Ltd. (UK)
  • Eric Lambert, EDF (France)

3
Overview
  • What is MultiSpeak?
  • Why different standards?
  • What does harmonization mean?
  • Rationale for harmonization
  • Approach to harmonization
  • Results of early efforts
  • Harmonization deliverables

4
Introduction to MultiSpeak
  • Developed by NRECA in collaboration with key
    industry vendors
  • MultiSpeak Initiative is a group of about 70
    vendors that provide products and services to
    distribution utilities.
  • Standard is mature, scope is continuing to grow
  • Well defined, third-party compliance and/or
    interoperability testing program since 2001.
  • In use at over 600 utilities in at least 15
    countries
  • Standard based on UML class model, XML Schema and
    web services messaging

5
MultiSpeak Vendor Members
  • NISC
  • NorthStar Utilities Solutions
  • NRTC
  • Olameter, Inc.
  • Open Systems International
  • Oracle Utilities
  • OSIsoft
  • Ovace A Mamnoon
  • Papros, Inc.
  • Partner Software
  • Powel
  • Power System Engineering (PSE)
  • Professional Computer Systems (PCS)
  • Progress Software
  • QEI
  • R.W. Beck (SAIC)
  • SageQuest
  • SEDC
  • Sensus
  • ABB
  • Aclara (DCSI TWACS)
  • Albeado
  • ATS
  • AutoDesk
  • C3-Ilex
  • Capricorn Systems
  • Carina Technology, Inc.
  • Central Service Association
  • CGI
  • Cigital
  • Clevest Solutions
  • Cooper Power (Cannon Technologies)
  • Cooperative Fusion
  • Cooperative Response Center
  • Cornice Engineering
  • Daffron
  • EFACEC (Advanced Control Systems)
  • Elster Integrated Solutions

Dated 3/2011
6
Why there are different standards?
  • Partly historical
  • Partly due to fact that small utilities cant
    justify cost of participation in international
    standards groups, hence have been
    under-represented on IEC working groups
  • The different standards serve needs of different
    communities

7
CIM Users
  • CIM typically is implemented by large IOUs
  • With large IT staffs
  • Messaging middleware
  • Need to customize application interfaces to match
    existing business processes and legacy
    applications
  • This community values
  • Customizability and flexibility in messaging
    approach
  • The CIM approach assumes that
  • Messaging middleware exists
  • Interoperation within a utility is all that is
    required, except where interoperability among
    utilities is critical, (e.g., power system model
    exchange),

8
MultiSpeak Users
  • MultiSpeak integration is typically used by
    utilities looking for an out-of-the box
    solution
  • Often these are small utilities, often with few
    IT staff
  • Typically such utilities do not have ESB or
    messaging
  • Such utilities often value
  • Simple interoperable solutions that require
    little customizability default choices made in
    MultiSpeak work
  • Interoperation among utilities, not just within a
    utility
  • The MultiSpeak approach
  • Includes protocol features to address lack of
    messaging
  • Focuses on interoperation, but supports
    customization
  • Can be implemented over transports other than web
    services, although this acts against core value
    of interoperation

9
What does harmonization mean?
  • Harmonized standards Equivalent standards on the
    same subject approved by different
    standardization bodies, which allow for
    establishment of interchangeability of products,
    processes and services, and for mutual
    understanding of test results or information
    provided according to these standards
  • Source NIST Global Standards Information web
    site http//gsi.nist.gov/global/index.cfm/L1-5/L2
    -44/A-87

10
What harmonization is not
  • Unified Standards Two standards that move over
    time towards using the same data model and
    service definitions. The end result is that a
    single standard exists.
  • An example of this approach is the plan for
    unifying CIM and IEC 61850

11
Rationale for harmonization
  • Neither standard is complete, nor does either
    completely serve the needs of all portions of the
    industry.
  • CIM and MultiSpeak are complementary and
    semantically compatible but not interoperable.
  • Separate standards continue to be a stumbling
    block for utility implementations and for vendor
    community.
  • Small international utilities have the same needs
    as small US utilities, but may be constrained to
    use international standards no acceptable
    solution exists

12
Proposed approach to harmonization
Existing Situation
Proposed Approach
13
ESB adapter requires mapping
  • CIM message to MultiSpeak web service method
    mapping, including header fields
  • CIM payload to MultiSpeak payload mapping
  • Appropriate round-trip error handling

14
CIM on-demand meter reading
15
MultiSpeak on-demand meter reading
16
Message header mapping
17
Top-level object field mapping
MultiSpeak has added optional IdentifiedObject
fields in V4.x to facilitate harmonization
18
Meter reading payload mapping
19
Early results of EPRI harmonization project
  • Proof of concept ESB service is being developed
    for this use case
  • Early results are promising
  • Mapping is being developed for IEC 61968-9
    messages and corresponding MultiSpeak methods
  • Mapping with proof of concept ESB service is
    expected to be released in 2nd Qtr 2011

20
Planned harmonization documents
  • Series of mapping documents for IEC
    standardization, named IEC 61968-14-1-x, where x
    is the 61968 Part number.
  • Current plan is for 61968-14-1-9 (Metering and
    Control) and 61968-14-1-13 (CDPSM)
  • Series of profile documents to build MultiSpeak
    functionality using CIM classes and messaging,
    named 61968-14-2-x, where x is the 61968 Part.
  • Will identify gaps and strengths in both
    standards
  • Will accelerate development of missing CIM Parts

21
For Further Information, Contact
  • Gary McNaughton Bob Saint
  • Cornice Engineering, Inc. NRECA
  • P.O. Box 155 4301 Wilson Blvd.
  • Grand Canyon, AZ 86023 Arlington, VA 22203
  • Phone (928) 638-4062 (703) 907-5863
  • gmcnaughton_at_corniceengineering.com
    Robert.Saint_at_nreca.coop
  • www.MultiSpeak.org
