msr/csc

1
MAIN SUPPLY ROUTE CONVOY SUPPORT CENTER
SELECTION
PRIMARY INSTRUCTOR ________________________ ALTE
RNATE INSTRUCTOR ________________________
2
TASK Establish a primary Main Supply Route
(MSR) and determine possible TTP and CSC
requirements
CONDITION Given a class room enviroment with
a 1250,000 map board determine primary MSRs
and determine type and placement of appropriate
CSC locations.
STANDARD Upon completion each individual will
have a working knowledge of the difficulties,
and restrictions involved in determining a MSR
and adequate Support Center requirements.
3
RESOURCE REFERENCES
REFERENCES FM 55 - 30 FM 55 - 10 SAFETY BOOK FM
5 - 36
4
PRE-TEST
1. What are the three types of road
classifications as determined by STANAG 2174?
A) 1,2,3 B) X,Y,Z C)Traffic,
oversized, limited
2. The highest bridge road classification
determines the military load class of a
route. A) True B) False 3. When identifying
a prospective route for oversized use the
following limitations must be followed. A) 7gt
grades B) 10gtgrades C) 5gtgrades
D) 12gtgrades 25Mlt curve 50Mlt
curve 35Mlt curve 60Mltcurve
Class 120 Class 80
Class 50 Class 60
5
PRE-TEST
4. How is a tunnel depicted on a military map?
A) by a arrow from the symbol to the location
of the entrance B) by a half circle with arrow
from the symbol to the tunnel entrance C) by a
bridge symbol with an arrow above it
5. How many different types of Convoy Support
Centers are there? A) five B) four C)
three D) two 6. The third type
(Complete CSC stop) contains the following
support? A) 1,2,4,6,7, B) 1,2,3,4,5,6,7,8
C) 1,2,3,4,5,7,8 D) 1,2,3,4,5,6
1.latrines 2. water 3. fuel 4. maint
5.security 6. TTP area 7. showers 8. beds
6
PRE-TEST
7. International boundaries are depicted by the
following symbol on a military map or
overlay? A) B) ------------
C)
8. What is the map sheet number that you are
currently using? A) NM32-10 B) NM32-7 C)
NM32-4 D) NM31-9 9. What is the name
of the map sheet you are currently using? A)
METZ, B) SAARBRUCKEN C) TRIER D)
LUXEMBOURG
7
PRE-TEST
10. Determine the road distance from the town of
Contweg (LV 856565 ) to the town of Sarnstall
(MV 228515) along route 10. A) 26 MILES
B) 29.5 MILES C) 28.5 MILES
8
MAP RECON
Maps provide a basic source of terrain
information. The reliability of a map is
determined by the data used to prepare it. Maps
are supplemented by aerial or ground photos,
sketches, and visual observation. Special maps
and overlays are designed for specific purposes,
such as trafficability, transportation
facilities, and soils, and are of particular
value in terrain evaluation.
9
ROUTE PLANNING FACTORS
OVERSIZED VEHICLES HEIGHT 4.5 M WIDTH 3.7
M WEIGHT(LOADED) 110 TONS
10
(No Transcript)
11
HIGHWAY TRAFFIC PRINCIPLES

• ASSIGN PRIORITY BASED ON TIME-DISTANCE
• CONSIDER SUSTAINMENT CAPABILITY OF THE MSR
• SEPARATE TRAFFIC FROM PEDESTRIANS
• SEPARATE CIVILIAN AND MILITARY TRAFFIC

12
MAIN SUPPLY ROUTE CRITERIA AND SELECTION

• CAPABLE OF SUPPORTING TRAFFIC VOLUME
• NORMALLY BEST ROUTE
• MUST INCLUDE ALTERNATES
• RECOMMENDED MOVEMENT PLANNER
• APPROVED BY G - 3

• MSR SELECTION CRITERIA IS BASED ON
• ROAD CHARACTERISTICS
• VEHICLE CHARACTERISTICS
• SUPPLY CLASSIFICATION
• DELIVERY TIME-LINE AND SPECIAL REQUIREMENTS

13
RECON FACTORS IN SELECTION OF MSRS
14
MSR PROBLEM AREAS

• ESTABLISH CHECKPOINTS
• GEOGRAPHIC BOUNDARIES
• TERMINALS/SUPPLY POINTS/CRITICAL POINTS
• REGULATE AND CONTROL MOVEMENT
• SEGMENT THE MSR INTO MANAGEABLE BLOCKS

• DETERMINE CRITICAL POINTS
• LIMITING ROADWAY STRUCTURES/CHARACTERISTICS
• CROSSROADS AT GRADE LEVEL

15
SPECIFICS

• ROAD SURFACE AND TYPE
• ROAD/BRIDGE MLC 100 MINIMUM
• OVERHEAD CLEARANCES (i.e. WIRES, TREES, TUNNELS
  , OVERPASSES, etc.)
• SUPPLY CLASS AND DELIVERY SCHEDULE
• POPULATION AND CIVILIAN TRAFFIC
• ROAD GRADE AND CURVATURE
• CHOKE POINTS/BOTTLE NECKS
• DISTANCE/TIME/SECURITY
• ESCORT AVAILABILITY
• OVERSIZED VEHICLE FUEL TANK CAPABILITY 250
  GALLONS VS. MILES PER GALLON
• ROM/RON REQUIREMENTS BASED ON ABOVE

16
MSR DEVELOPMENT AND SUPPORT

• NAME MSRs
• DETERMINE CRITICAL POINTS
• ESTIMATE CHECKPOINT TO SEGMENT
• ESTABLISH CONTROL MEASURES
• DEVELOP TRAFFIC CIRCULATION PLAN
• STAFF AND COORDINATE

• ROUTES ENGINEERING, RECON OR CLASSIFICATION
• TRAFFIC DENSITY TOE, TASK ORGANIZATION
• TERMINALS AND FACILITIES GUIDES, LOG ANNEX
• COMMO OPLANS, ORDERS, ESTIMATES
• WEATHER STAFF OFFICERS
• INTELLIGENCE INTELLIGENCE SUMMARY
• CONCEPT OF OPERATION OPLANS AND ORDERS

17
CONVOY SUPPORT CENTERS
LEVEL 0 REST STOP ONLY NO SERVICE OR SUPPORT
LEVEL 2 LATRINES, WATER, SECURITY, REFUEL,
MAINTENANCE, LIMITED RECOVERY, PARKING
GUIDELINES REST STOP EVERY TWO HOURS
ENROUTE REFUEL AT MIDDLE OF VEHICLE
RANGE RON AFTER 14 HOUR WORKDAY FOOD SERVICE
BASED ON TOTAL TIME ENROUTE (MRE, SOUP,
T-RATIONS)
LEVEL 3 LATRINES, WATER, SECURITY, REFUEL,
MAINTENANCE, RECOVERY, PARKING, SHOWERS, BEDS,
LEVEL 1 LATRINES, WATER, SECURITY, EMERGENCY
FUEL, SMALL REPAIRS
18
CONVOY SUPPORT CENTER LOCATION CRITERIA

• PRIMARY ISSUES
• PARKING AVAILABILITY / SURFACE
• ACCESSIBILITY FROM MSR
• LSA
• HAZARDOUS WASTE REQUIREMENTS
• ROM CAPACITIES i.e. 4PT, 6PT, 8PT
• LOCATION i.e WHERE AND WHY
• TIME / DISTANCE OF MSR DETERMINES CSC LEVEL

• SECONDARY ISSUES
• HOST NATION RESTRICTIONS
• CONTRACT REQUIREMENTS
• LIGHTING
• HEATING

19
PLANNING FACTORS
20
EXERCISE PLANNING FACTORS
TYPE OF VEHICLES M915/M872 LOAD 2
EA. M577 (FST) PER SEMITRAILER DRIVER
LIMITATION 10 HOUR PERIODS ONE WAY HAULING
DISTANCE LIMITATION 90 MILES CONVOY SPEED
20 mph (MIH) AVAILABLE TRANSPORTATION
COMPANIES TWO DELAY PERIODS 1)
CSC1 (30 MIN)
2) CSC2 (1 HOUR)
3) CSC3 (8
HOUR)
4) TTP (1 HOUR)
