Web-Based Management

• Display on Web browser
• Economical displays
• Ubiquitous access
• Reduction in network load for non-polled
  configuration
• Web Interface vs Web-base management
• Web-based management
• Desktop management interface
• Web-based enterprise management
• Java management extensions

3
Web Interface
4
Proxy Server
5
Embedded WBM
6
HP Embedded Agent
7
Desktop Management Interface
Desktop Resident Management Applications
Management Interface (MI)
Service Layer (SL)
API
Component Interface (CI)
Hardware/Software Components
MIF Management Information Format
8
Desktop Management Interface

• Industry standard generated by
• - Desktop Management Task Force (DMTF)
• Started in 1992 to manage PCs
• Manages both hardware and software
• Two standards
• Management information format (MIF), similar
  to MIB
• Program interface with two APIs

9
DMI Service Layer
Request/Confirms
Indications
MIF Access
Management Interface
MIF Set
Synchronization and Flow Control
MIF Install
MIF DataBase
Response/Confirms
Events/Response
Command Processing
Event Processing
MIF Processing
10
DMI Functions
11
DMI MIB

• MIF specified using ASN.1 syntax
• Can be managed by an SNMP manager
• DMTF task expanded to specify WBEM - Web-based
  enterprise management
• DMTF
• - Distributed Management Task Force

12
Web-Based Enterprise Management
13
Web-Based Enterprise Management

• WBEM based on Common Information Module,
  developed by Microsoft
• CIM is information-modeling framework intended
  to accommodate all protocols and frameworks
• Object-oriented
• Five components
• Web client
• CIM object manager (CIMOM)
• CIM schema
• Management protocol
• Managed objects with specific protocol

14
Microsoft WMI
15
Microsoft WMI

• WMI is Microsoft infrastructure to support WBEM
  CIM
• WMI comprises management infrastructure,
  applications, and agents
• CIMOM has plug-in management applications
• COM/DCOM API specifies interface to CIMOM
• CIM is the CIM schema
• Object providers are management agents (e.g. SNMP
  agent)

16
Service Driven Network

• Network of services (instead of network of
  components)
• based on Java technology and thin clients.
• It speeds up service creation and deployment, as
  well as handling provisioning, management and
  billing.
• Dynamic Management
• The Service-Driven Network enables you to
  reconfigure the infrastructure of the network
  dynamically, by pushing services in real-time,
  both to the network infrastructure elements, and
  to consumer devices across the Internet.
• Java technology calls plug-in JavaBean
• MBean is management JavaBean

17
JDMK- Java Dynamic Management Kits
18
JDMK

• Java dynamic management tool kit to build
  Java-based NMS
• MBean is an intelligent agent does not need
  polling as in SNMP agent
• JDMK library of core management services
  implemented as MBeans
• Java Dynamic Management agent comprises
• MBeans core management framework, MBean server
• Protocol adaptors interfaces to applications

19
MBean Flow Diagram
20
(No Transcript)
21
(No Transcript)
22
JMX Architecture
23
Jiro
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Looking Ahead

• Future network and system management frameworks
  should accommodate well-established SNMP entities
• Web agents are intelligent and future points to
  the use of Web technology
• Web-based management offers two options
• WBEM is comprehensive and centralized approach to
  enterprise management accommodates both scalar
  and object-oriented schemes
• JMX is decentralized and uses Java technology
  agents embedded in objects and can be downloaded
  from NMS platform independent
• Future NMS environment could be a merger of the
  old and the new - at least in the near future
