Unit 2 Plate Tectonics

1
Unit 2 Plate Tectonics
2
Theory of Plate Tectonics

• Plate Tectonics
• Plate Boundaries
• Causes of Plate Tectonics

3
What is Plate Tectonics

• The Earths crust and upper mantle are broken
  into sections called plates.
• Plates move around on top of the mantle like
  rafts.

4
(No Transcript)
5
What is the Lithosphere?

• The crust and part of the upper mantle
  lithosphere
• 100 km thick
• Less dense than the material below it so it
  floats

6
What is the Asthenosphere?

• The plastic layer below the lithosphere
  asthenosphere
• The plates of the lithosphere float on the
  asthenosphere

7
(No Transcript)
8
2 Types of Plates

• Ocean plates plates below the oceans
• Continental plates plates below the continents

9
Plate Boundaries
10
Divergent Boundaries

• Boundary between two plates that are moving apart
  or rifting
• ? ?
• RIFTING causes SEAFLOOR SPREADING

11
Divergent Boundaries Create

• mid-ocean ridges
• rift valleys

12
(No Transcript)
13
(No Transcript)
14
Convergent Boundaries

• Boundaries between two plates that are colliding
• ? ?
• There are 3 types of convergent boundaries.

15
Type 1

• Ocean plate colliding with a less dense
  continental plate
• Subduction Zone where the more dense plate
  slides under the less dense plate
• VOLCANOES occur at subduction zones

16
(No Transcript)
17
Andes Mountains, South America
18
Type 2

• Ocean plate colliding with another ocean plate
• The more dense plate slides under the less dense
  plate creating a subduction zone called a TRENCH

19
(No Transcript)
20
Aleutian Islands, Alaska
21
Type 3

• Continental plate colliding with another
  continental plate
• Collision Zones
• a place where folded and thrust faulted mountains
  form.

22
(No Transcript)
23
(No Transcript)
24
Transform Fault Boundaries

• Boundary between two plates that are sliding past
  each other
• EARTHQUAKES along faults

25
(No Transcript)
26
San Andreas Fault, CA
27
Causes of Plate Tectonics
28
Convection Currents

• Hot magma in the Earth moves toward the surface,
  cools, then sinks again.
• Creates convection currents beneath the plates
  that cause the plates to move.

29
(No Transcript)
30
Questions...

• What is the theory of plate tectonics?
• What is the lithosphere?
• What is the asthenosphere?
• What is the connection between the two?
• What are the two types of plates?

31
Questions...

• What are the three types of boundaries?
• What direction do plates go for each?
• Which boundary has a subduction zone and what
  occurs at a subduction zone?

32
Questions...

• What causes plates to move?
• How is a convection current formed?
