Multiple Regression Models: Interactions and Indicator Variables

1
Multiple Regression Models Interactions and
Indicator Variables
2
Todays Data Set

• A collector of antique grandfather clocks knows
  that the price received for the clocks increases
  linearly with the age of the clocks. Moreover,
  the collector hypothesizes that the auction price
  of the clocks will increase linearly as the
  number of bidders increases.
• (Lets hypothesize a first order MLR model.)

3
First order model

• y ß0 ß1x1 ß2x2 e
• y auction price
• x1 age of clock (years)
• x2 number of bidders

4
The regression equation is

• AuctionPrice - 1339 12.7 AgeOfClock 86.0
  Bidders
• Analysis of Variance
• Source DF SS MS
  F P
• Regression 2 4283063 2141531 120.19
  0.000
• Residual Error 29 516727 17818
• Total 31 4799790

5
Tests of Individual ß Parameters

• Predictor Coef SE Coef T P
• Constant -1339.0 173.8 -7.70 0.000
• AgeOfClock 12.7406 0.9047 14.08 0.000
• Bidders 85.953 8.729 9.85 0.000

6
What if the relationship between E(y) and either
of the independent variables depends on the other?

• In this case, the two independent variables
  interact, and we model this as a cross-product of
  the independent variables.

7
For our example

• Do age and the number of bidders interact?
• In other words, is the rate of increase of the
  auction price with age driven upward by a large
  number of bidders?
• In this case, as the number of bidders increases,
  the slope of the price versus age line increases.
• To facilitate investigation, number of bidders
  has been separated into
• A 0-6 bidders
• B 7-10 bidders
• C 11-15 bidders

8
Are these slopes parallel, or do they change with
the number of bidders?
9
Caution!

• Once an interaction has been deemed important in
  a model, all associated first-order terms should
  be kept in the model, regardless of the magnitude
  of their p-values.

10
Another Example Graph and interpret the
following findings

• Lets say we want to study how hard students work
  on tests. We have some achievement-oriented
  students and some achievement-avoiders. We create
  two random halves in each sample, and give half
  of each sample a challenging test, the other an
  easy test. We measure how hard the students work
  on the test. The means of this study are

Achievement-oriented (n100) Achievement avoiders (n100)
Challenging test 10 5
Easy test 5 10
11
Conclusions

• E(y) ß0 ß1x1 ß2x2 ß3x1x2
• The effect of test difficulty (x1) on effort (y)
  depends on a students achievement orientation
  (x2).
• Thus, the type of achievement orientation and
  test difficulty interact in their effect on
  effort.
• This is an example of a two-way interaction
  between achievement orientation and test
  difficulty.

12
Basic premises up to this point

• We have used continuous variables (we can assume
  that having a value of 2 on a variable means
  having twice as much of it as a 1.)
• We often work with categorical variables in which
  the different values have no real numerical
  relationship with each other (race, political
  affiliation, sex, marital status)
• Democrat(1), Independent(2), Republican(3)
• Is a Republican three times as politically
  affiliated as a Democrat?
• How do we resolve this problem?

13
Dummy Variables

• A dummy variable is a numerical variable used in
  regression analysis to represent subgroups of the
  sample in your study.
• Dummy variables have two values 0, 1
• "Republican" variable someone assigned a 1 on
  this variable is Republican and someone with an 0
  is not.
• They act like 'switches' that turn various
  parameters on and off in an equation.

14
Creating Dummy Variables

• In Minitab, we can recode the categorical
  variable into a set of dummy variables, each of
  which has two levels.
• In the regression model, we will use all but one
  of the original levels.
• The level which is not included in the analysis
  is the category to which all other categories
  will be compared (base level.) You decide this.
• The coefficient on the variable in your
  regression will show the effect that being that
  variable has on your dependent variable.

15
Returning to the Clocks at Auction Data Set

• The collector of antique grandfather clocks knows
  that the price received for the clocks increases
  linearly with the age of the clocks and he
  hypothesized that the auction price of the clocks
  will increase linearly as the number of bidders
  increases. But lets say he doesnt have the
  exact number of bidders, only knows if there was
  a high number of bidders (well say 9 and above)
  or a low number (below 9.)

16
Lets Create a Dummy Variable in Minitab

• Well use the Bidders2Cat column
• Calc? Make Indicator Variables
• In top box, specify that you want to make
  indicator variables for Bidders2Cat
• Lets store results in C10 - C11
• Once you have created the variables, name columns
  10 and 11 ManyBidders and FewBidders
• Which is which? Why?

17
Before we run the analysis

• Lets say we decide to include ManyBidders
  (FewBidders is the base level.)
• Because FewBidders is not included, we can
  determine if ManyBidders predicts a different
  Auction Price than FewBidders.
• If ManyBidders is significant in our regression,
  with a positive ß coefficient, we conclude that
  ManyBidders has a significant effect on the price
  of the clocks at auction.

18
Thinking Through the Variables

• What is x1?
• Lets hypothesize the model in plain English
  just looking at high/low bidders.)
• Whats the Null Hypothesis?

19
Run the Analysis

• Results of the t-test?
• What would happen if we used ManyBidders as our
  base?

20
Lets look at your Journal Application

• What does it mean to create a dummy variable and
  when is it appropriate to do this?
• What are all the terms in the original model?
• This researcher started with a complex model and
  simplified it. Which model was better? How can we
  know?

21
Nested Models

• Two models are nested if both contain the same
  terms and one has at least one additional term.
• Example
• The first (straight-line) model is nested within
  the second (curvilinear) model.
• The first model is the reduced model and the
  second is the full or complete model.

22
Which is better? How do we decide?

• In this example, we would test
• To test, we compare the SSE for the reduced model
  (SSER) and the SSE for the complete model (SSEC).
• Which will be larger?

At least one
23
Error is Always Greater for the Reduced Model

• SSERgtSSEC
• Is the drop in SSE from fitting the complete
  model large enough?
• We use an F-test to compare models
• Here, we test the null hypothesis that our
  curvature coefficients simultaneously equal zero.

24
Test statistic F

• F drop in SSE/number of ßs being tested
• s2 for larger model
• Table C4 (p. 766) gives you the critical value
  for F
• df for numerator (v1)
• Number of ßs being tested
• df for denominator (v2)
• Number of ßs in the complete model
• If F The critical F value, reject H0. At least
  one of the additional terms contributes
  information about the response.

25
Conclusions?

• Parsimonious models are preferable to big models
  as long as both have similar predictive power.
• A model is parsimonious when it has a small
  number of predictors
• In the end, choice of model is subjective.

26
Question 3 (Journal)

• What type of error do we risk making by
  conducting multiple t-tests?
• Pages 184, 188
