INTRODUCTION TO CHEST IMAGING

1
(No Transcript)
2
INTRODUCTION TO CHEST IMAGINGfor 5th year
medical students

• DR/HOSSAM ZYTON
• LECT OF RADIOLOGY

3
IMAGING TECHNIQUES

• Plain radiography (CXR) routine, special.
• Fluoroscopy with and without contrast.
• Bronchography.
• Pulmonary Angiography and bronchial
  Arteriography.
• Tomography
• C.T scanning
• MRI.
• Scintigraphy Isotope studies.
• Ultrasound

4
PLAIN RADIOGRAPHY OF THE CHEST (CXR)

• IMPORTANCE OF CHEST X-RAY
• Diagnosis follow up of chest heart diseases.
• Routine pre-employment examination.
• Routine preoperative examination
• Follow up of malignancy
• Medical checkup.

5
PLAIN RADIOGRAPHY OF THE CHEST (CXR)
6
Normal PA View of the chest
7
PLAIN RADIOGRAPHY OF THE CHEST (CXR)
8
Normal Lateral View of the chest
9
PLAIN RADIOGRAPHY OF THE CHEST (CXR)
10
PLAIN RADIOGRAPHY OF THE CHEST (CXR)

• ANALYSIS OF THE X-RAY OF THE CHEST
• Does the x-ray belong to the correct patient?
  Check the patients name on the film.
• Have the left and right side markers been labeled
  correctly, or does the patient really have
  dextrocardia?
• Lastly has the projection of the radiograph (PA
  vs. AP) been documented?

11
PLAIN RADIOGRAPHY OF THE CHEST (CXR)

• CRITERIA OF A GOOD X-RAY OF THE CHEST
• Patient central
• a-Sterno-clavincular junction equidistant from
  midline (spinous process).
• b-Mediasternum 2/3 to left and 1/3 to right
• Lung apices appear and lower 3 cervical
  vertebrae.
• The diaphragm should be found at about the level
  of the 8th - 10th posterior rib or 5th - 6th
  anterior rib on good inspiration.
• Costo-phrenic and cardio-phrenic are seen
• Scapula away from lung field.
• Vertebral bodies should just be visible through
  the heart. Intervertebral disc spaces and
  anterior end of ribs not seen through cardiac
  shadow
• Non visualized vertebral bodies whiter film ?
  Underexposure
• If the film appears too black ? Overexposure

12
Normal PA View of the chest
R
13
Centrally Positioned Film
Rotated Film
14
Penetration (Exposure)
Under Exposed (Soft)
Over Exposed (hard)
15
Imaging Techniques of the Chest

• Bronchography

16
Imaging Techniques of the Chest
Mediastinal Window
Lung Window

• CT Scan

17
Imaging Techniques of the Chest

• MRI

18
Imaging Techniques of the Chest

• Pulmonary Angiography

19
Imaging Techniques of the Chest

• Ultrasound

20
Imaging Techniques of the Chest

• Isotope Studies

21
PLAIN RADIOGRAPHY OF THE CHEST (CXR)

• RADIOLOGICAL ANATOMY

22
(No Transcript)
23
Normal PA View of the chest
R
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Viewing PA radiograph of the chest

• Pleura and Diaphragm
• The highest point of the right diaphragm is
  usually 11.5 cm higher than that of the left.
• Each costophrenic angle should be sharply
  outlined.

29
Viewing PA radiograph of the chest

• Pleura and Diaphragm
• Assessment of diaphragmatic flattening
• The highest point of a hemidiaphragm should be at
  least 1.5 cm above a line drawn from the
  cardiophrenic to the costophrenic angle.

30
Viewing PA radiograph of the chest

• Hilar region
• Both hila should be concave.
• Both hila should be of similar density.
• The left hilum is usually superior to the right
  by up to 1 cm.

31
Viewing PA radiograph of the chest

• Bones and soft tissue
• Ribs (anterior and posterior)
• Clavicles
• Vertebrae
• Shoulder joints
• Look carefully at the soft tissues for asymmetry
  (i.e. mastectomy)

Ribs
32
Dont Forget to look at hidden areas
Viewing PA radiograph of the chest
33
Normal PA View of the chest
R
34
PLAIN RADIOGRAPHY OF THE CHEST (CXR)

• Soft tissue abnormality
• Bony thoracic cage
• Pleura
• Diaphragm
• Lungs
• Mediastinum
• Heart

35
(No Transcript)
36
PATTERNS OF CHEST DISEASE

• Airspace disease
• Airway disease
• Interstitial Disease
• Pleural disease
• Thoracic cage disease

37
AIRSPACE DISEASE
38
AIRWAY DISEASE
39
INTERSTITIAL DISEASE
40
PLEURAL DISEASE
41
PLEURAL DISEASE
42
CHEST WALL DISEASE
43
COMMON SIGNS IN CHEST RADIOLOGY

• Silhouette sign
• Air bronchogram
• Solitary pulmonary nodule

44
SILHOUETTE SIGN
45
SILHOUETTE SIGN
46
AIR BRONCHOGRAM
47
AIR BRONCHOGRAM
48
AIR BRONCHOGRAM
49
SOLITARY PULMONARY NODULE
50
ADDITIONAL RESOURCES

• http//www.med-ed.virginia.edu/courses/rad/cxr/ind
  ex.html
• http//www.chestradiology.net/
• http//www.mc.uky.edu/education/images/flash/chest
  new.swf

51
Thank You
