Post-Op Management Options

1
Post-Op Management Options
Cameron Ward B.PO
2
Overview

• What is needed in post op management?
• A quick look at oedema.
• Comparing the options?
• Something new
• Compression therapy

3
What is needed in post op management?-
Multi-disciplinary team
Optimal recovery and rehabilitation after
amputation requires a multi-disciplinary
approach.
It is important that all personnel involved in
the treatment of the amputee, obtain knowledge of
each others professions and working procedures.
4
What is needed in post op management?

• - Aims
• Ensure good wound healing
• Reduce oedema in residual limb
• Pain reduction
• Shape residuum
• Protection of residuum from external stresses
• Prevent contractures
• Prepare for prosthetic management/ambulation

5
Wound Healing - oedema

• Inflammatory response
• Oedema exudate forms
• Fluids from the medullary bone bleeding, tissue
  exudate and blood loss form oedema exudate
• Harmful effects of oedema
• Delays wound healing
• Increases interstitial pressure
• Increased risk of infection
• Induces the onset of pain

6
Harmful effects of Oedema

• Amputees often predisposed to edema
• Pre existing vessel disease
• Decreased capacity for venous return
• Incision to vessels
• Cut muscles
• Immobility

7
Stump Volume

• 1 week post op- volume is at its peak
• 1-2 weeks decreased edema and some tissue
  atrophy
• 2-3 weeks edema resolved, tissue atrophy
• If you can limit volume in initial week
• ? the rate change over time (same volume reached
  after 3 months)
• ? wound healing

8
What are the options

• Nothing
• Soft dressings
• Elastic Bandaging
• Juzo / stump shrinkers
• Rigid dressings
• Thigh level rigid plaster dressing without
  immediate prosthesis
• IPOP Immediate Post op Prosthesis
• Removable Rigid Dressing (RRD)
• Compression therapy/RRD

9
Soft dressings Advantages

• ease of application
• accessibility to the wound
• Low initial cost

10
Soft dressings Disadvantages

• High local or proximal pressures impair skin
  survival and healing
• Likelihood of gauze falling off
• ?ed chance of knee flexion contracture
• ?ed pain ??ed bedrest, ?mobility
• ?ed hospital stays ??risk of pulmonary
  complications, stokes, pneumonia
• ?ed health care costs due to ?ed hospital stays

11
Shrinkers Vs Bandaging

• Bandaging
• application is unreliable
• Dangerous in terms of pressure distribution
  (Puddifoot and associates showed elastic wrap to
  have the greatest range of pressures and the
  highest readings)
• Shrinkers have been shown to be more effective
  than bandaging in decreasing residual limb volume

12
Thigh level rigid plaster dressingAdvantages

• Significantly shorter rehab times compared to
  soft gauze dressings
• Protects the residual limb ??es revision surgery
• ?es edema, pain and healing times
• ?es tolerance to weight bearing/early ambulation
• Holds knee in extension ? prevents flexion
  contracture

13
Thigh level rigid plaster dressingDisadvantages

• More difficult to apply
• Requires skilled surgical/prosthetic/rehab team
• ?ed cost (short term)
• ?ed access for wound inspection
• Inability to adjust fit
• Immobilises knee into extension

14
Thigh level rigid plaster dressing with
IPOPAdvantages

• Simular benefits of no IPOP plus
• ?stimulation of circulation
• Weightbearing within 24 hours
• ?es edema (by ?ing pressure and pumping action of
  muscles)
• ?ed time to custom prostheses
• Fewer surgical revisions
• Emotional/ self imaging benefits
• Rapid healing

15
Thigh level rigid plaster dressing with
IPOPDisadvantages

• Difficult to inspect wound
• Tissue damage mechanical trauma (particularly
  vascular patients)
• Need a dedicated team/ highly skilled
• Unskilled application could lead to disaster
• Difficult to control early weight bearing
• Healing rate studies have shown Ambulate healing
  rates to be 20 less than non-ambulant

16
Removable Rigid Dressings (RRD)Advantages

• Significantly less oedema compared to soft
  dressings
• Enhanced wound healing
• Limited oedema formation
• Immobilisation of soft tissues
• Healing on average 3 weeks earlier than soft
  dressing management
• Healing more rapid than IPOP
• Ability to remove and inspect wound
• Patient learns donning and doffing
• Permits knee flexion
• Ability to adjust fit

17
RRD vs Elastic Bandages

• Easier to apply
• Remain secure
• Better stump shrinkage and shaping
• No pressure problems
• Stump protection
• ?ed Length of Stay (LOS) in accute hospital
• Average of 9 days instead of 14

18
Rehabilitation Prostheses

• Plaster interims - Physios
• Moulded directly onto stumps
• Limitations
• Socket design
• Basically walking on a cast
• No modifications can be made
• Volume adjustments restricted to socks
• Materials (weight, strength etc)
• Huge medico legal issues
• Different amputation levels
• Heavy patients

19
Plaster vs prosthesesEvaluation of service -
MECRS

• Plaster
• Prostheses
• 32 54
• 108 59
• 4 2
• 87 0

• Criteria
• Admissions
• L.O.S
• No. of sockets
• 2nd definative
• in 1st year

20
MECRS service delivery model

• Acute Hospital
• RRD fitted day 0
• Days 0-7 acute

• Rehabilitation
• Day 7 onwards
• Continue wearing RRD
• Day 21 fit shrinker
• Day 23 fit Rehab prostheses

21
Postoperative dressing and management strategies
for transtibial amputations A critical
reviewDouglas G.Smith et al

• Consensus on the most effective postoperative
  management strategies for TTA is lacking however
• Rigid dressings have been shown to significantly
• ? edema compared to soft dressings
• ?rehab times compared to soft dressings
• ?time to initial gait training compared to soft
  dressings

22
Compression Therapy

• A silicone liner is used for edema and volume
  control and for shaping of the residual limb
• allows the prosthetic treatment to start
  earlier.
• Three objectives are achieved in this phase

23
1. Stretching of the soft tissue distally
24
2. Compression of the wound surfaces along the
suture lines.
25
3. An even compression that decreases proximally

• Due to the decreasing thickness of the liner
  walls.

26
Compression Therapy

• Time of use and measure- ments are documented
• Size of the liner is changed when necessary to
  maintain continuous compression

• Guidelines
• Day 1 2 x 1h
• Day 2 2 x 2h
• Day 3 2 x 3h
• Day 4 and further.. 2 x 4h

27
Compression Therapy

• Oedema control
• Graded compression assists with oedema management
• The same level of compression is achieved
  regardless of who applies the liner
• In traditional care, both the compression and the
  quality of the dressing vary, depending on who
  performs the treatment.
• Improved pain control through the increased
  proprioception.

28
Compression Therapy

• Improved wound healing
• Reduction of oedema
• Provides occlusive environment
• Considered standard treatment of leg ulcers
• Prevents tissue dehydration and cell death
• Provides barrier to bacteria
• Decreases risk of infection

29
Compression Therapy

• Further Benefits
• Shaping of residuum to give optimal shape for
  prosthetic fitting
• Thus reducing prosthetic complications
• Facilitates early mobilization
• Silicone speeds up maturation of residuum and
  helps smooth scar

30
Case Study Mr B 2/2/04WARNING on next slide
31
Mr B 4/2/02
32
Mr B 12/2/04

• Once the stitches were removed and there was no
  infection found a silicone liner was used to
  assist with the continuation of healing.

33
Mr B - 3/3/04

• Healing improved as the hardness of the distal
  end reduced
• Patient reported pain reduction.

34
Mr B Today!
35
Launceston General Hospital Pilot Trial

• May 2003
• Prem Anandam
• Full pilot trial can be found on
• www.monash.edu.au/rehabtech/

36
QUESTIONS?
37
For related Post Op references or any further
information please contact me at APC
prosthetics.02-9890-8123or cameron_at_advcancedpro
sthetic.com.au
Thank you
38
Thank You
