Transcript and Presenter's Notes

Title: Electrical Theory I - The Basics


1
Electrical Theory I - The Basics
  • Let there be light.

2
(No Transcript)
3
Introduction
  • Basic Terminology
  • Ohms Law
  • Kirchhoffs Laws Applications
  • Basic Circuit Analysis
  • Transformers Rectifiers

4
Basic Terminology
  • Electromotive Force (E or V)
  • Force which causes electrons to move from one
    location to another
  • Known as emf, potential difference, or voltage
  • Unit is volt (V)
  • Source
  • Generator
  • Battery
  • Like pump that moves water through pressure

5
Basic Terminology
  • Current (I)
  • Flow of electric charges - electrons (or holes) -
    through a conductor or circuit per increment of
    time
  • Unit is ampere (number of charged particles
    passing a point each second)
  • 1 amp 1 coulomb/sec 6.02x1023 electrons/sec
  • Like rate of flow of water through a pipe

6
Basic Terminology
  • Resistance (R)
  • An electrical circuits opposition to the flow of
    current through it
  • Measured in ohms (W)
  • Conductor
  • All materials will conduct electricity, but at
    varying resistances
  • Good conductors have little resistance (ie
    silver, copper, aluminum, iron)

7
Basic Terminology
  • Insulator
  • Substances which offer high resistance to current
    flow (ie wood, rubber, plastics)
  • Circuits made of wires covered with insulator
  • Power (P)
  • Rate at which work is performed
  • Measured in watts (W)

8
Basic Terminology
  • Direct Current (DC)
  • Current flow is unidirectional and of constant
    magnitude (battery)
  • Alternating Current (AC)
  • Magnitude direction of current flow
    periodically change
  • Each sequence called a cycle
  • Frequency is cycles per second (Hz)

9
Electrical Devices
  • Rectifier
  • Converts AC DC
  • Designed to have small resistance to current flow
    in one direction large resistance in opposite
    direction
  • Typically called a diode or rectifier

10
Electrical Devices
  • Transformer
  • Device w/o moving parts that transfers energy
    from one circuit to another by electromagnetic
    induction
  • Consists of ferromagnetic core sets of windings
  • Step-up Vin Vout
  • Step-down Vin Vout
  • Only works with AC

11
Ohms Law Applications
  • Law current of a circuit is directly
    proportional to the applied voltage and inversely
    proportional to circuit resistance
  • I a V, I a 1/R V IR
  • Power
  • P VI P (IR)I I2R

12
Applications
  • Resistors in Series
  • RT R1 R2 R3 . . .
  • Resistors in Parallel
  • 1/RT 1/R1 1/R2 1/R3 . . .
  • Examples should be able to find total current
    flow in circuit, current flow through each
    resistor, voltages, power dissipated, etc.

13
Kirchhoffs Laws
  • Kirchhoffs Current Law (KCL)
  • A node is any junction in a circuit where two or
    more elements meet
  • Currents into a node sum to zero OR
  • Current entering a junction is equivalent to the
    current leaving a junction

14
Kirchhoffs Laws
  • Kirchhoffs Voltage Law (KVL)
  • A loop is any path in a circuit that current can
    take so that it meets back up to where it starts
  • Voltages around a CLOSED loop sum to zero

15
Questions?
16
Electrical Theory II The Applications
  • Harnessing the Power

17
  • of

18
Introduction
  • Electromagnetic Induction
  • DC
  • Generators
  • Motors
  • AC
  • Generators
  • Motors
  • Three-phase AC

19
How is Electricity Produced?
  • Friction static electricity from rubbing
    (walking across a carpet)
  • Pressure piezoelectricity from squeezing
    crystals together (quartz watch)
  • Heat voltage produced at junction of dissimilar
    metals (thermocouple)
  • Light voltage produced from light striking
    photocell (solar power)
  • Chemical voltage produced from chemical reaction
    (wet or dry cell battery)
  • Magnetism voltage produced using electromotive
    induction (AC or DC generator).

20
Electromagnetic Induction
  • Faraday (1831)
  • Showed that an emf is induced in a conductor if a
    magnet passes by a conductor
  • When pole of magnet entered coil, current
    flowed in one direction
  • When direction of magnet reversed, current
    flowed in opposite direction

21
Electromagnetic Induction
  • Results in
  • Generator action generator converts mechanical
    to electrical energy
  • Motor action motor converts electrical to
    mechanical energy

22
Generator Action
  • For emf/current (electricity)
  • Magnetic Field
  • Conductor
  • Relative Motion b/t the two
  • Voltage produced induced emf/voltage
  • Current produced induced current
  • Left-hand rule for generator action

23
Motor Action
  • For motor action (torque/motion)
  • Magnetic Field
  • Conductor
  • Current flow in conductor
  • Torque produced induced torque
  • Right-hand rule for motor action

24
Electromagnetic Induction
  • Magnitude of induced current can be increased by
  • Increasing strength of magnetic field
  • Increasing speed of relative motion
  • Positioning of field conductor to increase
    number of magnetic lines of flux cut
  • Magnetic field usually produced by electromagnet

25
Electromagnet
  • Soft iron core wound with coils of wire
  • When current present (excitation current), core
    becomes magnetized
  • Field strength determined by number of turns and
    magnitude of current
  • B a NIDC

26
Standard Terminology
  • Stator stationary housing of the generator or
    motor
  • Rotor rotating shaft inside the stator
  • Field windings conductors used to produce
    electromagnetic field
  • Armature windings conductors in which output
    voltage is produced (or input is provided)

27
DC Generators
  • Basic Principle rotate a conductor within a
    magnetic field to induce an EMF
  • Field windings located on stator receive
    current from outside source

28
DC Generators
  • Armature windings on rotor
  • Commutator rings used to mechanically reverse the
    armature coil connection to the external circuit
  • EMF developed across the brushes becomes a DC
    voltage/current (pulsating and unidirectional)

29
DC Motors
  • Essentially the same in construction as DC
    generator
  • Based on principle that current carrying
    conductor placed at a right angle to a magnetic
    field tends to move in a direction perpendicular
    to magnetic lines of flux
  • Only need to change relative voltage to go
    between generator motor

30
AC Generators
  • Most electrical power used is AC made by AC
    generators
  • Basic principle rotating magnetic field cutting
    through a conductor
  • Regardless of size, all AC generators work on
    same principle
  • Two types
  • Revolving armature (NOT used)
  • Revolving field (Used in SSTGs, GTGS, DG)

31
AC Generators
  • Two types
  • Revolving armature (NOT used)
  • Revolving field (Used in SSTGs, GTGS, DG)

32
AC Generators
  • Field windings on rotor
  • DC current provided for field via slip rings and
    brushes (vice commutator rings)
  • Rotor turned by prime mover creates
    rotating magnetic field
  • Armature windings on stator
  • As field rotates, AC current produced in
    armature
  • Since stationary contacts, no arc-over

33
AC Generators
  • Determining speed of AC machine
  • f P(RPM)/120 RPM 120f/P
  • Must maintain constant 60Hz output use speed
    governor to maintain constant RPM (independent of
    loading)
  • Must also regulate voltage output
  • Since constant RPM, must control field excitation
    (DC current) to control output voltage

34
AC Motors
  • Use AC current as input to produce work
  • Many different types depending on number of
    phases of AC input construction
  • Ex induction motor
  • Input AC current on stator produces rotating
    field
  • Current produced in conductors on rotor produces
    torque

35
Three Phase (3f) AC Power
  • Phases number of sets of armature windings on
    stator
  • 3f has three sets of armature windings
  • Voltage induced is 120o out of phase for each
  • Output 3 sinusoidal voltages and currents
  • Allows more power to be delivered with a smaller
    design generator

36
Three Phase (3f) AC Power
37
Questions?
