Implementing Disaster Recovery Plans

1
Implementing DisasterRecovery Plans

• Chapter 9

2
You Will Learn How To

• Develop an implementation plan
• Assign responsibilities for implementation
• Establish an implementation schedule
• Distribute the disaster recovery documentation
• Assess the value and effectiveness of mitigation
  steps
• Manage internal and external awareness campaigns
• Launch a training program for disaster recovery

3
Developing an Implementation Plan

• Implementation plan affects all the departments
  in an organization
• The plan must be managed step by step, and
  progress must be evaluated on a scheduled basis
• Implementation plan requires training for all
  employees, and might require new equipment and
  procedures
• Events occurring during implementation
• Responsibilities for implementation are assigned
  to members of the disaster recovery planning team
  and departmental groups
• An implementation schedule is developed, with
  timelines and planned progress evaluations
• Disaster recovery documentation is distributed to
  everyone who needs copies, or online access is
  provided
• The value and effectiveness of mitigation steps
  are assessed. New mitigation steps could be put
  into place, and existing steps may be modified
• The organization plans and launches internal and
  external awareness campaigns
• The organization develops and launches employee
  training programs for disaster recovery procedure

4
Developing and Implementation Plan

• Organization wide activities may include raising
  awareness and training
• Deployment of equipment and other like actions
  may need to occur at the facility level
• The departments and work groups affected by new
  or changed procedures must make these changes or
  additions

5
Organizational levels for implementing parts of
the plan
6
Assigning Responsibilities for Implementation

• The disaster recovery planning coordinator and
  planning team assign responsibilities for
  implementing the plan
• The coordinator takes the lead in monitoring and
  evaluating the progress of implementation
• The activities involved in implementation include
  directing management to establish liaisons with
  law enforcement and emergency services
• Managers need to assign activities to employees
• Department work groups implement the aspects of
  the plan that impact their department
• Activities include changing existing procedures
  and evaluating mitigation steps, as well as
  developing new mitigation procedures to support
  recovery priorities in the plan

7
Assigning Responsibilities for Implementation

• The Purchasing Department takes the lead in
  processing all paperwork necessary to acquire
  equipment necessary to implement the plan
• If the new equipment is used only in one
  department, that department may install the
  equipment
• New contracts needed for the recovery must be
  developed by the department with the Purchasing
  Department, and ensures fees and retainers are
  paid
• Solid liaisons must be established with law
  enforcement, emergency services organizations,
  and contractors
• Disaster recovery coordinator, facility managers,
  and disaster response team work to establish
  these liaisons, as well as maintain the
  relationships over the long term

8
Implementation activities
9
Implementation tasks

• Many activities may be broken down into specific
  tasks assigned to employees or departments that
  are not part of the planning team

10
Establishing an Implementation Schedule

• Disaster recovery planning team establishes an
  implementation schedule for completing each
  activity in the plan
• Available resources, geography, and other factors
  will influence the speed of this schedule
• The disaster recovery planning coordinator and
  planning team must monitor the progress of the
  implementation
• A monthly report of accomplishments and
  activities that are behind schedule should be
  compiled by the coordinator
• The team may modify the schedule as conditions
  warrant, or suggest acceleration to various
  departments
• The planning team should bring obstacles to the
  attention of executives so that the obstacles can
  be cleared by the influence of the executive

11
Sample implementation schedule
12
Distributing the Disaster Recovery Documentation

• The plan must be distributed during the
  implementation, rehearsal and testing phases
• Disaster recovery plan documents include all the
  written analyses, policies, and procedures that
  employees and contractors should follow when
  responding to a disaster
• Organizations should not rely on just one method
  to make documents available to response teams
• As long as the intranet web servers function,
  they are acceptable for distributing disaster
  recovery plan documents
• Each distribution method has unique advantages
  and disadvantages

13
Distribution alternatives
14
Assessing the Value and Effectiveness of
Mitigation Steps

• Mitigation steps are used to reduce the impact of
  system failure or disruption of operations
• Many of these steps are common practices for
  managing assets or business processes
• Such steps include backing up computer files to
  mitigate the consequences of disk or system
  failure
• The exposure inventory and risk assessments
  collected information on mitigating and avoiding
  business disruptions
• All mitigation steps must have a sound economic
  value
• Table 9-6 illustrates that if power is lost nine
  times per year, the return on investment (ROI)
  for using a UPS to protect the server is about 15
  months

15
Analysis of the value of UPS
16
Assessing the Value and Effectiveness of
Mitigation Steps

• Determining what kind of data back-up systems an
  organization should use is more difficult than
  analyzing the benefits of a UPS
• System backups are certainly necessary to
  preserve computer files and databases
• The selection of particular back-up systems
  depends on a number of factors

17
Analysis of the value of data backup systems
18
Assessing the Value and Effectiveness of
Mitigation Steps

• After determining how much money could be saved
• The planning team can examine what types of data
  back-up systems to put in place
• How much the organization should spend for them
• The planning team should address several
  questions before selecting a back-up system
• How resilient to failure is the back-up system?
• Can it be used for more than one system or
  application, thus improving ROI?
• What level of disaster does the back-up system
  help mitigate (e.g., catastrophic, major, or
  minor)?
• How much does it cost to deploy the back-up
  system?
• How much IT staff time is needed to maintain the
  back-up system?
• The planning team should use ROI analyses to
  evaluate mitigation steps that make economic sense

19
Managing Internal and External Awareness Campaigns

• As an organization develops and implements a
  disaster recovery plan, it needs to make
  employees highly aware of the plan
• During training, employees should learn the
  details of the plan and learn their roles and
  responsibilities during disaster response
• The goal of the awareness program is to
  indoctrinate employees about the importance of
  disaster response and recovery
• Depending on an organizations resources, there
  are several ways to increase awareness during
  plan implementation

20
Using Existing Channels of Communication

• Organizations often have employee relations
  programs, customer relations management systems,
  and business partner communications that can help
  build awareness
• Some forms of communication include
• Employee newsletters
• Bulletin boards
• Motivational posters
• Intranets with employee information sections
• E-mail announcement lists
• Customer relations e-mail newsletters and
  bulletins
• Business partner Web sites
• Corporate Web portals with sections for
  employees, customers, and business partners

21
Building Awareness Among Employees

• Organizations can use regularly scheduled
  department or work group meetings to call
  attention to disaster recovery planning efforts
• A series of announcements that department
  managers and supervisors can use in their
  meetings may include
• A basic description of disaster recovery planning
• The mission statement of the planning team
• The status of disaster recovery planning
• The status of implementing the recovery plan
• The schedule for disaster recovery training
• The schedule for testing recovery procedures

22
Building Awareness Among Customers and Business
Partners

• Managers of the Customer Relations Department can
  build awareness among customers through
  newsletter articles, e-mail bulletins, or
  announcements at meetings
• Channel managers or product managers can build
  similar awareness among business partners
• Bulletins and announcements to both customers and
  business partners should include the following
  materials
• Basic description of disaster recovery planning
• How the organization works with customers or
  business partners to develop recovery procedures
• How the disaster recovery plan can benefit
  customers or business partners
• What customers or business partners can expect
  when a disaster strikes
• Basic steps for customers or business partners to
  follow in a disaster

23
Launching a Training Program for Disaster Recovery

• The scope and depth of the training program
  depend on the size and type of the organization
• Training must be developed for several levels of
  employee involvement
• Training with local emergency organizations is
  also advisable
• General broad training should be developed from
  the overall plan, for managers, supervisors, or
  all employees
• More specific training modules directed toward
  middle managers, supervisors, and disaster
  response teams
• These modules include training on how teams
  should be organized, along with activities that
  require managers and employees to be involved
• Some specialized training may also be necessary
  for certain special procedures

24
General disaster recovery training modules
25
Specialized training modules
26
Training modules for special disaster recovery
procedures
27
Elements of Disaster Recovery Training Modules

• Most of the material required to develop a
  training program should already be included in
  the disaster recovery plan
• The plan documentation may not always be easy to
  convert to training material
• The training modules should contain several
  elements that are presented in different formats

28
Elements of disaster recovery training modules
29
Launching a Training Program for Disaster Recovery

• The disaster recovery planning team should watch
  and approve training presentations before they
  are given to the entire organization
• Overheads and slides used during disaster
  recovery training should look professional and be
  easy to read from all parts of the training rooms
• When trainers use sections of the disaster
  recovery plan in their training, they should
  organize the sections separately for each
  training module
• An evaluation form should inquire about the
  overall quality of the training, as well as the
  quality of materials used during training
• The overview of the recovery plan is designed for
  all employees, and should be included in all
  training modules
• The overview should last about one hour it
  should focus on what is expected from employees
  during a disaster, and how they should report to
  supervisors or middle managers

30
Training for Executives

• Training modules designed for executives should
  be tightly structured
• It should include only as much detail as
  necessary to explain what is expected of them
  during a disaster
• Table 9-12 shows a recommended training session
  for executives
• The training is designed so that sessions can be
  held independently, grouped for the convenience
  of executives, or delivered in a single day

31
Disaster recovery training for executives
32
Training for Middle Managers

• Middle managers generally have far more extensive
  roles in disaster response and recovery than
  executives
• Their recovery training needs to cover topics in
  greater depth
• Table 9-13 shows a recommended training session
  for middle managers
• Sessions can be held independently, grouped for
  the managers convenience, or delivered in a
  three-day training session

33
Disaster recovery training for middle managers
34
Training for Supervisors

• Supervisors generally have more extensive roles
  in disaster response and recovery than executives
• They work under the direction of middle managers
  to implement procedures or support a specific
  response team
• Disaster recovery training for supervisors needs
  to cover the same topics as that for executives,
  but not in as much depth as the training for
  middle managers
• Table 9-14 shows a recommended training session
  for supervisors
• Sessions can be held independently, grouped for
  the supervisors convenience, or delivered in a
  one-day training session

35
Disaster recovery training for supervisors
36
Training for Disaster Response Teams

• Training specific response teams is the most
  complicated aspect of disaster response and
  recovery training
• Response teams must be trained on much of the
  same material as executives and middle managers
• They must be extremely well trained in their own
  roles to ensure that disaster response proceeds
  smoothly
• Training modules for specific response teams
  should provide in-depth coverage of procedures,
  so that team members fully understand their
  responsibilities in a disaster
• All response team members should attend disaster
  recovery training for middle managers, as well as
  specialized training designed for their team
• Table 9-15 shows recommended training sessions
  for specific disaster response teams

37
Training sessions for specific response teams
38
Training for Employees

• All employees should be required to attend
  training that is appropriate for their management
  level and participation on response teams
• Disaster recovery coordinators should work with
  the Human Resources and Training departments to
  ensure that trainers receive a list of all
  employees who are scheduled to attend specific
  modules
• Trainers should record attendance on a class
  roster and return it to the office that schedules
  training

39
Chapter Summary

• The implementation plan affects all the
  departments in an organization
• The plan must be managed step by step, and
  progress must be evaluated on a scheduled basis
• The activities required to implement a disaster
  recovery plan range from directing management to
  establishing liaisons with local law enforcement
  and emergency services
• The disaster recovery planning coordinator and
  the planning team assign responsibilities for
  implementing the plan
• The coordinator takes the lead role in monitoring
  and evaluating the progress of implementation

40
Chapter Summary

• Once responsibilities have been assigned for
  specific activities and tasks, the disaster
  recovery planning team needs to establish an
  implementation schedule for completing each
  activity in the recovery plan
• The disaster recovery plan must be distributed
  and made available during implementation, test
  and rehearsal steps, and thereafter
• Organizations should not rely on just one method
  to make documents available to response teams

41
Chapter Summary

• All mitigation steps must have sound economic
  value
• As an organization develops and implements a
  disaster recovery plan, it needs to make
  employees highly aware of the plan
• The disaster recovery training plan is an
  essential element of being prepared for a
  disaster
• The scope and depth of the training program
  depend on the size and type of the organization
• Training must be developed for several levels of
  employee involvement
• Training with local emergency organizations is
  also advisable
