MINERALS AND ROCKS IN THE EARTH

1
MINERALS AND ROCKS IN THE EARTHS CRUST

• Igneous, Sedimentary, Metamorphic Rocks and
  Environments

2
MINERALS AND ROCKS COME FROM ELEMENTS

• Chemical elements are the fundamental materials
  of which all matter is composed.
• From the modern viewpoint
• a substance that cannot be broken down or reduced
  further

3
PERIODIC TABLE OF ELEMENTS




4
MAKING MINERALS FROM ELEMENTS

• ALMOST ALL THE MINERALS FOUND IN THE EARTH ARE
  FORMED FROM THE BONDING OF EIGHT (8) ELEMENTS
• OXYGEN (O)
• SILICON (Si)
• ALUMINIUM (Al)
• IRON (Fe)
• CALCIUM (Ca)
• POTASSIUM (K)
• SODIUM (Na)
• MAGNESIUM (Mg)

MOST ABUNDANT
LEAST ABUNDANT
5
WHAT ARE MINERALS?

• BUILDING BLOCKS FOR ROCKS
• DEFINITION
• NATURALLY OCCURRING,
• INORGANIC SOLIDS,
• CONSISTING OF SPECIFIC CHEMICAL ELEMENTS, AND
• A DEFINITE ATOMIC ARRAY
• CRYSTALLINE STRUCTURE CRYSTAL
• CRYSTAL AND MINERAL INTERCHANGEABLE TERMS

6
MINERALS

• Minerals divided into two main groups based on
  Silica content
• Silica (SiO) compound of molecularly bonded
  silicon (Si) and oxygen (O) molecules (SiO,
  SiO2, SiO4, SiO6 etc.)
• GROUP 1 SILICATES CONTAIN SILICA
• GROUP 2 NON-SILICATES (CONTAIN NO SILICA)

7
NON-SILICATE MINERALS

• Non-silicate minerals are very rare
• Make up 5 of Earths continental crust
• Considered valuable commercially as building
  materials, gemstones, iron ores for steel,
  ceramics, and more.
• Native metals gold, silver, copper, platinum
• Native elements diamonds, corundum Ruby (red)
  or Sapphire (blue)
• Carbonates calcite (used in cement)
• Oxides hematite (iron ores)
• Sulfides galena (lead ores)
• Sulfates gypsum (used in plaster, dry wall)
• Halides halite (table salt)

8
SILICATE MINERALS

• THE MOST ABUNDANT OF ALL MINERALS
• MAKE UP APPROXIMATELY 95 OF WEIGHT OF EARTHS
  CRUST
• CONTAIN VARYING AMOUNTS OF SILICA (SiO)
• DOMINANT COMPONENT OF MOST ROCKS
• IGNEOUS
• SEDIMENTARY
• METAMORPHIC

9
SILICATE MINERALS

• LISTED BELOW IN DECREASING OF SILICA ARE MOST
  COMMON SILICATE MINERALS
• QUARTZ (SiO2) (High Silica content 100)
• FELDSPARS (PLAGIOCLASE - (Na,Ca)(Si,Al)4O8 )
• MICAS (MUSCOVITE -KAl2(AlSi3O10)(F, OH)2 and
• BIOTITE - K (Fe, Mg)3 AlSi3 O10 (F, OH)2 )
• AMPHIBOLES (Hornblende -Ca2(Fe,Mg)5Si8O22(OH2)
• PYROXENES (Augite (Mg,Fe) SiO3)
• OLIVINE - (Mg, Fe)2SiO4, (Low Silica
  content 40)

10
SILICATE MINERALS

• SILICATE MINERALS ARE BROKEN INTO THREE MAIN
  GROUPS ACCORDING TO SILICA
• FELSIC High percent
• MAFIC
• ULTRAMAFIC Low percent

11
FELSIC SILICATE MINERALS

• FELSIC SILICATE MINERALS HAVE A HIGH
  CONCENTRATION OF SILICON, OXYGEN, ALUMINIUM AND
  POTASSIUM
• FELSIC SILICATES HIGH SiO (75-100)
• QUARTZ (100 SiO2)
• FELDSPARS (Plagioclase, Orthoclase)
• MUSCOVITE MICA

12
QUARTZ
FELDSPAR
MUSCOVITE MICA
13
MAFIC SILICATE MINERALS

• MINERALS WITH HIGH CONCENTRATION OF MAGNESIUM AND
  IRON, PLUS CALCIUM AND SODIUM, AND LOWER AMOUNTS
  OF SILICON AND OXYGEN
• MAFIC SILICATES - LESS SiO (50-60)
• BIOTITE MICA
• AMPHIBOLE (Hornblende)
• PYROXENE (Augite)

14
BIOTITE MICA
PYROXENE (AUGITE)
AMPHIBOLE (HORNBLENDE)
15
ULTRAMAFIC SILICATES

• MINERALS WITH GREATER CONCENTRATION IN MAGNESIUM
  AND IRON. VERY RARE AT EARTHS SURFACE
• ULTRA MAFIC SILICATES - VERY LOW SiO (less than
  50)
• VERY RARE AT SURFACE
• OLIVINE (FORSTERITE, FAYALITE)

16
(No Transcript)
17
WHAT ARE ROCKS?

• AGGREGATIONS OF 2 OR MORE MINERALS
• Same or different minerals combine together
• THREE CATEGORIES
• IGNEOUS
• SEDIMENTARY
• METAMORPHIC

18
IGNEOUS ROCKS

• Ignis Latin for Fire
• FORMED FROM COOLED, SOLIDIFIED MOLTEN MATERIAL
  AT, NEAR, OR DEEP BELOW, THE SURFACE
• TYPES
• PLUTONIC (INTRUSIVE) IGNEOUS ROCKS COOLED AND
  SOLIDIFIED BELOW SURFACE AT GREAT DEPTHS
• VOLCANIC (EXTRUSIVE) IGNEOUS ROCKS COOLED AND
  SOLIDIFIED AT OR NEAR THE SURFACE THROUGH
  VOLCANIC ERUPTIONS

19
IDENTIFICATION OF IGNEOUS ROCKS

• TWO IDENTIFICATION PROCESSES FOR PLUTONIC OR
  VOLCANIC IGNEOUS ROCKS
• TEXTURE
• Size, shape and manner of growth of individual
  crystals
• MINERAL COMPOSITION
• Based on SiO content
• Felsic, Intermediate, Mafic
• (high Silica low Silica)

20
TEXTURE IDENTIFICATION

• SIZE, SHAPE OF CRYSTALS AND MANNER OF GROWTH
• FINE GRAINED TEXTURE
• VERY TINY, MINERAL CRYSTALS VISIBLE ONLY WITH
  MAGNIFICATION
• INDICATES FAST COOLING AT SURFACE CRYSTALS
  SOLIDIFIED QUICKLY WITH NO TIME TO GROW
• COARSE-GRAINED TEXTURE
• LARGE, EASILY-VISIBLE MINERAL CRYSTALS
• INDICATES SLOW COOLING AT DEPTH CRYSTALS
  SOLIDIFIED SLOWLY WITH LOTS OF TIME TO GROW

21
TEXTURE IDENTIFICATION
Fine-Grained Textures
Coarse-Grained Textures
22
MINERAL COMPOSITION

• CLASSIFIED BY SILICA (SiO) CONTENT
• FELSIC MORE THAN 85 SILICA
• INTERMEDIATE 60-85 SILICA
• MAFIC LESS THAN 60 SILICA

23
MINERAL COMPOSITION OF COMMON IGNEOUS ROCKS

• FELSIC IGNEOUS ROCKS (gt85 SiO)
• GRANITE
• PLUTONIC-INTRUSIVE PHANERITIC TEXTURE FELSIC
  MINERAL COMPOSITION
• RHYOLITE
• VOLCANIC-EXTRUSIVE APHANITIC TEXTURE FELSIC
  MINERAL COMPOSITION
• INTERMEDIATE IGNEOUS ROCKS (60-85 SiO)
• DIORITE
• PLUTONIC-INTRUSIVE PHANERITIC TEXTURE
  INTERMEDIATE MINERAL COMPOSITION
• ANDESITE
• VOLCANIC-EXTRUSIVE APHANITIC TEXTURE
  INTERMEDIATE MINERAL COMPOSITION
• MAFIC IGNEOUS ROCKS (lt60 SiO)
• GABBRO PLUTONIC-
• INTRUSIVE PHANERITIC TEXTURE MAFIC MINERAL
  COMPOSITION
• BASALT
• VOLCANIC-EXTRUSIVE APHANITIC TEXTURE MAFIC
  MINERAL COMPOSITION

24
FELSIC IGNEOUS ROCKS
RHYOLITE
EXTRUSIVE
INTRUSIVE
GRANITE
25
INTERMEDIATE IGNEOUS ROCKS
ANDESITE
EXTRUSIVE
DIORITE
INTRUSIVE
26
MAFIC IGNEOUS ROCKS
GABBRO
INTRUSIVE
BASALT
EXTRUSIVE
27
IGNEOUS ROCKS
28
OTHER IGNEOUS ROCKS

• VOLCANIC GLASS
• OBSIDIAN VOLCANIC-EXTRUSIVE NO CRYSTALS FORM
  SILICA-RICH, COOLED INSTANEOUSLY
• PUMICE VOLCANIC-EXTRUSIVE NO CRYSTALS FORM
  SILICA-RICH SOLIDIFIED FROM GASSY LAVA
• PYROCLASTIC ROCKS
• TUFF VOLCANIC-EXTRUSIVE SOLIDIFIED WELDED ASH

29
VOLCANIC GLASS
OBSIDIAN
PUMICE
30
PYROCLASTIC IGNEOUS ROCKS
WELDED TUFF
31
SEDIMENTARY ROCKS

• WEATHERING PROCESSES BREAK ROCK INTO PIECES,
  SEDIMENT.
• READY FOR SEDIMENTATION PROCESSES
• TRANSPORTATION DEPOSITION BURIAL AND
  LITHIFICATION INTO NEW ROCKS.

32
SEDIMENTARY PROCESSES

• LITHIFICATION
• As sediment is buried several kilometers beneath
  the surface, heated from below, pressure from
  overlying layers, heat, and chemically-active
  water converts the loose sediment into solid
  sedimentary rock
• Compaction - volume of a sediment is reduced by
  application of pressure
• Cementation - sediment grains are bound to each
  other by materials originally dissolved during
  chemical weathering of preexisting rocks
• typical chemicals include silica and calcium
  carbonate.

33
CLASSIFYING SEDIMENTARY ROCKS

• THREE SOURCES FOR SEDIMENTARY ROCKS
• Detrital (or clastic) sediment is composed of
  transported solid fragments (or detritus) of
  pre-existing igneous, sedimentary or metamorphic
  rocks
• Chemical sediment forms from previously dissolved
  minerals that either precipitated from solution
  in water, or were extracted from water by living
  organisms
• Organic sedimentary rock consisting mainly of
  plant remains

34
CLASTIC/DETRITAL SEDIMENTARY ROCKS

• CLASSIFIED ON GRAIN OR PARTICLE SIZE
• Shales finest-grained
• Sandstones medium-grained
• Conglomerates Breccias coarse-grained

35
SHALES CLASTIC SEDIMENTARY

• SHALES finest-grained clastic sedimentary rocks
  composed of very small particles (from
  lt0.004-0.063 mm)
• 50 of all sedimentary rocks are Shales
• Consist largely of Clay minerals (weathered
  granite in many cases)
• Subcategories Claystones Siltstones Mudstones
• Economic value building material china and
  ceramics spark plug housings

36
SHALES
Burgess Shale in Canada
Limestone on black shale
37
MUDSTONES, SILTSTONES
Identified by decreasing amounts of sand and
increasing amounts of clay
38
SANDSTONES

• SANDSTONES medium-grained clastic sedimentary
  rocks particle-size (0.063-2 mm)
• 25 of all sedimentary rocks fall into this
  category
• Economic value glass natural reservoirs for
  oil, gas, and groundwater

39
SANDSTONES
40
CONGLOMERATES - BRECCIAS

• CONGLOMERATES AND BRECCIAS
• The coarsest of all the clastic sedimentary rocks

• Composed of particles gt2 mm in diameter
• Conglomerate - the particles are rounded
• Breccia - the particles are angular

41
CONGLOMERATES
42
BRECCIAS
43
CHEMICAL SEDIMENTARY ROCKS

• TWO CATEGORIES
• INORGANIC CHEMICAL SEDIMENTARY
• ORGANIC CHEMICAL SEDIMENTARY

44
INORGANIC CHEMICAL SEDIMENTARY ROCKS

• Formed when dissolved products of chemical
  weathering precipitate (form out of) from
  solution
• Most common types
• Inorganic limestones and cherts precipitates
  directly from seawater and fresh water
• Evaporites precipitates when ion-rich water
  evaporates
• Dolostones Origin is still in debate

45
INORGANIC - LIMESTONES

• Limestones - account for 10 - 15 of all
  sedimentary rocks formed from Calcite or Calcium
  Carbonate (CaCO3).
• Formed as pure carbonate muds accumulate on the
  sea floor
• Also formed on land
• Tufa - a soft spongy inorganic limestone that
  forms where underground water surfaces
• Travertine - forms in caves when droplets of
  carbonate-rich water on the ceiling, walls and
  floors precipitate a carbonate rock stalactites
  and stalagmites

46
LIMESTONES
TRAVERTINE
47
ORGANIC LIMESTONES

• Formed with calcite from marine environment
  CaCO3 shells and internal/external skeletons of
  marine animals
• Coquina - crushed shell fragments cemented with
  CaCO3
• Chalk - made from billions of microscopic
  carbonate- secreting organisms
• Coral Reefs - Formed from the skeletons of
  millions of tiny invertebrate animals who
  secrete a calcite-rich material. Live condo
  style while algae acts as the cement to create
  the large structures called reefs.
• Organic Chert - formed when silica-secreting
  microscopic marine organisms die (radiolaria
  single-celled animals and diatoms skeletons
  of singled-celled plants)
• Flint - an example of an Inorganic Chert

48
COQUINA, CHALK AND FOSSILIFEROUS LIMESTONES
COQUINA
FOSSILIFEROUS LIMESTONE
CHALK
49
ORGANIC SEDIMENTARY ROCKS

• Coal - Organic sedimentary rock consisting mainly
  of plant remains
• Formation
• Burial of decaying vegetation
• Increasing pressure from the overlying layers
  expels water, CO2 and other gases
• Carbon accumulates.
• STAGES
• Peat - formed early in the process, when the
  original plant structure
• can still be distinguished.
• Lignite - a more hardened form of Peat
• Bituminous - more pressure and more heat produce
  this moderately
• hard coal.
• Anthracite - the hardest coal - formed from
  metamorphic processes
• under extreme heat and pressure - Hard - Shiny
  - the most
• desired as an energy resource.

50
COAL
PEAT
LIGNITE
ANTHRACITE
BITUMINOUS
51
SEDIMENTARY ENVIRONMENTS

• Lakes
• Lagoons
• Rivers
• Ocean bottoms
• Estuaries
• Salt Flats
• Playas
• Glacial environments

52
METAMORPHIC ROCKS

• METAMORPHISM process by which conditions within
  the Earth alter the mineral content and structure
  of any rock - igneous, sedimentary or metamorphic
  - without melting it.
• Metamorphism occurs when heat and pressure exceed
  certain levels, destabilizing the minerals in
  rocks...but not enough to cause melting
• Ion-rich fluids circulating in and around rocks
  also influences metamorphism

53
METAMORPHIC PROCESSES

• HEAT
• (2000 C or 4000 F) reached near 10 km (6 miles)
  beneath the surface.
• PRESSURE
• gt 2 bar or 2000 mb, which is generally found 6
  km (4 miles) beneath the Earths surface
• FLUIDS Chemically-active water is the usual
  fluid and comes from various sources

TEMPERATURE/PRESSURE For every 3 kilometers
depth in the Earth, pressure increases by about 1
kb. Average temperature gradient in the Earth
increases 30 C per km
54
CHANGES IN METAMORPHIC ROCKS

• Metamorphic processes cause many changes in rocks

• Increased density
• Growth of larger crystals
• FOLIATION reorientation of the mineral grains
  into layers or banded texture
• Transformation of low-temperature minerals into
  high-temperature minerals

55
CLASSIFYING METAMORPHIC ROCKS

• TEXTURE the size, shape and distribution of
  particles in a rock
• texture is determined by grade of metamorphism
• Low grade (less than 6000C and 4 kilobars
  pressure)
• Intermediate grade occurs at a variety of
  temperatures and pressures.
• High grade (greater than 6000C and 4 kilobars
  pressure)

56
FOLIATED TEXTURES

• Foliated texture more pressure and mineral
  grains realign themselves and grow into larger
  crystals
• Three types of foliated texture
• Rock or Slaty Texture
• Schistosity
• Gneissic Texture

57
ROCK SLATY TEXTURE - SLATE

• Shale metamorphosed to Slate
• clay minerals (stable at surface temperatures
  and pressures) become unstable and recrystallize
  into mica crystals
• Slate is formed under Low-Grade Metamorphism

58
SLATE
59
SCHISTOCITY - SCHIST

• More extreme pressures and temperatures mica
  crystals grow even larger - 1 cm in diameter.
• rock has scaly appearance - schistosity,
• referred to as a Schist.
• Schists formed under Intermediate-Grade
  Metamorphism
• Schists named for the mineral constituents in the
  parent rock
• mica schist
• talc schist
• garnet schist

60
SCHIST
Mica schist
Ruby schist
61
GNEISSIC TEXTURE - GNEISS

• Light and dark silicate minerals separate and
  re-align themselves into bands
• Rocks with this texture are called Gneiss
• Gneiss forms from High Grade Metamorphism
• Typical parent rocks for Gneiss
• granite
• diorite
• gabbro
• shale

62
GNEISS
63
NON-FOLIATED TEXTURES

• Rocks with only one mineral metamorphose without
  a visibly foliated texture
• Limestone metamorphoses into Marble as the
  interlocking calcite crystals grow larger
• Quartz Sandstone metamorphoses into Quartzite

64
MARBLE AND QUARTZITE
MARBLE
QUARTZITE
65
METAMORPHIC ENVIRONMENTS

• CONTACT METAMORPHISM
• Metamorphism of a rock touched by the intense
  heat of migrating magma.
• REGIONAL METAMORPHISM
• Burial metamorphism - occurs when rocks are
  overlain by more than 6 miles of rock or sediment
• Dynamothermal metamorphism - occurs when rocks
  are caught between two convergent plates during
  mountain building
• OTHER METAMORPHIC ENVIRONMENTS
• Hydrothermal metamorphism - chemical alteration
  of preexisting rocks by hot seawater near
  seafloor spreading or subduction zones
• Fault metamorphism - occurs as rocks grinding
  past one another create a form of directed
  pressure, as well as considerable frictional heat

• Shock metamorphism - occurs when a meterorite
  strikes the Earth surface, resulting in
  tremendous pressures and temperatures at the
  impact sites. The shocked minerals do not
  fracture, but rather recrystallize

66
Contact and Regional Metamorphism
Regional Metamorphism
Contact Metamorphism
67
ROCK FORMING PROCESSES
68
THE ROCK CYCLE
